V50D
ELECTRIC GUITAR AMPLIFIER WITH DIGITAL DELAY
AND CHORUS
User's Manual
R
Velocity is a registered trademark of GHS Corporation Battle Creek MI, USA
May be covered by one or more of the following: U.S. Patents #4538297, 4647876, 4696044, 4745309, 4881047, 4893099,
5124657, 5263091, 5268527, 5319713, 5333201, 5402498 and 5493617.
Other patents pending. Foreign patents pending.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rocktron Velocity V50D
Summary of Contents for Rocktron Velocity V50D
- Page 1 V50D ELECTRIC GUITAR AMPLIFIER WITH DIGITAL DELAY AND CHORUS User’s Manual Velocity is a registered trademark of GHS Corporation Battle Creek MI, USA May be covered by one or more of the following: U.S. Patents #4538297, 4647876, 4696044, 4745309, 4881047, 4893099, 5124657, 5263091, 5268527, 5319713, 5333201, 5402498 and 5493617.
- Page 2 Your Rocktron Velocity V50D amplifier has been designed to comply with the following Standards and Directives as set forth by the European Union: Council Directive(s): 89/336/EEC, 73/23/EEC, 76/769/EC, 1994/62/EC, 2000/ 53/EC, 2002/95/EC Standard(s): EN55022, EN50082-1, EN60065 This means that this product has been designed to meet stringent guidelines on how much RF energy it can emit, and that it should be immune from other sources of interference when properly used.
- Page 3 Precautions NOTE: IT IS VERY IMPORTANT THAT YOU READ THIS SECTION TO PROVIDE YEARS OF TROUBLE FREE USE. THIS UNIT REQUIRES CAREFUL HANDLING. • All warnings on this equipment and in the operating instructions should be adhered to and all operating instructions should be followed. •...
-
Page 4: Front Panel Descriptions
FRONT PANEL DESCRIPTIONS INPUT JACKS HIGH INPUT jack This is a high impedence input jack. Connect the output of your guitar to the 1/4” input jack with a shielded guitar cable. Use this jack if you want a little more “edge” to your input. Note use only the High or the Low input, not both at the same time. -
Page 5: Equalization Controls
EQUALIZATION CONTROLS BASS control This knob controls the overall bass of both the CLEAN and DISTORTION channels. The BASS control boosts or cuts the amount of low frequencies, or bass sound in the signal. MIDDLE control This knob controls the overall MIDDLE frequencies of both the CLEAN and DISTORTION channels. The MIDDLE control boosts or cuts the amount of mid-band frequencies present in the signal. -
Page 6: Back Panel Descriptions
CLEAN and DISTORTION channels. FOOTSWITCH Input RFS2 Using a ROCKTRON RFS2 footswitch and a stereo cord (both sold separately) you can turn both the CHORUS and DELAY effects ON and OFF. * Rocktron Rampage single (RFS1) and double (RFS2) footswitches are available and sold... - Page 7 V50D Specifications Power Output 50 Watts (2x25) Speakers 2 x 8” Custom Voiced Velocity Speakers by Rocktron Treble Active Shelving Middle Active Bandpass Bass Active Shelving Presence Active Shelving Outputs: Line Two 1/4” jacks Speaker Two 1/4” jacks Headphone Output One 1/4”...
-
Page 8: Fuse Replacement
Fuse Replacement We recommend that you use an authorized repair person to change the fuse in this unit. To access the fuse, first power down the unit and unplug the cable from the wall outlet and the amplifier. Using a small screw driver, open the fuse tray by prying open the small tab as shown in the drawing above. Please note that the tray will not come all of the way out. - Page 9 V50D ELECTRIC GUITAR AMPLIFIER WITH DIGITAL DELAY AND CHORUS Rocktron -A Division of GHS Corporation 2813 Wilber Avenue Battle Creek MI 49015 Rocktron Phone: 1-(269)-968-3351 Email: info@rocktron.com Check us out on the web at: www.rocktron.com 2006-0001 Rev. 8/01/06...
