3.3 Front Panel View and Features

See the Front-Panel Features and Indicators section in the About Your System chapter of the
PowerEdge R715 Hardware Owner's Manual on

3.4 Back Panel View and Features

See the Back-Panel Features and Indicators section in the About Your System chapter of the
PowerEdge R715 Hardware Owner's Manual on

3.5 Power Supply Indicators

The PowerEdge R715 power supplies have one status bi-color LED: green for AC power present and
amber for a fault.
PowerEdge R715 Technical Guide
Front View (without Bezel)
Figure 2.
Front View (with Bezel)
Figure 3.
Support.Dell.com
Figure 4.
Support.Dell.com
for more information.
Back View
for more information.
13
