Summary of Contents for Intermec USB Bluetooth Adapter
- Page 1 Instructions USB Bluetooth Adapter...
- Page 2 The information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and service Intermec- manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec.
-
Page 3: Table Of Contents
Contents What Is the USB Bluetooth Adapter?........5 Microsoft Windows XP with SP2 ........6 Installing the Bluetooth Adapter......6 Pairing Your SF51 and Host PC......6 Connecting Your SF51 to Your Host PC....7 Connecting From Your SF51....... 7 Connecting From Your PC...... - Page 4 USB Bluetooth Adapter Instructions...
-
Page 5: What Is The Usb Bluetooth Adapter
Before you get started, you need to: ® • install EasySet version 5.2 or later. EasySet is available on the CD that ships with the SF51 or from the Intermec web site at www.intermec.com. • note the Bluetooth address for your SF51. Bluetooth... -
Page 6: Microsoft Windows Xp With Sp2
Press the Scan button on your SF51. The scanner enters a discoverable state. On your PC desktop, double-click the Bluetooth icon on the taskbar. The Bluetooth Devices window appears. Click Add. The Add Bluetooth Device wizard appears. USB Bluetooth Adapter Instructions... -
Page 7: Connecting Your Sf51 To Your Host Pc
Scan the bar code onscreen with the SF51, or print the setup sheet and scan the bar code. The SF51 beeps once, the green status light flashes once, and the blue Intermec Ready-to-Work™ indicator starts blinking. To verify your connection with EasySet, select Communication > Connect. The Online Setup dialog box appears. -
Page 8: Connecting From Your Pc
When the SF51 connects to your host PC, it emits a series of beeps from low to high, and the blue Intermec Ready-to- Work indicator turns on and stays on. To disconnect from EasySet, select Communication > Disconnect. The SF51 disconnects from EasySet, emits a series of beeps from high to low, and the blue Intermec Ready-to-Work indicator starts blinking. -
Page 9: Collecting Data With Your Sf51
Note: Do not insert the adapter until you are prompted to by the software. Go to the Intermec web site at www.intermec.com. From the Service & Support menu, select Downloads. From the Select A Product drop-down list, choose Bar Code Scanners: SF51 Cordless Scanner. -
Page 10: Configuring Bluetooth Serial Communications
Press the Scan button on your SF51. The scanner enters a discoverable state. Start EasySet. Make sure that SF51 is selected as your product. From the EasySet commands window, select Data transmission settings > Bluetooth parameters > connect/disconnect. USB Bluetooth Adapter Instructions... - Page 11 Select Always allow this device to access this service and click OK. When the SF51 connects to your host PC, it emits a series of beeps from low to high, and the blue Intermec Ready-to- Work indicator turns on and stays on. To disconnect •...
-
Page 12: Connecting From Your Pc
Bluetooth address. Click Connect. Your PC connects to your SF51, your SF51 emits a series of beeps from low to high, and the blue Intermec Ready-to- Work indicator turns on and stays on. The Serial Port dialog box appears. -
Page 13: Collecting Data With Your Sf51
If necessary, configure your data collection application to receive data from the Bluetooth serial communications COM port. Scan a bar code with your SF51. The data is entered into your application. For more information about My Bluetooth Places, see the online help. USB Bluetooth Adapter Instructions... - Page 14 USB Bluetooth Adapter Instructions...
- Page 15 USB Bluetooth Adapter Instructions...
- Page 16 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com © 2005 Intermec Technologies Corporation. All rights reserved. USB Bluetooth Adapter Instructions *074479-004* P/N 074479-004...
