- Page 1 (English Version) CODE FROM SERIAL NO: 005D 260000001 ISSUE 18.11.05 Hayterette CODE 005D OWNER'S HANDBOOK PART NUMBER: 111-0430 (A)
-
Page 2: Specifications
MAIN FEATURES Main Features 1. Decal - Height of Cut 2. Decal - Caution 3. Serial Number Label 4. Exhaust Guard 5. Spark Plug Lead 6. Air Cleaner 7. Fuel Filler 8. Finger Guard 9. Oil Filler Cap & Dipstick 10. - Page 3 1ST Year (12 months) We certify that this service has been carried out by an Authorised Hayter Service Dealer Date: 2nd Year (24 months) We certify that this service has been carried out by an Authorised Hayter Service Dealer Date: 1ST Year (12 months) Owner’s Name: Serial Number:...
-
Page 5: Table Of Contents
1.2 Main Features/Specifications 1.5 Contents 1.6 Introduction 1.7 Warranty 1.8 - 1.11 Safety Precautions 1.8 Safety Alert Symbol 1.8 Training 1.8 - 1.9 Preparation 1.9 - 1.10 Operation 1.10 - 1.11 Maintenance & Storage 1.11 Safety Symbols 1.11 Decal Symbols 1.12 Assembling the Mower 1.12 - Delivery Checklist... -
Page 6: Introduction
Any arbitrary modifications carried out to this machine may relieve Hayter Limited of liability for any resulting damage or injury. Hayter mowers are robustly constructed and designed for efficient economical performance under normal mowing conditions. Correct operation and maintenance will ensure a long and satisfactory service life. -
Page 7: Warranty
LIMITED WARRANTY Hayter Limited warrants to the original user/purchaser that this unit shall be free from defects in material and workmanship under normal use and service for a period of three years from the date of purchase. The manufacturer of major proprietry components ie. engines, gearbox / transaxle (where applicable) furnish their own warranty and services are provided through their authorised network. -
Page 8: 1.11 Safety Precautions
SAFETY PRECAUTIONS Safety Alert Symbol This safety alert symbol indicates important safety messages. When you see this symbol be alert to the possibility of injury. Carefully read the following and inform others. Your mower is perfectly safe if used correctly. Failure to observe the following precautions may result in serious injury. -
Page 9: Operation
SAFETY PRECAUTIONS Preparation - Always use fresh fuel. Stale fuel can block the carburettor and cause leakage. - Replace fuel tank and oil tank caps securely. A damaged cutterblade or loose fixing bolt are major hazards. Before use, always visually inspect the cutting mechanism to ensure that it is in good condition. -
Page 10: 1.11 Maintenance & Storage
SAFETY PRECAUTIONS Operation Do not tilt the mower when starting the engine. Do not put hands or feet near or under rotating parts. Never pick up or carry the mower while the engine is running. Never lift the rear deflector while the engine is running. Never touch the exhaust/exhaust guard or cooling fins when the engine is hot. -
Page 11: Safety Symbols
Maintenance & Storage Allow the engine to cool before storing in any enclosure. To reduce the fire hazard, keep the engine and the surrounding deck area free of grass, leaves, or excessive grease. Check the rear deflector and grassbag frequently for wear or deterioration. Replace worn or damaged parts for safety. -
Page 12: Assembling The Mower
ASSEMBLING THE MOWER Delivery Checklist Remove the mower from the packaging and check that the following items have been supplied correctly. If any items are missing contact, your local Hayter dealer. 1. Engine Handbook. Handlebar Unscrew the handlebar securing knobs sufficiently to allow the handle- bar to pivot. -
Page 13: Before Starting The Engine
BEFORE STARTING THE MOWER Prevent Engine Damage To prevent engine damage the engine is shipped without oil or petrol. The engine must be filled with the correct grade of oil and petrol before starting the engine. Always use high quality detergent oil classified “For service SE, SF, SG”... -
Page 14: 1.17 Operating The Mower
OPERATING THE MOWER Controls Operate all control levers several times and ensure that the cables move freely. Check that the engine stop lever returns freely to it’s rest position when released. Whilst operating the engine throttle mechanism slight resistance should be felt when moving the lever to the ‘choke’ Starting - Step 1 Move the throttle control lever to the ‘choke’... -
Page 15: Travel
OPERATING THE MOWER Forward travel: Hold and push against the handlebar with both hands to move the mower forwards. Reverse travel: Hold and pull against the handlebar with both hands to reverse the mower towards you. To make a wide turn steer the mower with the handlebar in the direc- tion required. -
Page 16: Height Of Cut
OPERATING THE MOWER Height of Cut Move the height of cut lever sideways to disengage it from the locking notch, then push forwards to lower or pull backwards to raise the height of cut. Release the lever in the required position and ensure that it locks firmly into one of the seven notch settings. -
Page 17: Heavy Growth
OPERATING Areas of heavy growth should be mown without collecting the clip- pings. If collection is required, first mow the area without the grass- bag at the maximum height of cut setting. Allow the grass clippings to dry out and then mow the area at the maximum height of cut setting with the grassbag fitted. -
