Clary Corporation DT1000R Owner's Manual

Dtr (et) series continuous power system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PRELIMINARY
Owner's
Operating
Manual
DTR (ET) SERIES
CONTINUOUS POWER SYSTEM
MODELS COVERED:
DT1000R(ET)
CLARY CORPORATION
1960 S. Walker Avenue
Monrovia, California 91016
Telephone
626-359-4486
800-44 CLARY
Fax.
626-305-0254
World Wide Web
HTTP: // www.signalpower.com
e-mail
signalpower@clary.com
Information contained herein is the property of Clary Corporation, is proprietary, confidential, and not to be
disclosed, disseminated or used except for the purpose provided by
CLARY CORPORATION
P/N 510-12750 REV. NR -Date: 2/2001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DT1000R and is the answer not in the manual?

Questions and answers

Related Manuals for Clary Corporation DT1000R

Summary of Contents for Clary Corporation DT1000R

  • Page 1 World Wide Web HTTP: // www.signalpower.com e-mail signalpower@clary.com Information contained herein is the property of Clary Corporation, is proprietary, confidential, and not to be disclosed, disseminated or used except for the purpose provided by CLARY CORPORATION P/N 510-12750 REV. NR -Date: 2/2001...

  • Page 2: Table Of Contents

    T H E C O N T I N U O U S P O W E R C O M P A N Y TABLE OF CONTENTS TITLE PAGE TABLE OF CONTENTS INTRODUCTION TECHNICAL DESCRIPTION PACKAGING PHYSICAL DESCRIPTION INSTALLATION OPERATION SIGNALS AND INTERFACING SPECIFICATIONS...

  • Page 3: Introduction

    T H E C O N T I N U O U S P O W E R C O M P A N Y INTRODUCTION This Owner’s Operating Manual is provided with ongratulations! You have selected the your new DTR(ET) UPS. It will enhance your highest quality protection for your continuous understanding of the product and its functions.

  • Page 4: Technical Description

    T H E C O N T I N U O U S P O W E R C O M P A N Y TECHNICAL DESCRIPTION Reference the block diagram for a simplified explanation of the system’s operation. The AC utility he Digital Technology-Extreme Temperature source is connected to the power and micro (DTR(ET) Series Continuous Power System...
  • Page 5 T H E C O N T I N U O U S P O W E R C O M P A N Y DT1000R(ET) UPS AC IN DC IN BATTERY BANK SIMPLIFIED SYSTEM INTERCONNECT...

  • Page 6: Packaging

    T H E C O N T I N U O U S P O W E R C O M P A N Y PACKAGING our UPS has been carefully packaged to These units are encapsulated in a protective wrap withstand most abuse sustained during that comes apart once the product is removed from shipment.

  • Page 7: Physical Description

    Pictured below is the front view of the model operating component’s name at the bottom with a DT1000R(ET). Plate with items 16 through 21 can brief identification. In the next section, a complete be repositioned to the rear panel. Reference the explanation of all numbered items will be enhanced figure on the adjacent page.
  • Page 8 T H E C O N T I N U O U S P O W E R C O M P A N Y DT1000R(ET) REAR PANEL VIEW 120VAC OUTPUT (LOAD II)- System output 120VAC OUTPUT (LOAD I)- System output...

  • Page 9: Summary Of Indicators And Controls

    T H E C O N T I N U O U S P O W E R C O M P A N Y SUMMARY OF INDICATORS AND Alarm Silent/Test - A momentary push-button switch that controls two different functions CONTROLS depending on the mode of operation.

  • Page 10: Installation

    T H E C O N T I N U O U S P O W E R C O M P A N Y INSTALLATION odels can be installed in a 19" rack system. The air should remain free from excessive dust Units are supplied with add-on brackets for and chemical fumes.

  • Page 11: Operation

    T H E C O N T I N U O U S P O W E R C O M P A N Y OPERATION • nce the system has been properly installed, Push and hold in the COLD START switch until it is ready to operate.

  • Page 12: Signals And Interfacing

    T H E C O N T I N U O U S P O W E R C O M P A N Y SIGNALS AND INTERFACING shutdown in battery mode. This conserves the here are two DB-9, subminiature, female battery life once an orderly shutdown has been connectors.

  • Page 13: Specifications

    T H E C O N T I N U O U S P O W E R C O M P A N Y SPECIFICATIONS ELECTRICAL DESIGN Input Standard Features Power Factor Corrected, Digital Regenerative™ On-Line, Sinewave Voltage 120VAC +12%, -25% Inverter Powers Load Continuously (without Battery discharge) Extended Brownout Protection...

  • Page 14: Care And Maintenance

    T H E C O N T I N U O U S P O W E R C O M P A N Y CARE AND MAINTENANCE his device is designed to be maintenance-free. CAUTION - Do not open or mutilate the battery or It can be cleaned with a damp cloth or batteries.

  • Page 15: Service And Repair

    The Service Department cannot take responsibility Clary Corporation for any unit damaged in return shipment. All units 1960 S. Walker Avenue must be returned prepaid to:...

  • Page 16: Warranty

    Page 16...
