Tilt / swivel base fixing,
removing
Fixing
This product consists of the MultiSync monitor and the tilt / swivel base.
When fixing the tilt / swivel base to the MultiSync monitor, please follow
the steps below.
• Push the six hooks of the tilt / swivel base into the six holes at the
bottom of the MultiSync monitor.
• Then slide the tilt /swivel base forward.
• Then the latch above the tilt / swivel base engages it is secure.
Removing
Please removing the tilt / swivel base when transporting for repair.
• Push down the latch of the MultiSync monitor and pull out the tilt /
swivel base.
• Slide backward the tilt / swivel base from the front of the MultiSync
monitor.
• Pull out the tilt / swivel base from the holes of the MultiSync monitor.
