Clary Corporation SP Series User & Service Manual

Continuous power system
Hide thumbs Also See for SP Series:
Table of Contents

Advertisement

Quick Links

Download this manual
User & Service
Information contained herein is the property of Clary Corporation, is proprietary,
confidential, and not to be disclosed, disseminated or used except for the purpose
P/N 510-18400, REV. A
Manual
SP SERIES
CONTINUOUS POWER SYSTEM
MODELS COVERED:
SP-1250 XLE
CLARY CORPORATION
CLARY CORPORATION
CLARY CORPORATION
CLARY CORPORATION
150 E. Huntington Drive
Monrovia, California 91016
Telephone
Fax.
World Wide Web
E-Mail
CLARY CORPORATION
1A\PROJECT FILES\403
626-359-4486
800-44 CLARY
626-305-0254
HTTP: // WWW.CLARY.COM
SALES @ CLARY.COM
provided by
09/24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP Series and is the answer not in the manual?

Questions and answers

Related Manuals for Clary Corporation SP Series

Summary of Contents for Clary Corporation SP Series

  • Page 1 World Wide Web HTTP: // WWW.CLARY.COM E-Mail SALES @ CLARY.COM Information contained herein is the property of Clary Corporation, is proprietary, confidential, and not to be disclosed, disseminated or used except for the purpose provided by CLARY CORPORATION P/N 510-18400, REV. A...

  • Page 2: Table Of Contents

    T H E C O N T I N U O U S P O W E R C O M P A N Y TABLE OF CONTENTS INTRODUCTION How it Works ........................5 Operating Modes ......................6 Packaging.......................... 7 Physical Description......................7 Summary Of Indicators and Controlls..
  • Page 3 T H E C O N T I N U O U S P O W E R C O M P A N Y LIST OF FIGURES Figure 1: PACKAGING..................... 7 Figure 2: FRONT PANEL VIEW SP1250XLE..............8 Figure 3: BYPASS SWITCH INDICATORS AND CONTROLS ........10 Figure 4: SP1250 INSTALLATION WITH LITHIUM BATTERY PACK......
  • Page 4 “IMPORTANT SAFETY INSTRUCTIONS” “SAVE THESE INSTRUCTIONS” This manual contains important safety instructions that should be followed during installation and maintenance of the UPS and batteries. The instructions should be followed during installation and maintenance of the UPS and batteries. Be aware of the following symbols and their meaning as they appear throughout the manual: This symbol indicates that This symbol indicates that...

  • Page 5: Introduction

    1 Introduction 1.1 How It Works The SP1250 XLE is a full‐featured on‐line dual conversion UPS rated for 1250 VA / 875 W that comes in a rack‐mounted 1U form factor. Clary’s unique technology conditions utility power and protects critical and valuable cabinet equipment from a broad range of power disturbances. The SP1250 XLE is designed to provide extended run time when configured with an available lithium battery pack or a 4 battery AGM system ‐...

  • Page 6: Operating Modes

    Operating Modes Once the system has been properly installed, it is ready to operate. The following procedures will explain how to start-up the system while plugged into rated electrical power and also how to start-up with no AC power available. Normal Operation on AC Start-Up: Verify that the unit is plugged into properly rated electrical power.

  • Page 7: Packaging

    Packaging 1. 3 Your UPS has been carefully These units are encapsulated packaged to withstand most in a protective wrap that abuse sustained during comes apart once the product shipment. The packing material is removed from the shipping has been specifically designed carton.
  • Page 8 Figure 2 SP1250 XLE FRONT PANEL VIEW Figure 1: FRONT PANEL VIEW SP-1250 XLE SHOWN AC IN PROGRAM LED AC IN FUSE ALARM SWITCH AC OUT COLD START SWITCH DC IN AC SENSE LED SYSTEM SWITCH LCD DISPLAY RELAY CONTACTS LCD CONTROL REMOTE DB9 SIGNAL...

