Page 1: User Manual
User Manual EtherUSB™ USB Ethernet Access Point for PDA V 2.0 Clarinet Systems, Inc. Clarinet Systems, Inc. http://www.clarinetsys.com Page 1... - Page 2 01/16/2007 Copyright Copyright 2006 - 2008 Clarinet Systems, Inc. All rights reserved. Information in this document is subject to change without notice. No part of this publication may be transmitted, transcribed, reproduced, stored in any retrieval system or translated into...
-
Page 3: Table Of Contents
APPENDIX A – QUICK START GUIDE ...............................11 APPENDIX B – CE5.0, CE.NET 4.1/4.2, AND PPC 2003/2003SE PDA .....................15 B.1 I PDA ................................15 NSTALLATION ON THE B.2 C ............................15 OMMUNICATIONS WITH THE ERVER B.3 A ..................................15 CCESS NTERNET Clarinet Systems, Inc. http://www.clarinetsys.com Page 3... -
Page 4: Product Overview
1 PRODUCT OVERVIEW The EtherUSB™ EA104 is a USB Ethernet Access Point for connecting PDA and PDA phone using Pocket PC 2003/2003SE operating systems (OS), CE5.0, CE.NET4.1/4.2 and Windows Mobile 5.0 and Windows Mobile 6.0 to an Ethernet network. Connection is established using a PDA USB cradle or with USB cables via the PDA USB port to10/100 Base-T Ethernet network. - Page 5 500mA power provided to each USB port enables recharging of PDAs while connected. Clarinet Systems, Inc. http://www.clarinetsys.com Page 5...
-
Page 6: Hardware Installation
1. Four Ethernet RJ45 and four USB female connectors. 2. One DC power connector. 3. One Reset button: press and hold the Reset Button for 8 seconds or longer, to reset EA104 to factory default and then reboot. Clarinet Systems, Inc. http://www.clarinetsys.com Page 6... -
Page 7: Hardware Installation
EA104 when there is a PDA performing data communications since this may cause data to be lost. Notes: * In a non-DHCP environment, the system administrator must set up an enclosed DHCP network by accessing the EA104 configuration using the browser-based AdminTool. Clarinet Systems, Inc. http://www.clarinetsys.com Page 7... -
Page 8: Configuration
Update firmware 3.3 Access AdminTool and change EA104 initial values Please refer to EtherUSB Admin Tool User Manual for information on access and modify EA104 configuration. Factory default can be restored by pushing the Reset Button for 8 seconds or longer. -
Page 9: Specifications And Provisions
Regulation: UL and <PS>E for Japanese version only 4.4 Safety and EMI certificate • CE and FCC – B • VCCI (application in process) www.clarinetsys.com Note: Please check the Data Sheet on for updated product information. Clarinet Systems, Inc. http://www.clarinetsys.com Page 9... -
Page 10: Functions And Compatibility
CE5.0; Pocket PC 2003/2003SE, Windows CE.NET4.1/4.2, and Windows Mobile 5.0 and 6.0 PDA and PDA phone. 5.1.6 Communications Procedures • EtherUSB will be recognized as an Access Point on the network • Once the PDA is connected, the PDA will be recognized as a network terminal •... -
Page 11: Appendix A - Quick Start Guide
Reset Button for eight seconds or longer. A.2. PDA connections Now connect your USB PDA devices to the available USB ports on the back of the unit. Clarinet Systems, Inc. http://www.clarinetsys.com Page 11... - Page 12 EA104 has four USB host ports that simultaneously connect up to four PDAs through their USB ports to an Ethernet network. Each connected PDA can perform server synchronization, Internet browsing, and file transfer. A.3. Clarinet Systems DevFinder (optional) Download “Clarinet Systems DevFinder” from http://www.clarinetsys.com and launch the DevFinder application to locate the EA104 device and find its IP address.
- Page 13 You will be presented with a Login Screen. The default User name and Password are admin/password. Click “OK” to continue. Once the correct username and password have been entered, you should see a status screen like this. Clarinet Systems, Inc. http://www.clarinetsys.com Page 13...
- Page 14 The status screen will display system information such as IP address and EtherUSB device identification. Please refer to EtherUSB AdminTool User Manual for details. Clarinet Systems, Inc. http://www.clarinetsys.com Page 14...
-
Page 15: Appendix B - Ce5.0, Ce.net 4.1/4.2, And Ppc 2003/2003Se Pda
APPENDIX B – CE5.0, CE.NET 4.1/4.2, AND PPC 2003/2003SE PDA B.1 Installation on the PDA None B.2 Communications with the Server TCP/IP and UDP B.3 Access Internet Built-in browser on PDA Clarinet Systems, Inc. http://www.clarinetsys.com Page 15...
