Magnadyne MKE-300A Installation Manual

Installation Manual

Keypad Keyless
Entry System
Models:
MKE-300A and MKE-400A
For Technical Assistance call (800) 638-3600 or visit www.magnadyne.com
Transmitters
Turns On / Off Porch Light
(Can be Programmed to
Unlock Cargo Doors)
Locks All Doors Unlocks Entry
(Including Cargo) Doors
Unlocks Cargo Doors
(Can be Programmed to
Turn On / Off Porch Light)

Programming

A. 3-Button Transmitter Programming
Note: This mode will only retain the last 4 remote
transmitters programmed. If the transmitter memory
is exceeded, the security system will start deleting
transmitters from memory in chronological order.
1. Turn the ignition switch to the "ON" position.
2. Within 15 seconds, push the Program Button
(located on the back of the housing) 3 times. The
onboard LED will be flashing and the beeper will
emit a long chirp to indicate the system is in
Transmitter Programming Mode.
3. Press and hold any button on the transmitter
until the onboard LED turns on for 2 seconds and
the beeper responds with a confirming chirp, indi-
cating the signal has been stored into memory.
4. If you have additional transmitters (up to 4)
that need to be programmed, repeat step 3 for
each transmitter.
Exit: Turn the ignition switch to the "OFF" posi-
tion, or wait for 15 seconds. The onboard LED
turns off and the beeper will emit 3 long chirps to
confirm exit.
B. 4-Button Transmitter Programming
Note: This mode will only retain the last 4 remote
transmitters programmed. If the transmitter memory
is exceeded, the security system will start deleting
transmitters from memory in chronological order.
1. Turn the ignition switch to the "ON" position.
2. Within 15 seconds, push the Program Button
(located on the back of the housing) 5 times, the
onboard LED will be flashing and the beeper will
emit a long chirp to indicate the system is in
Transmitter Programming Mode.
3. Press and hold any button on the transmitter
until the onboard LED turns on for 2 seconds and
2
Press Simultaneously to
Turn On / Off Porch Light
Locks All Doors Unlocks Entry
(Including Cargo) Doors
Locks All Unlocks All
Cargo Doors Cargo Doors
the beeper responds with a confirming chirp,
indicating the signal has been stored into memory.
4. If you have additional transmitters (up to 4)
that need to be programmed, repeat step 3 for
each transmitter.
Exit: Turn the ignition switch to the "OFF" posi-
tion, or leave it for 15 seconds. The onboard LED
turns off and the beeper will emit 3 long chirps to
confirm exit.
C. Feature Programming
1. Turn the ignition switch "ON" then "OFF".
2. Within 15 seconds, push the Program Button
(located on the back of the housing) 7 times, the
onboard LED will be constantly on and the beeper
will emit a long chirp to indicate the system is in
Feature Programming Mode.
3. Press and release the transmitter button or
keypad button that corresponds to the feature
you want to change (see chart). The beeper
chirps and the onboard LED flashing will indicate
setting.
4. Continue to press and release the transmitter
button or keypad button until the beep response
matches your desired setting.
