Swisher 2644 PALLET LIFTER Manual

Atv accessories

Download this manual

2643

2646

2644

2645

Made In The

USA

2801

REV. 05-010

Need help?

Do you have a question about the 2644 PALLET LIFTER and is the answer not in the manual?

Page 1 2643 2646 2644 2645 Made In The 2801 REV. 05-010...
Page 2: Limited Warranty
LIMITED WARRANTY...
Page 4: Safety Precautions
SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. Failure to observe the following safety instructions could result in serious injury or death.
Page 5 SECURE THE FORK ARMS(4) WITH THE SAFETY HITCH PINS(5). PLACE THE FORK LIFT KIT IN FRONT OF THE ALREADY INSTALLED SWISHER ACCESSORY MOUNT. INSERT THE MOUNT PIN(2) INTO THE FORK LIFT ADAPTER(1) AND THROUGH THE ACCESSORY MOUNT. ATTACH YOUR WINCH TO THE EYELET AT THE TOP OF THE...
Page 6 FIGURE 3 ITEM NO. QTY. PART NO. DESCRIPTION 5525TK FORK LIFT ADAPTER 2660TK MOUNT PIN NB506 3/16 CLICK PIN 5535TK FORK ARM WELDMENT SAFETY HITCH PIN...
Page 7 USE YOUR WINCH TO RAISE AND LOWER THE SKID LIFTER. DO NOT LET THE SKID LIFTER DRAG WHILE OPERATING. WHEN MOVING PALLETS, OPERATE THE SKID LIFTER AT SLOW SPEEDS TO AVOID ACCIDENTS. WATCH OUT FOR ANGLED SURFACES ON WHICH THE SKID LIFTER COULD GET STUCK OR STICK INTO!!

Skid lift 2644
