Model No. HREX2076.99
Serial No.
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if parts are
damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT
DIRECTLY.
CALL TOLL-FREE:
1-888-922-4222
Mon.–Fri., 6 a.m.–6 p.m. MST
ON THE WEB:
www.healthriderservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Serial
Number
Decal
USER'S MANUAL
Visit our website at
www.healthrider.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for Healthrider N35 HREX2076.99
Summary of Contents for Healthrider N35 HREX2076.99
- Page 1 Mon.–Fri., 6 a.m.–6 p.m. MST ON THE WEB: www.healthriderservice.com CAUTION Read all precautions and instruc- tions in this manual before using this equipment. Keep this manual for future reference. USER’S MANUAL Visit our website at www.healthrider.com new products, prizes, fitness tips, and much more!
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............2 BEFORE YOU BEGIN . -
Page 3: Before You Begin
BEFORE YOU BEGIN Congratulations for selecting the new HEALTHRIDER N35 exercise cycle. Cycling is one of the most effec- tive exercises for increasing cardiovascular fitness, building endurance, and toning the body. The N35 exercise cycle offers a selection of features designed to let you enjoy this healthful exercise in the conve- nience and privacy of your home. -
Page 4: Assembly
ASSEMBLY To hire an authorized service technician to assemble the exercise cycle, call toll-free 1-800-445-2480. Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the pack- ing materials. Do not dispose of the packing materials until assembly is completed. In addition to the included hex keys, assembly requires a phillips screwdriver wrench As you assemble the exercise cycle, use the drawings below to identify small parts. - Page 5 1. While another person lifts the front of the Frame (1) slightly, attach the Front Stabilizer (3) to the Frame with two M10 x 75mm Carriage Bolts (51) and two M10 Nylon Locknuts (63). See the inset drawing. Loosen the Adjustment Knob (17), slide the Rear Frame (2) out of the Frame (1), and then retighten the Adjustment Knob.
- Page 6 5. Have another person hold the Seat Frames (7) under the Rear Frame (2) as shown. Attach the Seat Frames and the Seat (12) to the Rear Frame with four M6 x 42mm Button Screws (49) and four M6 Washers (55). See step 3.
- Page 7 8. Connect the Upper Wire Harness (36) to the Lower Wire Harness (65). Attach the Upright (13) to the Frame (1) with three M8 x 25mm Button Screws (33) and three M8 Split Washers (59). Be careful to avoid pinching the Wire Harnesses. 9.
-
Page 8: How To Operate The Exercise Cycle
HOW TO OPERATE THE EXERCISE CYCLE Program Button Profiles Program/Manual Button FEATURES OF THE CONSOLE The advanced console offers a selection of features designed to make your workouts more enjoyable and effective. When the manual mode of the console is selected, the resistance of the pedals can be changed with the touch of a button. - Page 9 Monitor your progress with the display. The upper half of the display will show the elapsed time, the distance you have pedaled, and the resistance level of the pedals. The display will change from one mode to the next every few seconds. The lower half of the display will show your pedal-...
- Page 10 HOW TO USE A PULSE PROGRAM Pulse program 1 is designed to keep your heart rate within a set range during your workout. Pulse program 2 is designed to keep your heart rate near a target heart rate setting that you select. Follow the steps below to use a pulse program.
- Page 11 Turn on the fan if desired. See step 6 on page 9. When you are finished exercising, the console will automatically turn off. See step 7 on page 9. HOW TO USE A PRESET PROGRAM Preset programs 3 and 4 automatically change the resistance of the pedals and prompt you to increase or decrease your pedaling pace as they guide you through effective workouts.
-
Page 12: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Inspect and properly tighten all parts of the exercise cycle regularly. Replace any worn parts immediately. To clean the exercise cycle, use a damp cloth and a small amount of liquid dish soap. Important: To avoid damage to the console, keep liquids away from the console and keep the console out of direct sunlight. -
Page 13: Conditioning Guidelines
CONDITIONING GUIDELINES The following guidelines will help you to plan your exercise program. Remember that proper nutrition and adequate rest are essential for successful results. WARNING: Before beginning this or any exercise program, consult your physician. This is especially important for persons over the age of 35 or persons with pre-existing health problems. -
Page 14: Part List
PART LIST—Model No. HREX2076.99 Key No. Qty. Description Frame Rear Frame Front Stabilizer Rear Stabilizer Backrest Handlebar Seat Frame Seat Frame Top Left Side Shield Right Side Shield Stabilizer Endcap Seat Upright Front Bushing Rear Bushing Console Adjustment Knob Wheel Wheel Cap Frame Pad Frame Stop... -
Page 15: Exploded Drawing
EXPLODED DRAWING—Model No. HREX2076.99 R0806A... -
Page 16: How To Order Replacement Parts
• the MODEL NUMBER of the product (HREX2076.99) • the NAME of the product (HEALTHRIDER N35 exercise cycle) • the SERIAL NUMBER of the product (see the front cover of this manual) • the KEY NUMBER and DESCRIPTION of the part(s) (see pages 14 to 15) ICON Health &...
