Model No. HRSY23080
Serial No.
The serial number is found in the
location shown below. Write the
serial number in the space above.
QUESTIONS?
As a manufacturer, we are
committed to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee complete satisfac-
tion through direct assistance
from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manu-
al for future reference.
Serial
Number
Decal
USERÕS MANUAL
PATENT PENDING
¨
Advertisement
Table of Contents
Related Manuals for Healthrider HRSY23080
Summary of Contents for Healthrider HRSY23080
- Page 1 Model No. HRSY23080 Serial No. The serial number is found in the location shown below. Write the serial number in the space above. Serial Number Decal QUESTIONS? As a manufacturer, we are committed to providing complete customer satisfaction. If you...
-
Page 2: Table Of Contents
3. If you feel pain or dizziness at any time while exercising, stop immediately and begin cool- ing down. 4. Use the home gym system only on a level surface. Cover the floor or carpet beneath the home gym system for protection. -
Page 3: Before You Begin
Mountain Time (excluding holidays). To help us assist you, please note the product model number and serial number before calling. The model number is HRSY23080. The serial number can be found on a decal attached to the HEALTHRIDER System (see the front cover of this manual). -
Page 4: Assembly
Assembly Note: This introduction will save you more time than it takes to read it! Making Things Easier for Yourself Everything in this manual is designed to ensure that the assembly of our products can be complet- ed successfully by anyone. However, it is impor- tant to recognize that your new equipment is a sophisticated product with many small parts. -
Page 5: Frame Assembly
Frame Assembly 1. Before beginning, make sure that you have read and understood the information on page 4. Locate and open the parts bag labeled ÒFRAME ASSEMBLY.Ó Insert four 3/8Ó x 2 3/4Ó Carriage Bolts (45) up through the indicated holes in the Stabilizer (4). Insert a 3/8Ó... - Page 6 4. Place the bracket on the lower end of the Main Upright (1) over the indicated 3/8Ó x 2 3/4Ó Carriage Bolts (45) in the Stabilizer (4). Hand tighten two 3/8Ó Nylon Locknuts (50) onto the Bolts. Do not tighten the Nylon Locknuts yet.
- Page 7 7. Locate two 3/8Ó x 4 3/4Ó Bolts (46) and slide a 3/8Ó Flat Washer (55) onto each of them. Insert the Bolts through the indicated holes in the Top Frame (9) and then through the holes in the Main Upright (1). Slide a 3/8Ó...
- Page 8 10. Attach two Bumpers (40) to the Weight Base (5) with two #8 x 1Ó Screws (78). Insert the two Weight Guides (15) through the indicated holes in the Weight Base (5). See the inset drawing. Press two Weight Inserts (77) into the indicated holes in each Weight (21).
-
Page 9: Arm Assembly
Arm Assembly 13. Press Arm AssemblyÑLocate and open the parts bag labeled ÒARM ASSEMBLY.Ó Press a 2Ó Square Inner Cap (28) into the open end of each press arm on the Press Frame (8). Press a 1Ó Round Inner Cap (58) into each of the indicated holes on the press arms. -
Page 10: Cable Assembly
17. Leg Lever Assembly. Attach a Bumper (40) to the Seat Frame (7) with a #8 x 1Ó Screw (78). Press a 2Ó Square Inner Cap (28) into the indicated end of the Leg Lever (41). Lubricate a 3/8Ó x 3Ó Bolt (53). Attach the Leg Lever (41) to the Seat Frame (7) with the 3/8Ó... - Page 11 20. Wrap the Low Cable (72) around a 3 1/2Ó Pulley (24) in the direction shown. Attach the 3 1/2Ó Pulley (24) and a Cable Trap (25) to the bracket on the Press Adjustment Frame (14) with a 3/8Ó x 3Ó Bolt (53), a 3/8Ó Flat Washer (55), a 5/8Ó x 1 1/4Ó...
- Page 12 24. Thread the bolt at the end of the Low Cable (72) a couple of turns into the Weight Tube (17). 25. Identify the High Cable (73). It is approximately 340Ó long and it has a ball on one end and a loop on the other.
- Page 13 28. Wrap the High Cable (73) around a 3 1/2Ó Pulley (24) in the direction shown and route it back down through the bracket on the Main Upright (1). Attach the 3 1/2Ó Pulley (24) inside the bracket on the Main Upright (1) with the 3/8Ó...
