4.2 Overview

Overview of the control elements
12
11
10
9
3 8
2 4 6 7
5
1. Color-buttons für SELECT-COLOR MODE
2. PAUSE FUNCTION button
3. SELECT-COLOR MODE Button
4. PROGRAM SELECT MODE Button
5. PROGRAM SELECT channel fader
6. SPEED channel fader
7. FLASH FREQUENCY/SENSITIVITY channel fader
8. Microphone
9. BLACKOUT- Button
10. SOUND CONTROL Button
11. AUTO Button
12. R G B Buttons
Rear panel:
13
14
13. DMX Out
14. DC Input
11/14 00041883.DOC, Version 1.1
