Clarinet Systems EtherUSB EA104 User Manual

Usb ethernet access point for pda
Hide thumbs Also See for EtherUSB EA104:
Table of Contents

Advertisement

Quick Links

User Manual

EtherUSB™
USB Ethernet Access Point for PDA
V 1.6
Clarinet Systems, Inc.
Clarinet Systems, Inc.
//www.clarinetsys.com
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EtherUSB EA104 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Clarinet Systems EtherUSB EA104

Summary of Contents for Clarinet Systems EtherUSB EA104

  • Page 1: User Manual

    User Manual EtherUSB™ USB Ethernet Access Point for PDA V 1.6 Clarinet Systems, Inc. Clarinet Systems, Inc. //www.clarinetsys.com Page 1...
  • Page 2 1/16/07 Copyright Copyright 2006 Clarinet Systems, Inc. All rights reserved. Information in this document is subject to change without notice. No part of this publication may be transmitted, transcribed, reproduced, stored in any retrieval system or translated into any language or computer language in any form or by any means, mechanical, electronic, optical, chemical, manual or otherwise, without the prior written permission of Clarinet Systems, Inc., 44040...

  • Page 3: Table Of Contents

    5.1.2 Network protocols ...10 5.1.3 Network connection side...10 5.1.4 PDA connection side...10 5.1.5 PDA Compatibility...10 5.1.6 Communications Procedures...10 5.2 EA104 F ...10 IRMWARE VERSION 5.2.1 v02.00.00 ...10 APPENDIX A – QUICK START GUIDE ...11 APPENDIX B – WINDOW MOBILE 5.0 DEVICE...15 APPENDIX C –...

  • Page 4: Product Overview

    Base-T Ethernet network. EA104 belongs to EtherUSB™ product line. EA104 is equipped with 4 USB host ports and four 10/100 Base-T ports, one for uplink to the Ethernet network and three for optional connection of PC or computing devices. EA104 provides TCP/IP-based network connectivity for up to 4 PDA devices simultaneously using a PDA USB cradle or USB cables and the server side 10/100 Base-T network.

  • Page 5: Hardware Installation

    2. 180cm (6’) Ethernet cable 3. 5VDC/3A power adapter, 2.1x5.5mm plug, center positive polarity 4. A paper notice that indicates the website from which to download the EA104 Users Manual (this manual), Data Sheet and about WM5.0 device connection. 2.1 Status LED, port, and button of EA104 main unit 2.1.1 External Status LED...

  • Page 6: Hardware Installation

    2. Connect PDA to the EA104 USB port**. 3. Connect the power adapter to rear socket of the EA104, then into the wall outlet. If power is present, the EA104 will proceed with normal power on sequence - self test and boot up sequence within 25 seconds;...

  • Page 7: Configuration

    User name: admin Password: password If the network contains a WINS server, you may use the device name of the EA104 in place of the IP address. That is http://<device name>:9876/. For example: http://EA4000100:9876. All fields will be overwritten when restoring factory defaults by pushing the Reset Button for 8 seconds or longer.
  • Page 8 The Default Factory Setting is as follow: Device Name: <Serial Number> Domain Name: IP Mode: DHCP IP Group: 193.168.10.0 User ID: Admin Password: Password Please refer to EtherUSB AdminTool User Manual for details. Clarinet Systems, Inc. //www.clarinetsys.com Page 8...

  • Page 9: Specifications And Provisions

    Regulation: UL and <PS>E for Japanese version only 4.4 Safety and EMI certificate • CE and FCC – B • VCCI (application in process) Note: Please check the Data Sheet on //www.clarinetsys.com for updated product information. Clarinet Systems, Inc. //www.clarinetsys.com 6” x 3.5” x 1” Page 9...

  • Page 10: Functions And Compatibility

    Once the PDA is connected, the PDA will be recognized as a network terminal • All configurations are done via HTTP using a browser on PC 5.2 EA104 Firmware version 5.2.1 v02.00.00 • For the current Firmware Version, please check http://www.clarinetsys.com Clarinet Systems, Inc.

  • Page 11: Appendix A - Quick Start Guide

    1. Connections Connect the Ethernet cable into the 10/100 uplink port (WAN) on the rear of the EA104. Connect the Ethernet cable into your switch or hub. Connect the power cord to the back of the unit and plug the power supply into the wall socket or AC power source.
  • Page 12 EA104 has four USB host ports that simultaneously connect up to four PDAs through their USB ports to an Ethernet network. Each connected PDA can perform server synchronization, Internet browsing, and file transfer. 3. Clarinet Systems DevFinder (optional) Download “Clarinet Systems DevFinder” from http://www.clarinetsys.com...
  • Page 13 URL area and then press enter. If the network contains a WINS server, you may use the serial number of the EA104 in place of the IP address. That is http://<serial number>:9876/. For example: http://EA4000100:9876.
  • Page 14 The status screen will display system information such as IP address and EtherUSB device identification. Please refer to EtherUSB AdminTool User Manual for details. Clarinet Systems, Inc. //www.clarinetsys.com Page 14...

  • Page 15: Appendix B - Window Mobile 5.0 Device

    3. Once you download and install the firmware and/or application, the ActiveSync Mode Switcher can be found at Start->Setting->Connections. B) Use Clarinet Systems’ “EtherUSB Client” application to enable multiple WM5.0 connections to EA104. (You will only need to do this once for each device.) EtherUSB Client offers the following functions for WM5.0 devices:...
  • Page 16 Drag and drop the EtherUSB_Installer.cab file to My Documents folder on the PDA. Go to the PDA and launch File Explorer under Start menu. Go to My Documents folder and click on EtherUSB_Installer.cab file to install the application on your PDA. Clarinet Systems, Inc. //www.clarinetsys.com Page 16...
  • Page 17 3. Select one Client ID from 49 choices (under normal conditions, each device should be assigned one unique Client ID). (Fig 3 & 4.) 4. Apply Setting so the device can now connect to EA104 along with other WM5.0 devices simultaneously.
  • Page 18 Client ID. Otherwise, connection time varies from 10 to 40 seconds. Note 1: When a WM5.0 device is plugged into the EA104, port the USB LED will flash. LED flashing means the connection process is on-going. Important: During LED flashing, the user should not unplug a mobile device from the USB port unless it takes more than 40 seconds.

  • Page 19: Clarinet Systems, Inc. //Www.clarinetsys.com

    APPENDIX C – CE5.0, CE.NET 4.1/4.2, AND PPC 2003/2003SE PDA Installation on the PDA None Communications with the Server TCP/IP and UDP Access Internet Built-in browser on PDA Clarinet Systems, Inc. //www.clarinetsys.com Page 19...