- Page 14 32. Wrap the High Cable (73) around a 3 1/2Ó Pulley (24) in the direction shown. Attach the 3 1/2Ó Pulley (24) to the lower half of the Small Pulley Frame (22) with a 3/8Ó x 2Ó Bolt (54) and a 3/8Ó...
- Page 15 36. Route the High Cable (73) through the slot in the leg of the Seat Frame (7). Attach the closed loop at the end of the High Cable (73) to the Leg Lever (41) with a 3/8Ó x 2 3/4Ó Bolt (47), two 3/8Ó...
-
Page 16: Seat Assembly
40. Important: Follow all three Cables from end to end and make sure they rest in the grooves of all Pulleys and that both the Cables and the Pulleys move smoothly. Attach the bolt at the end of the Low Cable (72), the 1/2Ó... -
Page 17: Miscellaneous Assembly
44. Press two 3/4Ó Round Inner Caps (43) into each Pad Tube (42). Insert one Pad Tube (42) into the Seat Frame (7). Slide a Foam Roller (30) onto each end of the Pad Tube. Insert the other Pad Tube (42) into the Leg Lever (41). - Page 18 48. The decal shown below has been attached to the home gym system in the location shown. If the decal is missing or illegible, please call our customer hotline at the number on the front cover to order a replacement decal.
-
Page 19: Cable Diagram
Cable Diagram The Cable Diagrams below show the proper routing of the Butterfly Cable (92), the High Cable (73) and the Low Cable (72). The numbers show the correct route for each Cable. Make sure the Cables are routed correctly, that the Pulleys move smoothly and that the Cable Traps do not touch or bind the Cables. -
Page 20: Adjustment
Adjustment The instructions below describe how each part of the home gym system can be adjusted. Refer to the exercise guide accompanying this manual to see how the home gym system should be set up for each exercise. IMPOR- TANT: When attaching the lat bar or ab strap, make sure that the attachments are in the correct starting position for the exercise to be performed. - Page 21 Adjusting the Press Arms Pull out on the Press Frame Knob (11) on the Press Frame (8) and pivot the press arms up or down to the desired position. Release the Press Frame Knob and let it snap into one of the adjustment holes in the cam on the Press Arm Adjustment Frame (14).
-
Page 22: Weight Resistance Chart
Adjusting the Butterfly Arms Make sure the Backrest (12) is in the horizontal position as described on the previous page. Pull out the Adjustment Knob (66) on one of the Adjustment Discs (26, 27) and pivot the Butterfly Arm (10 or 11) up or down to the desired position. -
Page 23: Trouble-Shooting And Maintenance
Trouble-shooting and Maintenance Inspect and tighten all parts each time you use the home gym system. Replace any worn parts immediately. The home gym system can be cleaned using a damp cloth and mild non-abrasive detergent. Do not use solvents. - Page 24 5/8Ó x 1/2Ó Bushing (85) 3/4" Round Inner Cap (43) 3/4Ó Retainer Ring (31) 5/8Ó x 1Ó Bushing (86) 1" Round Inner Cap (58) 1Ó Retainer Ring (32) 5/8Ó x 1 1/4Ó Bushing (91) 1/2Ó x 3/8Ó Bushing (83) 1" Round Cover Cap (81) 3/4Ó...
- Page 25 Part Identification Chart - Model No. HRSY23080 1/4" Flat Washer (71) 3/8" Flat Washer (55) 1 1/2" Flat Washer (48) 1/4" Nylon Jamnut (94) 5/16" Nylon Locknut (64) 1/2" Plain Nut (68) 3/8" Nylon Locknut (50) 3/8" Nylon Jamnut (63) #8 x 1Ó...
- Page 26 3/8" x 1 3/4" Bolt (57) 3/8" x 2" Bolt (54) 3/8" x 2 3/4" Bolt (47) 3/8" x 2 3/4" Carriage Bolt (45) 3/8" x 3" Bolt (53) 3/8" x 3 1/2" Bolt (56) 3/8" x 3 1/2" Carriage Bolt (62) 3/8"...
- Page 27 Part List - Model No. HRSY23080 Key No. Qty. Description Main Upright Weight Upright Support Upright Stabilizer Weight Base Seat Base Seat Frame Press frame Top Frame Butterfly Arm Press Frame Knob Backrest Seat Press Arm Adjustment Frame Weight Guide...
- Page 28 Exploded DrawingÑ Model No. HRSY23080 R0199A...
-
Page 29: Ordering Replacement Parts
Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be pre- pared to give the following information: 1. The MODEL NUMBER of the product (HRSY23080). 2. The NAME of the product (HEALTHRIDER 3.
