CHIEF MSP-DCC9000 Instruction Manual

Universal ceiling projector mount kit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
I N S T R U C T I O N
PART #MSP-DCC9000
Universal
Ceiling Projector Mount Kit
The Universal Ceiling Projector Mount provides a unique, sim-
plified method of ceiling mounting your inverted projector. This
low profile design offers three easy mounting methods (adjust-
able column, flush or threaded rod); roll, pitch and yaw adjust-
ment; a cable management system; and a universal bracket that
allows quick projector disconnect without loss of registration.
The Universal Ceiling Projector Mount is constructed of heavy
gauge steel and designed to ensure proper projector ventilation.
Fast and precise image registration is achieved through the easy
roll, pitch and yaw adjustments built into the Universal Ceiling
Projector Mount.

BEFORE YOU BEGIN

• CAUTION: To prevent damage to the Universal Ceiling Mount, which could affect or void the Factory warranty, thor-
oughly study all instructions and illustrations before you begin to install the Universal Ceiling Mount. Pay particular
attention to the "Important Precautions" on Page 1.
If a defect is discovered after Dell's initial 21 day Customer Satisfaction period, Chief Mfg. will, at its option, repair or replace
the product at no charge provided it is returned during the warranty period. Please note contact information for Chief Mfg.
listed below.
Chief Manufacturing, a division of Milestone AV Technologies
8401 Eagle Creek Parkway, Savage, MN 55378
P: 800.582.6480 / 952.894.6280 F: 877.894.6918 / 952.894.6918
M A N U A L
2008 Milestone AV Technologies
8832-000026 Rev. B
www.chiefmfg.com
11/08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MSP-DCC9000 and is the answer not in the manual?

Questions and answers

Related Manuals for CHIEF MSP-DCC9000

Summary of Contents for CHIEF MSP-DCC9000

  • Page 1: Before You Begin

    “Important Precautions” on Page 1. If a defect is discovered after Dell’s initial 21 day Customer Satisfaction period, Chief Mfg. will, at its option, repair or replace the product at no charge provided it is returned during the warranty period. Please note contact information for Chief Mfg.

  • Page 2: Table Of Contents

    Instruction Manual MSP-DCC9000 IMPORTANT WARNINGS AND CAUTIONS! WARNING: A WARNING alerts you to the possibility of serious injury or death if you do not follow the instructions. CAUTION: A CAUTION alerts you to the possibility of damage or destruction of equipment if you do not follow the cor- responding instructions.

  • Page 3: Parts & Dimensions

    Instruction Manual MSP-DCC9000 PARTS & DIMENSIONS Table 1: ITEM Nomenclature ITEM Nomenclature Ceiling Column Cable Tie 1/4”-20 Locking Nut Cable Wrap 1/4”-20 x 1 1/2” Security Bolt M3 X 12mm Button Head Security Screw 1” NPT Column M4 X 12mm Button Head Security Screw...
  • Page 4 Instruction Manual MSP-DCC9000 Acrobat Document...

  • Page 5: Inspect The Unit Before Installing

    Instruction Manual MSP-DCC9000 INSPECT THE UNIT BEFORE INSTALLING Carefully inspect the Universal Ceiling Projector Mount for shipping damage. If any damage is apparent, call your carrier claims agent and do not continue with the installation until the carrier has reviewed the damage.

  • Page 6: Universal Ceiling Projector Mount Installation Procedures

    Instruction Manual MSP-DCC9000 UNIVERSAL CEILING PROJECTOR MOUNT INSTALLATION PROCEDURES There are three common methods for installing the Universal Ceil- ing Projector Mount Series ceiling mount. The Universal Ceiling Projector Mount can be suspended from an adjustable column, stan- dard fasteners secured to a wood framing member, or threaded rods.

  • Page 7: Standard Fasteners Secured To A Wood Framing Member

    Instruction Manual MSP-DCC9000 Standard Fasteners Secured to a Wood Framing Member The Universal Ceiling Projector Mount can be secured to a wood framing member through four slotted holes in the Universal Ceiling Projector Mount using four 1/4” diameter lag screws or, if the area is accessible from above, four 1/4”...

  • Page 8: Projector Interface Plate Attachment Procedures

    Instruction Manual MSP-DCC9000 PROJECTOR INTERFACE PLATE ATTACHMENT PROCEDURES Attach the bottom portion of the universal projector mount to the projector as follows. Loosen, but do not remove, acorn nuts securing arms of the universal projector mount (see Figure 5). Adjust front and back legs to mounting points. If there are only three mounting points, remove one leg from the mount.

  • Page 9: Projector Interface Plate Installation Procedures

    Instruction Manual MSP-DCC9000 PROJECTOR INTERFACE PLATE INSTALLATION PROCEDURES The bracket attaches to the universal projector mount lifting and sliding the screws of the bracket into the slot and four vee slots of the universal projector mount (see Figure 5). Secure the bracket using provided thumb screws and route cabling as necessary.

  • Page 10: Security Installation (Optional)

    Instruction Manual MSP-DCC9000 SECURITY INSTALLATION (OPTIONAL) Using security wrench (provided), remove 5/16” standard set- screw and replace using 5/16” security screw (see Figure 8). Remove two screws from bottom of Projector Interface Plate, preferably one from each corner. Using security wrench and security screws from All-Points Security package, secure Projector Interface Plate to projector.

  • Page 11: Projector Aligmnment Instructions

    Instruction Manual MSP-DCC9000 PROJECTOR ALIGMNMENT INSTRUCTIONS The Universal Ceiling Projector Mount can be adjusted for vertical elevation (pitch), horizontal tilt (roll), and rotation (yaw). Once the desired position is located and all the screws of the Universal Ceil- ing Projector Mount are tightened, the projector may be removed from its location and replaced using the four thumb nuts without loosing the registration of the projector.