  • Page 9: Summary Of Indicators And Controlls

    1. 5 SUMMARY OF INDICATORS AND CONTROLS AC IN – IEC-320 Inlet C14 type used to supply 120VAC utility power to the system. AC IN FUSE – Input Inlet protection. 15A, 250VAC, 3AG. AC OUT – IEC Outlet C13 type used to supply 120VAC Inverter generated power provided. DC IN –...
  • Page 10 BYPASS SWITCH SUMMARY OF INDICATORS AND CONTROLS (SPH-302 Shown) SPH-302/SPH-303 BYPASS SWITCH – When switch is in the “ON” Position, bypass box AC-Out will provide inverter power from the UPS as long as inverter power is available. If inverter power is not available, bypass power will be supplied at the output.

  • Page 11: Preparation

    2 Installation & Operations 2.1 Preparation Ensure that the Installation Requirements will be met. (See following section). • Read this manual thoroughly. • Assemble wiring diagrams. • Installation The system is lightweight and can be easily moved. Some important points to consider when positioning a unit for operation: The installation site should maintain an ambient air temperature of less than 165 ºF (74 ºC).
  • Page 12 Figure 4 Above: Installation of the SP1250 XLE with the SPH-303 bypass switch and single lithium battery pack. Figure 5 Above: Installation of the SP1250 XLE with the SPH-303 bypass switch and double rack mount.
  • Page 13 Figure 6 Above: Installation of the SP1250 XLE and SPH-303 bypass switch with battery monitor and four AGM batteries. Balancers: SPHBB4, SPHEQ4.

  • Page 14: Operating Configuration And Setup

    Operation Configuration & Setup Once the system has been properly installed, it is ready to operate. The following procedures will explain how to start-up the system while plugged into rated electrical power and also how to start-up with no AC power available. Normal Operation on AC Start-Up: Verify that the unit is plugged into properly rated electrical power.

  • Page 15: Signals And Interfacing

    SIGNALS AND INTERFACING There is one DB-9, sub-miniature, female connector and one USB connector. These connectors are provided for communications links to a computer or sophisticated monitoring device. Use the USB Type B connector when using the Clary Universal Traffic software which can be downloaded at www.Clary.com. See following page for USB setup instructions.

  • Page 16: Specifications

    SPECIFICATIONS ELECTRICAL Input Voltage 120VAC 85VAC to 155VAC (without Battery discharge) Frequency 45Hz to 65Hz Output Voltage 120VAC +3% Frequency 50Hz or 60Hz +.25% (software selectable) Power 1000W / 1250VA Crest Factor Ratio @50% Load Up to 4.8:1 (Non-linear load and @75% Load Up to 3.2:1 less than 5% THD) Typical...

  • Page 17: Usb Setup

    USB SETUP Contact Clary Corporation or your representative for latest software version. o SP560_SP1250LE SERIES Software o CDC_PCDriver Connect the USB cable from your computer to the UPS’s USB port (use the USB type B (Square) port). Turn on the UPS.
  • Page 18 6. Select the “Include this location in the search:” then click “Browse”. Select the CDC_PCDriver folder then click "Next." 7. The driver will then be installed.
  • Page 19 Driver is now installed. Click “Finish”. 9. Go to your device Manager, then click on the “Ports (COM & LPT)” tab. You will see the USB CDC serial port emulation (Com 1, 2, 3…etc.). This will be the com port assigned to your USB port. This is the Com port you will use when connecting to the Clary Software while using the USB port.

  • Page 20: Snmp Configuration

    SNMP Configuration The UPS system includes an SNMP card. Below are the basic instructions to find or change the IP address of the SNMP card. To see more detailed information, see the manual that is located on the CD for the SNMP card. IP address comes set from the factory at 172.17.10.10.
  • Page 21 SNMP Extended Device Support – CT-16F, EMD Module The CT-16F (Environmental Monitoring Device) is a connectivity device that allows you to remotely monitor the temperature, humidity and status of two contact devices. Its connection to the USHA Card enables monitoring or notification of alarms via a standard Web browser. SNMP EMD Features 1.

