- Page 1 EthIR LAN™ User Guide - ESB5001 and ESB5004 Infrared Ethernet Access Point for mobile device V 1.7 Clarinet Systems, Inc.
- Page 2 Copyright Copyright 2007 Clarinet Systems, Inc. All rights reserved. Information in this document is subject to change without notice. No part of this publication may be transmitted, transcribed, reproduced, stored in any retrieval system or translated into any language or computer language in any form or by any means, mechanical, electronic, optical, chemical, manual or otherwise, without the prior written permission of Clarinet Systems, Inc., 48834...
-
Page 3: Table Of Contents
APPENDIX B – CONFIGURING POCKET PC ...12 PPC PDA ...12 CE5.0 PDA...12 WM5.0 PDA ...13 WM5.0 S ...13 MART HONE APPENDIX C – CONFIGURING PALM ...14 PDA ...14 Clarinet Systems, Inc. Table of Contents ESB5001/5004 ...2 ) ...5 DMIN ES5001/5004 ...5 INITIAL VALUES ...8 //www.clarinetsys.com... -
Page 4: Product Overview
TCP/IP network protocol. ESB5001/5004 belongs to the EthIR LAN product line which contains single port ESB101/301/3011b/1000 and multi-port ESB208/216/608 early models. ESB5001 is equipped with one USB IR ports, while ESB5004 is equipped with four USB IR ports, and two 10/100 Base-T one for uplink and one for PC. -
Page 5: Hardware Installation
2. 120cm (4’) Ethernet cable 3. 5VDC/2A power adapter, 2.1x5.5mm plug, center positive polarity 4. A paper slip that indicates the website from which to download ESB5001 Users Manual (this manual), Quick Start Guide, and Data Sheet As for ESB5004 Please contact Clarinet Systems for the availability of ESB5004 product.) -
Page 6: Hardware Installation
ES5001/5004 when there is a PDA performing data communications since this may cause data to be lost. Note * In non-DHCP environment, the system administrator has to set up an enclosed DHCP network to access ES5001/5004 configuration via administration tool. Clarinet Systems, Inc. //www.clarinetsys.com Page 3... - Page 7 ESB5004 system configuration Clarinet Systems, Inc. //www.clarinetsys.com Page 4...
-
Page 8: Based A Dministration T Ool (A Dmin T Ool )
IP address. All fields will be overwritten when restoring factory default by pushing the Reset Button for 8 seconds or longer. The Default Factory Setting is as follow: Clarinet Systems, Inc. (Note syntax: http://<IP address><colon>9876/ ) //www.clarinetsys.com Page 5... - Page 9 Device Name: <Serial Number> Domain Name: IP Mode: DHCP IP Group: 193.168.10.0 User ID: Admin Password: Password Please refer to EtherUSB AdminTool User Manual Clarinet Systems, Inc. for details. //www.clarinetsys.com Page 6...
-
Page 10: Specifications And Provisions
• VCCI (application in process) Note: Please check the Data Sheet on //www.clarinetsys.com to get updated info. Clarinet Systems, Inc. Weight in kg & in oz 0.5kg; 18 oz 1.85” x 0.7” x 0.35” 0.006kg;0.2 oz (include 4’ USB cable) 0.8kg;... -
Page 11: Functions And Compatibility
Data transmission speed: Max 12M (USB1.1 is currently enabled although USB2.0 capable) 5.1.5 PDA Compatibility Windows Mobile 5.0, Windows Mobile for Pocket PC 2003/2003SE, Windows CE.NET4.1/4.2, CE5.0, Palm and Psion 5.2 Software Architecture Overview 5.2.1 Linnux OS 5.2.2 Firmware Version Firmware version: please check http://www.clarinetsys.com Clarinet Systems, Inc. //www.clarinetsys.com Page 8... -
Page 12: Appendix A - Quick Start Guide
APPENDIX A – QUICK START GUIDE This guide shows you how to quickly connect the ESB5001/5004 to your network and to PDA devices with IR port. Included in this box are: • ES5001 or ES5004 EthIR Switch • EB5000DT or EB5000WM EthIR Beam •... - Page 13 ES5004 has four USB host ports that simultaneously connect up to four PDAs through EB5000 to an Ethernet network. Each connected PDA can perform server synchronization, Internet browsing, and file transfer. 3. Clarinet Systems DevFinder (optional) Download “Clarinet Systems DevFinder” from http://www.clarinetsys.com...
- Page 14 “OK” to continue. Once the correct username and password have been entered, you should see a status screen like this. The status screen will display system information such as IP address and EtherUSB device identification. Please refer to EtherUSB AdminTool User Manual for details. Clarinet Systems, Inc. That is http://<device name>:9876/. For For example: http://192.168.101.91:9876 //www.clarinetsys.com...
-
Page 15: B.2 Ce5.0 Pda
“Disconnect”, wait for ~3 seconds then remove PDA Please refer to your user manual on how to setup Generic IrDA Modem connection. CE5.0 PDA Please refer to your user manual on how to setup Generic IrDA Modem connection. Clarinet Systems, Inc. //www.clarinetsys.com Page 12... -
Page 16: B.3 Wm5.0 Pda
“Disconnect”, wait for ~3 seconds then remove PDA Please refer to your user manual on how to setup Generic IrDA Modem connection. WM5.0 Smart Phone Please refer to your user manual on how to setup Generic IrDA Modem connection. Clarinet Systems, Inc. //www.clarinetsys.com Page 13... -
Page 17: C.1 Palm Pda
APPENDIX C – CONFIGURING PALM Palm PDA Please refer to your user manual on how to setup network connection base on IR. Clarinet Systems, Inc. //www.clarinetsys.com Page 14...
