Glossary; Specifications - Sansui WLD+201L User Manual

18. Glossary

DAB Digital Audio Broadcasting
DLNA Digital Living Network Alliance
DLS Dynamic Label Segment – short text information broadcast with DAB audio
FM Frequency Modulation
MSC (USB) Mass Storage Class (device)
RDS Radio Data System
UI User Interface
UPnP Universal Plug and Play
USB Universal Serial Bus
WLAN Wireless Local Area Network

19. Specifications

Operating voltage: AC 220/240 V/ ~ 50 Hz
-
Max. power consumption: 12 W
-
Harmonic Distortion: < 0.2% at 1KHz, 1W
-
- Freq Response: 20Hz-20KHz, +/ -3dB
S/N Ratio: > 83dB(A)
-
802.11b/g – WEP, TKIP, WPA, WPA2, WPS security
-
DAB (Band 3)
-
- DAB+ with additional AAC+ codec
Audio playback from USB (USB port is NOT Apple compatible)
-
uPNP support
-
iPhone apps support
-
- Frequency range:
FM 87.5 – 108 MHZ
o
DAB 174.928 - 239.200 MHz
o
Connections:
-
Tuner antenna connection
o
RJ-45 Ethernet jack
o
Wi-Fi 2.4 G connection
o
Analog stereo output via RCA connection
o
Digital stereo output via optical TOSLINK connection
o
USB port
o
Audio File Support
Codec
FLAC
WAV
AAC
MP3
WMA
RealAudio
-
[1] – This is the maximum bit-rate tested. Higher bit-rates may work but are not currently tested.
[2] – This is the MP3 ISO standard maximum although some decoders can generate much higher data rates which we do not support.
[3] – The maximum offered by most encoders is 320 kbit/s (WMP limits it to 192 kbit/s)
All decoders use 32-bit internal precision and output 16-bit PCM except FLAC and MP3 which output 24-bit PCM
The FLAC decoder supports up to 24-bits/48k
NOTE:
Specifications and design are subject to possible modifications without notice
Supported Min
1.5 mbit/s [1] undefined
1.5 mbit/s [1] undefined
320 kbit/s [1] 8 kbit/s
320 kbit/s 8 kbit/s
320 kbit/s [1] 4 kbit/s
64 kbit/s 8 kbit/s
Max [1]
24-bits/48k
24-bits/48k
576 kbit/s
320 kbit/s [2]
384 kbit/s [3]
96 kbit/s
Page | 47
© Sansui UK 2012 WLD+201 IB Ver 1.0 Rev 0.0
