Table 4-2 OSD Menu (continued)
Icon
20 Chapter 4 Operating the Monitor
Main Menu Submenu
Monitor Status
DDC/CI Support
Bezel Power LED
Sleep Timer
Language
Information
Current Settings
Recommended
Settings
Serial Number
FW Version
Backlight Hours
Service Support
Factory Reset
Description
Displays the operating status of the monitor each
time the monitor is powered on. Select the location to
display the status to:
●
Top
●
Middle
●
Bottom
●
Off
The factory default is Top.
Allows the computer to control some OSD menu
features such as brightness, contrast and color
temperature. Set to:
●
On
●
Off
The factory default is On.
Turns off the power LED on the front panel of the
monitor. The factory default is On.
Provides the timer adjustment menu options:
●
Set Current Time—sets the current time in
hours and minutes
●
Set Sleep Time—sets the time you want to
place the monitor in sleep mode
●
Set on Time—sets the time you want the
monitor to wake up from sleep mode
●
Timer—sets the Sleep Timer feature On or Off.
The default setting is Off
●
Sleep Now—immediately sets the monitor to
enter sleep mode
Selects the language in which the OSD menu is
displayed. The factory default is English.
Selects and displays important information about the
monitor.
Provides the current input video mode.
Provides the recommended resolution mode and
refresh rate for the monitor.
Reports the serial number of the monitor. The serial
number is needed if contacting HP technical support.
Reports the firmware version of the monitor.
Reports the total hours of backlight operation.
http://www.hp.com/support
Returns all OSD menu settings and DDC/CI controls
to the factory default settings, except the Language.
