Aficionado
Icemaker
User Manual
Read this manual carefully before using
your new Aficionado ice maker. It is
suggested that you keep the manual in a
safe place after reading it for future
reference.
C883 / C887
09.09 / V1.0
Advertisement
Table of Contents
Related Manuals for Aficionado C883
Summary of Contents for Aficionado C883
- Page 1 Aficionado Icemaker User Manual Read this manual carefully before using your new Aficionado ice maker. It is suggested that you keep the manual in a safe place after reading it for future reference. C883 / C887 • This product is designed for indoor use only.
-
Page 2: Table Of Contents
Table of Contents O ve r v i ew … … … … … … … … … … . . … … . . … … … … . … … … . … … … … … … … … 2 Recognize Safety Symbols, Words and Labels ….……..…….….…….. -
Page 3: Overview
1. Overview Thank you for purchasing the Aficionado C88 Series Ice Maker. This product is a built-in type of ice maker that may also be used for “free-standing” applications. Your ice maker is designed for indoor usage, within your home, and should not be used for commercial purposes. The Aficionado C88 series ice maker produces transparent, clear ice of the highest quality, at a rate of 70 lbs per day. -
Page 4: Recognize Safety Symbols, Words And Labels
2. Recognize Safety Symbols, Words and Labels What you need to know about safety instructions Warnings and Important Safety Instructions appearing in this manual are not meant to cover all possible conditions and situations that may occur. Common sense, caution and care must be exercised when operating, moving or cleaning this product. -
Page 5: Safety Precautions
SAFETY PRECAUTIONS Read all of the instructions before using this appliance. When using this appliance, always exercise basic safety precautions, including the following: 1) Use this appliance only for its intended purpose as described in this use and care guide. 2) This ice maker must be properly installed in accordance with the installation instructions before it is used. - Page 6 Risk of child entrapment. Before you throw away your old ice maker, take off the door. This will reduce the risk of danger to children. Model number Thank you for choosing our Aficionado product. This easy-to-use manual will guide you in getting the best use of your Serial number ice maker.
-
Page 7: Set Up
4. Set Up After removing the packing materials, check the appearance of the ice maker for possible defects or irregularities. Should the product show any irregularity in its appearance, contact the dealer immediately. All packing materials (strings, box, Styrofoam, wood, etc.) should be placed out of children’s reach and disposed of properly. -
Page 8: Installation Specifications
Neutral water is not recommended. Water softeners should not be used for the water supply because they add minerals and soft ice may result. If you have any questions about the purity of water, address your inquiry about water treatment to your Aficionado dealer, or to a water quality expert in your area. - Page 9 14.9"(378) 24.97"(634.2) 21.1"(538) Fig. 1 Fig. 2 Fig. 3 Front View Side View Top View CAUTION The front and rear of the ice maker must be perfectly leveled. If installed on an uneven floor, and the unit is not leveled, ice clumping may occur due to improper drainage, as the drain is not able to process the water fast enough.
- Page 10 WARNING Requirements for Power Supply 120 volt, 60Hz, dedicated 15-amp circuit breaker and electric power are required. A separate circuit is required for grounding. The power cord of the product should be inserted into a suitable 3-prong grounding- type outlet. Important Information! A Ground Fault Circuit Interrupter (GFCI) is not recommended because the operation of the product may be stopped.
-
Page 11: Gravity Drain Pipe Model
Gravity Drain Pipe Model Shut- Off Valve Drain Tube This product is a gravity drain pipe model that requires a drain pipe Water Filter to run from the exhaust hole at the back of the product to the Locate drain Water Inlet Tube within 2"... -
Page 12: Drain Pump Model
Drain Pump Model Shut- Off Valve Water Inlet Tube Water Filter 1) Arrange the ice maker at the front of the opening of installation. 2) Install the inlet pipe (copper pipe with a diameter of Drain Tube 1/4”) on the wall and connect the water supply valve. 3) Connect the drain pipe from the wall to the ice maker. -
Page 13: Product Installation
8. Product Installation Important Information! Turn on the tap and check for any leakage at the connection. The user does not need to fill the container with water. The first batch of ice should be discarded. Ice production requires 1-2 hours. - Page 14 Door Reversal The direction in which the door swings opens may be changed. Hinges are attached to the right-hand side of the door when the product is shipped from the factory. The ice maker is designed so that the hinges may be installed on either side.
- Page 15 Installation of Custom Door Panels This description concerns the model on which a decorative door is installed. ① Loosen the anchor screws on the lower hinge of the door and separate the door. ② Arrange the decorative door so that it matches the door of the product.
- Page 16 Installation Checklist Important Information! The installer should check whether any installation part has been omitted and follow the check list below to ensure safe and proper installation. If you have any questions or problems regarding installation, address your queries to the distributor or dealer. ■...
-
Page 17: O P E R A T I N G T H E I C E M A K E
Operating the Ice Maker Initial Operation 1) Open the water supply valve connected with the ice maker. 2) Insert the ice maker plug into the electrical outlet. 3) Open the door and turn the switch at the lower end of the product to the “ICE”... - Page 18 The ice has a “top hat” shape (refer to Figure 10). Newly produced ice is clear and transparent. The inside of the ice is sometimes cracked; however, such cracks commonly occur in the production process and disappear with time. Ice stored in the container for a long time may gather frost on the outside and look cloudy.
-
Page 19: Cleaning The Ice Maker
Cleaning the Ice Maker All the exterior parts, door, ice container, condenser, water circulation parts, and ice scoop of the product should be kept clean. The ice maker should be cleaned periodically. Keeping the ice maker clean extends the lifespan of the product. Regular cleaning of the entire ice maker should be performed at least once a year. The frequency of cleaning the ice-production system should be increased depending upon the water quality;... -
Page 20: Maintaining The Ice Maker
Cleaning the Ice-Production System 1) Open the door and turn off the switch at the lower right front. 2) Remove all the ice and dispose of it or store it in a freezer. 3) Pour 4 ounces of a washing agent (liquid dishwashing detergent) into the water container of the ice maker. 4) Turn the switch to the “WASH”... -
Page 21: S P E C I F I C A T I O N
Specifications UNIT C883, C887 / C883P, C887P Rated Power Frequency Power Consumption WxDxH (mm) 378 x 634.2 x 863.3 (including legs) Dimensions WxDxH (inch) 14.9” x 24.97” x 34.0” (including legs) 45.5 / 47.5 Net Weight 100.3 / 104.7 53.1 / 55.1 Gross Weight 117.1 / 121.5... -
Page 22: Troubleshooting Guide
Troubleshooting Guide PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION Ice maker is unplugged Plug ice maker in. Reset breaker - if it happens again, call an authorized service Breaker tripped center. Switch turned to “OFF” Turn switch to “ICE”. Level of ice has reached sensor tube – it is normal for ice maker to Ice maker does not be off. -
Page 23: Warranty
Limited Warranty What is covered and for how long? 3. Customer service is provided by Aficionado. This warranty covers all defects in workmanship or To have your product serviced, please materials for a period of: contact customer service at 1-866-327-5817.
