- Page 1 Analogue Phone Link 721 User manual v2.0...
- Page 2 FUNCTION KEYS MAPPING: 11. MENU 1. UP / CALLER LIST 12. YES / REDIAL 2. DELETE 13. SPEAKER 3. NO 14. HEADSET 4. ONE TOUCH MEMORY 15. DOWN / PHONE BOOK 5. MUTE 16. HEADSET JACK 6. IN USE 17. TELEPHONE LINE 7.
-
Page 3: Wall Mounting
INSTALLATION 1. Connect the handset coil cord on the left side of the phone. 2. Connect one end of the telephone line cord to the telephone line (17 TELEPHONE LINE) and the other end to the wall socket. Make sure that the plugs are correctly matched. If there is no suitable wall outlet in the house, a plug adaptor must be added. - Page 4 Select STORE by following the steps in MENU setting, [1] The display shows: NAME, enter the name using the alphanumeric keys. If you press the wrong key, use “ ” button to correct. Press “OK” key to confirm the name. [2] Enter the phone number to store.
- Page 5 Noted: The time and date will be automatically set when the first call is received. This function depends on the support available of your local Telecom services. Menu function 8: Language selection Select LANGUAGE by following the steps in MENU setting, 1.FRENCH is shown in the LCD first.
- Page 6 Line in used & Missed call & Message LED indication Line in use: When the unit is engaged on line, the LED will light up indicating that the line is used. Missed call: When a missed call appears, it will be indicated by the icon on display.
- Page 7 View Repertory & Dial out [3] In on-hook mode, press DOWN button. Enter the first letter of the contact using the alphanumeric keyboard. Use DOWN and UP buttons to select the contact. [4] Press “OK” to call the contact. Reviewing Incoming phone number & dial out The unit can store up to 50 records of incoming caller list and each can be viewed and dialed out by the following procedures: 1.
- Page 8 Pre- fix IP Number If you always need to dial the pre-fix operator code, you can enter the pre-fix IP number first, then all the dialed out number will be automatically added to the prefix number. Set up pre-fix IP number Press *477* buttons + pre-fix IP number + # button.
- Page 9 Features sum-up DATA Port Ring tone volume Permanent memory back-up adjustable Flash adjustable In-use LED Wall mountable Headset Port Hands free Message icon Caller Name Identification 50 contacts directory Time of call displayed Presentation 50 last incoming calls Tone & Pulse Battery free ROHS compliant...
