Summary of Contents for NetComm NP560
-
Page 2: Table Of Contents
Contents Introduction ..............................4 Package Contents ............................5 Installing the NetComm Indoor Wireless Booster (NP560/NP562) ...............6 Electrical Specification ..........................8 Appendix A: Registration and Warranty Information ..................9 NP560-NP562 Installation Guide YML821 Rev1... - Page 3 Alternatively you can visit the ACMA website at www.acma.gov.au Exceeding such power restriction limits is illegal and may result in undesirable radio interference which is strictly monitored by the ACMA. NP560-NP562 Installation Guide YML821 Rev1...
-
Page 4: Introduction
Introduction Thank you for purchasing NetComm’s INDOOR WIRELESS BOOSTER. This product is designed to dramatically increase your wireless coverage and eliminate non-coverage wireless trouble spots. The Indoor Wireless Booster will increase the effective range of your 802.11b/g Access Point or wireless Router. -
Page 5: Package Contents
You will need to use the detachable antenna from your Wireless Router or Access Point.) • One Installation Guide • One AC Adapter • One RG 316 Cable If any of the above items are missing or damaged, please contact NetComm immediately. NP560-NP562 Installation Guide YML821 Rev1... -
Page 6: Installing The Netcomm Indoor Wireless Booster (Np560/Np562)
Installing the NetComm Indoor Wireless Booster (NP560/NP562) Step1: Unscrew and remove the existing antenna on your Wireless Router or Access Point. Note: Your equipment must have a detachable SMA antenna in order to use the NP560/NP562 NetComm Wireless Booster Step 2: The connector cable that comes with the Booster needs to be installed in a specific way. - Page 7 The connector cable uses SMA connectors (adaptors are available from NetComm for other aerial connector types). The installation procedure is the same for NP560 (200mW) and NP562 (500mW) Boosters. Longer connection cables are available to connect your Router/Access Point to the Booster, however, these cables need to be made by a cable specialist and will reduce your signal strength.
-
Page 8: Electrical Specification
+/- 1dB over operating range Frequency Response Maximum 100mW - Minimum 6mW Transmit Input Power Output Power (11g @ 54Mbps) - NP560: 200mW (23dBm nominal) - NP562: 500mW (27dBm nominal) Transmit Gain 12dBm (adjustable) 14dBm (typical) Receive Gain 3.5dBm nominalOperating... -
Page 9: Contact Information
Appendix A: Registration and Warranty Information All NetComm Limited (“NetComm”) products have a standard 12 month warranty from date of purchase against defects in manufacturing and that the products will operate in accordance with the specifications outlined in the User Guide. However some products have an extended warranty option (please refer to your packaging). -
Page 10: Customer Information
NetComm. Failure to do so may cause damage to this product, fire or result in personal injury. -
Page 11: Product Warranty
2. This warranty shall not apply to software programs, batteries, power supplies, cables or other accessories supplied in or with the product; 3. The customer complies with all of the terms of any relevant agreement with NetComm and any other reason- able requirements of NetComm including producing such evidence of purchase as NetComm may require;...