  • Page 22: Programmable Lcd Display

    3 PROGRAMMABLE LCD DISPLAY 3.1 Introduction load: 100% ONLINE bat: 100%, 115Vac, 60Hz stat: ry:000000 Figure 7 The LCD display on the UPS front panel is used to show various operational parameters of the UPS (in real time) as well as other important system information. It is also used to program the six relay c ontacts on the front of the UPS.

  • Page 23: Main Screen

    Main Screen The Main screen will show various UPS status information. Use the “Arrow” buttons to scroll up and down to see the information below. load: 100% ONLINE bat: 100%, 115Vac, 60Hz stat: ry:000000 _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ UPS Connect: 192.168.7.250 type: Static IP...

  • Page 24: Event Log Status Screen

    Event Log Status Screen The Event log status screen will show UPS events. From the main screen, press the “Select” button until you reach this screen. Event Log Status >> READ CLEAR Use the “Arrow” buttons to select Read or Clear. Press Enter to choose your desired choice. If Read is selected, use the “Arrow”...

  • Page 25: Relay Rules Screen

    Relay Rules Screen The Relay rules screen will allow the user to configure the 6 relay contacts on the front panel. See Relay Rules/Set table on next page. From the main screen, press the “Select” button until you reach this screen. Relay Rules >>...

  • Page 26: Relay Rules Set Table

    Relay Rules/Set Table Rule Description SystemOn Turn relay on/off 0-Off, 1-On BatRunTime Activates relay after x minutes on battery Minutes LowBatVolt Activates relay after x volts on battery Volts LowBatCap Activates relay after battery capacity reaches x% LowEstTime Activates relay after battery low estimated time is reached Minutes OpMode Operation Mode...

  • Page 27: Configuration Screen

    Configuration Screen The Configuration screen allows the user to configure UPS settings. From the main screen, press the “Select” button until you reach this screen. Configuration >> READ/(Change) Press the “Enter” button. System Date: 12-18-2019 System Time: 17:15:30 IP Address: 000.000.000.000 Bat Install Date: 04-05-2019...

  • Page 28: Care And Maintenance

    4 CARE AND MAINTENANCE 4.1 Safety There are hazardous high voltages and materials present in the UPS system which present safety risks. You MUST follow basic safety procedures when maintaining the UPS. In addition please note the following: ELECTRICAL SAFETY Hazardous high voltages are present in this product, which can cause electrical shock.

  • Page 29: Preventive Maintenance

    4.2 Preventive Maintenance CLEANING This device is designed to be maintenance-free. It can be cleaned with a damp cloth or nonabrasive cleanser. WARNING: Do not use ACETONE-BASE cleaning solutions. Keep cleaning solutions out of the electrical receptacles on this device. Be sure filters, vents and fans are kept free from accumulation of dust, dirt or lint.

  • Page 30: Battery Maintenance

    4 . 3 BATTERY RECYCLING The batteries used in this equipment are recyclable. Proper disposal is required and mandated • by law. The batteries contain lead and pose a hazard to the environment and human health if not dispose of properly. Refer to local codes for proper disposal requirements or return the batteries to the factory.

  • Page 31: Service And Repair

    Service and Repair Your SP-XLE Series UPS is backed by one of the finest customer service teams available. Write or call them at any time to obtain more information about your unit. Clary Corporation 150 E. Huntington Drive Monrovia, CA 91016...

  • Page 32: Warranty

    TIME AND SCOPE OF WARRANTY: 1.1. Clary Corporation hereby warrants parts shipped under this Agreement to be free from defective workmanship for a period of 2 years following date of shipment. Accidental damage, misuse or normal wear and tear shall not be construed as a defect.
