Swisher LV87537 Ower's Manual

Swisher LV87537 Ower's Manual

Wand adaptor kit sold separately. part number 5473
Hide thumbs
Table of Contents

Advertisement

Quick Links

swisherinc.com
OWNER'S
MANUAL
STARTING SERIAL #:
L106-001001
MODEL NO.
LV87537
IMPORTANT
Read and follow all Safety
Precautions and Instructions
before operating this
equipment.
Rev. 06-289
1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093
Manufacturing quality lawn care equipment since 1945
12945
LAWN VACUUM
Wand Adaptor Kit sold
separately. Part Number 5473
Assembly
Operation
Service and Adjustment

Repair Parts

FAX 660-747-8650
PHONE 660-747-8183
Made In The
USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LV87537 and is the answer not in the manual?

Questions and answers

Related Manuals for Swisher LV87537

Summary of Contents for Swisher LV87537

  • Page 1: Repair Parts

    OWNER’S MANUAL STARTING SERIAL #: L106-001001 MODEL NO. LV87537 LAWN VACUUM Wand Adaptor Kit sold separately. Part Number 5473 IMPORTANT Read and follow all Safety Assembly Precautions and Instructions before operating this Operation equipment. Service and Adjustment Rev. 06-289...

  • Page 2: Limited Warranty

    1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed.

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. This machine can amputate hands, feet, and throw objects.

  • Page 4: Safety And Operational Decals

    Do not fill the lawn vacuum to its full capacity without checking the towing capacities of the tow vehicle. SAFETY AND OPERATIONAL DECALS Replace decal immediately if damaged. Order by part number from Swisher Mower and Machine Co. Inc. OD55-TRIANGLE DANGER DECAL OD70142-DANGER STOP ENGINE...

  • Page 5: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Remove outside crate and set parts aside. Remove small components and identify each piece. Raise front hitch, using caution to prevent latch from being bent. (Figure 1) Latch hitch to wagon. Align holes in frame and install 3/8-16X1” Hex Head bolt and lock nuts. Tighten all four of the hitch bolts securely.
  • Page 6 Be careful while lifting, not to bend latch. Install 4 bolts and nuts. Insert tongue and pin. Figure 2 Move components off of pallet and identify. Bag adapter fits into bag and over blower Figure 1 tube. Assemble frame into corner holes.
  • Page 7 OPERATING YOUR LAWN VACUUM The operation of any mower can produce foreign objects to be thrown into the eyes, resulting in severe eye damage. Always wear certified safety glasses or wide-vision safety goggles over spectacles before starting any cutting machine and while operating such a machine.
  • Page 8 CHANGING CONDITIONS ON SLOPES. DO NOT OVER FILL CART. TWO – IN – ONE APPLICATION Your Swisher Lawn Vacuum has been designed to perform two capabilities in one product. While you are not using your Lawn Vacuum to sweep up leaves and grass clippings the engine assembly, fabric cover and upper frame may be disassembled to leave you with a utility trailer.

  • Page 9: Vacuum Maintenance

    ATTENTION: GRASS CATCHER COMPONENTS ARE SUBJECT TO WEAR, DAMAGE, AND DETERIORATION, WHICH COULD EXPOSE MOVING PARTS OR ALLOW OBJECTS TO BE THROWN. FREQUENTLY CHECK COMPONENTS AND REPLACE WITH SWISHER’S RECOMMENDED PARTS, WHEN NECESSARY. STORAGE • Clean the vacuum. • Before storing be sure Lawn Vacuum is thoroughly dried, especially the fabric covering.

  • Page 11: Service Parts

    SERVICE PARTS Please have Model and Serial Numbers ready when ordering parts. Color cannot be guaranteed upon service parts ITEM NUMBER DESCRIPTION PART NUMBER MOTORBASE 5443TK BAG FRAME WELDMENT 5412TK TRAILER 5400TC REAR FRAME SECTION 5437TK FRONT FRAME SECTION 5433TK LATCH 5439TK LATCH LOCK...
  • Page 12 All Lawn Vacuum parts listed herein may be ordered directly MODEL NO. from Swisher Mower & Machine Co. Inc., your nearest Swisher dealer, or from our website. www.swisherinc.com LV87537 All engine parts may be ordered from the nearest dealer of the...
