American Standard Easy Touch 6310SSEZ Specification Sheet

GENERAL DESCRIPTION:

Metal body, handle, and escutcheon plate. Swivel pull-out
spray spout. Adjustable spray pattern with push button
activation. Washerless 47mm ceramic disc valve cartridge
with integral hot limit safety stop.
hoses with 3/8" compression connections. Brass mounting
shank with brass fixation ring. Complete with two integral
check valves. 2.2 gpm/8.3L/min. maximum flow rate. Fitting
can be mounted with or without escutcheon plate (escutcheon
size 10"L x 2-3/4"W).
SUGGESTED SPECIFICATION:
Single control kitchen pull-out faucet shall feature a swivel pull-out spray spout with two check valves, WhisperGlide™ hose,
metal escutcheon plate and handle. Shall also feature washerless ceramic disc valve cartridge with integral hot limit safety stop
and flexible supply hoses. Faucet shall be American Standard Model # 6310SSEZ.
© 2008 AS America, Inc.
35 to 38mm
(1-3/8 to 1-1/2)
DIA. MOUNTING
HOLE
508mm
(20)
Braided flexible supply
HD-65
SINGLE CONTROL KITCHEN FAUCET
MODEL NUMBER:
6310SSEZ Kitchen Faucet with Pull-out Spray
Escutcheon plate (use is optional).
Stainless Steel (PVD) finish.
232mm
(9-1/8)
127mm
(5)
224mm
(8-7/8)
57mm(2-1/4)
with escutcheon
76mm(3)
less escutcheon
254mm
(10)

PRODUCT FEATURES:

Oversize Button:
Switches water flow from stream to spray
with just a touch.
Durable WhisperGlide Hose:
Easy to Install:
Flexible supply hoses are factory-installed
for fast hook-up.
Ideal for Granite and Other Solid Surfaces:
without deck plate for single hole installation
Ceramic Disc Valve Cartridge:
smooth handle operation and drip-free performance
Adjustable Hot Limit Safety Stop:
hot water allowed to mix with cold to reduce the risk of
accidental scalding
Lifetime Warranty:
On function & finish
EASY TOUCH
WITH PULL-OUT SPRAY
207mm
(8-1/8)
150mm
(6)
For smooth, quite operation.
Mounts
Provides a lifetime of
Limits the amount of