Page 18: Lawn Care Calendar
LAWN CARE CALENDAR To be used as a guide only. January There is very little work to do this month apart from brushing away leaves. Keep off the grass if frozen or waterlogged. February Rake the grass thoroughly. Spike the lawn to aerate and stimulate soil organisms and root growth and apply lawn sand if necessary. -
Page 19: Lawn Care
LAWN CARE CALENDAR August Keep mowing regularly and watering as necessary. Fill any cracks caused by drought with a mixture of sharp sand and soil. In dry weath- er conditions leave the grass longer to help retain ground moisture. September Raise the height of cut to allow the grass to thicken and protect the roots from the winter frost and snow. -
Page 20: Maintenance Schedule
MAINTENANCE SCHEDULE To prevent accidents stop the engine disconnect the spark plug lead before attempting to carry out maintenance procedures on the mower. Follow the hourly or calendar intervals, whichever occurs first. More frequent service will be required if working for prolonged periods under dusty, dry conditions, or when airborne debris is present or after extensive operation cutting tall, dry grass. -
Page 21: Mower Maintenance
50Hrs or Every Season Clean the engine cooling system. Clean more often under dusty conditions or when airborne debris is present or after prolonged operation whilst cutting tall, dry grass. Replace the spark plug. Finger Guard Carburettor Spark Plug / Lead Exhaust Guard Exhaust Oil filler Cap/ Dipstick... -
Page 22: Oil Service
MOWER MAINTENANCE Oil Service Check the oil level daily before starting the engine and ensure that the correct oil level is maintained. Refer to-‘Before Starting the Mower’ for oil checking and filling instructions. Change the engine oil after the first 5 hours of operation and thereafter according to the ‘Maintenance Schedule’:- Air Cleaner Service To service the air cleaner, loosen screw (1) and remove cover (2). -
Page 23: Spark Plug Service
MOWER MAINTENANCE Spark Plug Service Use only Briggs & Stratton spark tester (1) to check for a spark as shown in the diagram. Replace the spark plug every 100 hours or every season, whichever occurs first. A spark plug wrench is available from any authorised Briggs &... -
Page 24: Deck Housing
MOWER MAINTENANCE Deck Housing Remove grass debris from the top and underside of the deck housing immediately after use. To prevent accidents fertilisers and top dressings are particularly corrosive. Thoroughly clean the mower deck immediately after use on treated grass and store well away from corrosive materials. Securing Nuts &... -
Page 25: Cutterblade Removal
Cutterblade Removal WARNING - PREVENT ACCIDENTS: Never work on the cut- terblades unless the spark plug lead has been removed. The cut- terblades have sharp edges. ALWAYS wear strong gloves to pro- tect your hands when working on the cutterblades. DO NOT rotate tools towards the cutting edges to avoid the risk of injury should the tool slip. -
Page 26: Storage
MOWER MAINTENANCE Storage To store the handlebar unscrew the 2 small securing knobs sufficient- ly to allow it to be pivoted forwards to rest against the mower. Take care to ensure that the control cables do not become snagged at the pivot point and depress the engine stop lever to prevent it being dam- aged through contact with the engine spark plug. -
Page 27: Trouble Shooting
PROBLEM Engine will not turn over Engine smokes Engine runs then stops Engine will not start Engine runs rough TROUBLE SHOOTING POSSIBLE FAULT Engine stop lever released Incorrect oil level Obstruction under deck Excess oil level Air cleaner plugged Fuel starvation Fuel cap vent blocked Engine under load Fuel starvation... - Page 28 TROUBLE SHOOTING PROBLEM Engine vibrates excessively Uneven cut Mower is hard to push 1.28 POSSIBLE FAULT Mounting bolts loose Cutterblade bolt loose Cutterblades out of balance Engine crankshaft bent Undulating ground conditions Cutterblades worn Cutterblades out of balance Wheels damaged Cut height too low Wheels damaged REMEDY...
-
Page 29: Declaration Of Conformity
DECLARATION EC DECLARATION OF CONFORMITY Manufacturer: HAYTER LIMITED, Address: Spellbrook, Bishop’s Stortford, Herts. CM23 4BU. ENGLAND declare that the lawnmower: Model name: Type: Model No: Cutting width: Speed of rotation of the cutting device: Engine manufacturer: Speed of rotation of engine: Complies with the provisions of Directive: 98/37/EC Essential Health &... -
Page 30: Parts List
PARTS LIST NO. DESCRIPTION Pin - Pivot Washer - 19mm Nylon Lever - Engine Screw - 6mm x 20 Bottom Plate Handlebar - Upper Guide - Rope Throttle Control & Cable Screw - M5 x 35mm Taptite Cable - Engine Brake Tie - Cable Handwheel - Triangular Bolt - M8 x 45 Handlebar... - Page 31 NO. DESCRIPTION Handle Grip - Black Rivet Hub Cap Plug - Tube 7/8” Washer - 3/8” Spring S/C Screw - 3/8” UNF x 1” Long Nut - 3/8” UNF Nyloc Key - Woodruff Decal - Hayter Decal - Height of Cut Decal - Caution Decal - Serial No.
- Page 32 PARTS LIST 1.32 1C005D02A 21 32...
- Page 33 NOTES Notes:- 1.33...
- Page 34 NOTES Notes:- 1.34...
- Page 35 NOTES Notes:- 1.35...
-
Page 36: Customer Information
CUSTOMER INFORMATION Serial No: Engine Type:- 12F802-1325-01 Date of Sale:- Your Local Dealer:- 1.36 Engine:- Briggs & Stratton Quantum XTS 50...
