NEC MultiSync LCD1550VM User Manual page 16

7. This LCD monitor is designed for use with a flexible arm. Please use
the attached screws (4pcs) when mounting. To meet the safety
requirements the monitor must be mounted to an arm which
guaranties the necessary stability under consideration of the weight
of the monitor. The LCD monitor shall only be used with an approved
arm (e.g. GS mark).
4 SCREWS
(MAX depth: 8.6 mm)
If use other screw,
check depth of hole.
01b_English
Replace screws
75 mm
75 mm
Weight of LCD assembly: 3.5kg (MAX)
English-8
8
Thickness of bracket (arm)
2.0 ~ 3.2 mm
Tighten all screws
