DeLonghi deep fryer Manual

EN
Read this manual carefully before installing and using
the appliance. This will ensure optimum results and
maximum safety.
DESCRIPTION
(see drawing on cover)
A. Lid
B. Viewing window (not all models)
C. Filter
D. Removable bowl
E. Release button
F. Timer
G. Timer button
H. Timer display (not all models)
I. Detachable control panel
L. Thermostat slider
M. Indicator light
N. Cable compartment
O. Pointer
P. Handle slider
Q. Basket handle
R. Basket
S. Filter cover
T. Filter cover hook
IMPORTANT WARNINGS
• Before use check that the voltage power supply cor-
responds to the one shown on the appliance data
plate.
• Only connect the appliance to electrical sockets
which have a minimum load of 10A and which are
properly earthed. (If the socket and the plug on the
appliance should prove incompatible, get a profes-
sionally qualified technician to replace the socket
with a more suitable one).
• Do not place the appliance near heat sources.
• If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent in order to
avoid a hazard.
• The appliance is hot when it is in use. DO NOT
LEAVE IT WITHIN THE REACH OF CHILDREN.
• Do not move the deep fryer when the oil is hot, as
there it could cause serious burns.
• The deep fryer must only be switched on after it has
been filled with oil or fat. If it is heated up while
empty, a thermal safety device comes into operation
which stops it from working. In this case it is neces-
sary to contact our nearest authorised service cen-
10
tre.
• If the deep fryer leaks oil, contact the technical ser-
vice centre or staff authorised by the Company.
• Before using the deep fryer for the first time, wash
the pan, the basket and the lid (removing the filter)
carefully with hot water and washing up liquid.
When this has been done, dry carefully.
After washing, dry thoroughly. Remove any water
left in the bottom of the container. This avoids dan-
gerous spurts of hot oil during use.
• The appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety. Children should
be supervised to ensure that they do not play with
the appliance.
• To move the appliance, use the special lifting hand-
les (I). (Never lift by the basket handle). Check that
the oil is cool enough (waiting about 2 hours).
• It is totally normal that, on first use, the appliance
emits a "new appliance" smell. If this happens,
aerate the room.
• Never leave the power cable hanging from the
edge of the surface the deep fryer is resting on,
where it could be grasped by a child or get in the
way of the user.
• When opening the lid, take great care to avoid hot
steam and splashes of boiling oil.
• Never use homemade or very acid oils.
• Appliance is not intended to be operated by means
of an external timer or separate remote-control
system.
• Only use the detachable control panel supplied with
F26237
• This appliance
2004/108/EC on Electromagnetic Compatibility
and EC regulation no. 1935/2004 of 27/10/2004
on materials intended for contact with food.
• This is a household appliance only. It is not intended
for use: in staff kitchen areas in shops, office and
other working environments, farm houses, by clients
in hotels, motels and other residential type environ-
ments, bed and Breakfast type environments.
OPERATING INSTRUCTIONS
Before plugging into the mains, always make sure there
is oil in the bowl.
Pour the oil into the bowl: 2,3 litres maximum capacity
conforms to EC directive
