American Standard SELECTRONIC 606B2 Series Installation Instructions Manual

American Standard SELECTRONIC 606B2 Series Installation Instructions Manual

Concealed toilet flush valve 1.1. 1.28 & 1.6 gpf, exposed back spud/concealed back spud/top spud
Hide thumbs

Advertisement

Quick Links

Download this manual
SELECTRONIC
CONCEALED TOILET FLUSH VALVE
1.1. 1.28 & 1.6 GPF
Certified to comply with ASME A112.19.2
© 2017 AS America, Inc.
NOTE TO INSTALLER: Please give this manual to the customer after installation.
To learn more about American Standard Selectronic
or e-mail us at: CRTTEAM@americanstandard.com
For Parts, Service, Warranty or other Assistance,
please call (844) CRT-TEAM / (844) 278-8326 (In Canada: 1-800-387-0369)
© 2017 AS America Inc.
®
Exposed Back Spud
(In Toronto Area only: 1-905-306-1093)
Concealed Back Spud
CAUTION: Use only American Standard supplied
transformers and cable sets. Using non-AS supplied
cables, or cutting, splicing or modifying any components
will void the warranty.
Products visit our website at: www.americanstandard-us.com
®
1
MODEL NUMBERS
606B2XX
Top Spud
M965640 Rev. 1.4 (11/17)

Advertisement

loading
Need help?

Need help?

Do you have a question about the SELECTRONIC 606B2 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for American Standard SELECTRONIC 606B2 Series

Summary of Contents for American Standard SELECTRONIC 606B2 Series

  • Page 1 Certified to comply with ASME A112.19.2 © 2017 AS America, Inc. NOTE TO INSTALLER: Please give this manual to the customer after installation. To learn more about American Standard Selectronic Products visit our website at: www.americanstandard-us.com ® or e-mail us at: CRTTEAM@americanstandard.com...
  • Page 2 Thank you for selecting American-Standard...the benchmark of fine quality for over 100 years. To ensure that your installation proceeds smoothly--please read these instructions carefully before you begin. All American Standard Products Are Water Tested At Our Factory. UNPACKING Some Residual Water May Remain In The Valve During Shipping.

  • Page 3: General Description

    Top Spud Fixtures WALL 160mm 127mm X 127mm (6-1/4) (5X5 CUTOUT FOR BOX) CAUTION: Use only American Standard DETECTION ZONE supplied transformers and cable sets. 400mm-800mm Using non-AS supplied cables, or cutting, (Factory Setting: 400mm) 160mm splicing or modifying any components will...
  • Page 4 Fig.3 (TOP SPUD FIXTURE ILLUSTRATED) FLUSH VALVE INSTALLATION 127mm INSTALL ELECTRICAL BOX; Fig. 3 127mm 1. Cut a 127x127mm (5"x 5") opening in finished wall for ELECTRICAL BOX (1) at the dimension shown. 2. Rotate the 4 MOUNTING TABS (2) flat against the T O P electrical box.
  • Page 5 INSTALL VACUUM BREAKER AND Fig. 6 FLUSH CONNECTIONS; Fig. 6 1. Place the SPUD FLANGE (1) over the spud on the Fixture. Fig. 6. 1-1/2" TOP SPUD 2. Place FRICTION WASHER (3) and SEAL WASHER (4) inside SPUD COUPLING NUT (2) and thread onto Spud. Do not tighten fully.
  • Page 6 INSTALL FLASH VALVE; Fig. 7 Fig. 7 Insert the side ADJUSTABLE TAILPIECE (1) on the FLUSH VALVE (2) into the STOP VALVE (3). Lubricate the TAILPIECE O-RING (4) with water if necessary. Thread the COUPLING NUT (5) onto the STOP VALVE (3) and tighten lightly.

  • Page 7: Electrical Installation

    ELECTRICAL INSTALLATION Fig. 9 T O P STANDARD BATTERY POWER KIT (PK00.CRP); Fig. 9, 10 1. Attach the SAFETY CHAIN (1) from the COVER PLATE (2) to the MOUNTING POST (3) as shown. Fig. 9. 2. Connect one end of the 27" EXTENSION CABLE (1) to SENSOR CABLE (2).
  • Page 8 5. Place Y-ADAPTERS (3) into respective electrical box. 6. Plug in AC power supply into wall outlet once all daisy-chain unit connections have been made. CAUTION: Use only American Standard supplied transformers and cable sets. Using non-AS supplied cables, or cutting, splicing or modifying any components will void the warranty.
  • Page 9 INSTALL COVER PLATE; Fig. 12 Fig. 12 Install the two TABS (1) on the back side of COVER PLATE (2) into the two SLOTS (3) located on the top edge of the ELECTRICAL BOX (4). Push on the bottom edge of the COVER PLATE (2) until it snaps into place.

  • Page 10: Maintenance

    MAINTENANCE Fig. 14 INSTALL NEW BATTERY; Fig. 14 1. Remove the COVER PLATE (1). For removing front panel instructions, see Step 10. 2. Remove old BATTERY (2) from BATTERY HOLDER (4). Install the new BATTERY (3), making sure the shape of the BATTERY (2) follows the shape of the BATTERY HOLDER (4).
  • Page 11 SET DETECTION RANGE (if required); Fig. 16 & 17 Fig. 16 Note: The detection distance is preset and ideal for most installations. Should an adjustment be required, follow the steps below. 1. Remove COVER PLATE (1). See Step 10 for front panel removal instructions.

  • Page 12: Troubleshooting Flowcharts

    Product n ames liste d h ere in are t r ademar ks of AS Amer ica , In c. ©2 01 7 CLOSE ANGLE STOP AND OPEN AGAIN TO PRIME THE VALVE. To learn more about American Standard Selectronic® Products visit our website at: DOES FLUSHING STOP? www.americanstandard-us.com or e-mail us at: CRTTEAM@americanstandard.com...
