Secure the drive

NOTE: The server latches and side views of your server model may not be exactly the same as
shown in the illustrations. Please refer also to you server documentation.

Mounting hardware used (HP ProLiant)

Ensure that you use the correct mounting rails or locating screws, as described in
hardware" on page 13. The server also incorporates a locking mechanism to hold the tape drive in
place.
1. Push the server latch down to lock the tape drive into position, as shown in
Figure 11 Securing drive, mounting hardware used
1
1
2
2. Ensure blanking plates are in place over empty bays and replace the cover on the server.
2
plastic rail
server latch
HP StorageWorks DAT Tape Drives User Guide
"Attach mounting
Figure 11.
21
