Summary of Contents for Clarinet Systems ESB1000
- Page 2 Note: The (ESB301) comes equipped with an additional Ethernet port for user PC. IMPORTANT NOTE: The single port (ESB101), (ESB1000), (ESB3011B), (ESB301) and Multiport (ESB208/216) are shipped with DHCP enabled. If you connect to a non DHCP network you will experi- ence connection difficulties.
- Page 3 The (ESB208/216) The multiport (ESB208) comes equipped with: • 8 Infrared ports • 8 Ethernet pass-through ports (See Section 3 for more pass-through information) The multiport (ESB216) comes equipped with: • 16 Infrared ports • 16 Ethernet pass-through ports (See Section 3 for more pass-through information) EthIR Beam with RJ45 connector Power cable RJ45 patch cable to connect the EthIR Beam to the EthIR Switch...
- Page 4 Section 2 The (ESB101, ESB301,ESB1000, ESB3011b and the ESB208/216) are all DHCP enabled. Insure a DHCP server is up and running on the network before uplinking. If there is no DHCP server on the network then do not uplink. You will have to configure the Switch first, before uplinking to the network.
- Page 5 EthIR Switch front view RJ45 cable RJ45 wall jack EthIR Beam B: Housed in the network equipment closet. These switches can be placed in the wiring closet to provide either Infrared or Ethernet connectivity to the existing wall jacks. Position Switch in wall rack. Connect the incoming RJ45 cable from each office or cubicle wall jack to one of the bottom infrared ports on the Switch.
- Page 6 For Further Information Contact: Clarinet Systems, Inc. email: sales@clarinetsys.com 44040 Fremont Blvd. support@clarinetsys.com Fremont, CA 94538 www.clarinetsys.com For updated information on Clarinet Systems products, contacts and FAQ’s please visit our web site at www.clarinetsys.com © 2003 Clarinet Systems, Inc. All Rights Reserved 11/02...
