en | Navigating the Monitor
6.2
Using the Monitor On-screen Display
(OSD)
The LCD is programmed through the on-screen display (OSD)
menus and submenus where an operator can select operating
parameters. To access the OSD menus, press the Menu button
on the control panel. Use these controls to make any necessary
adjustments to the OSD.
NOTICE!
When you are navigating through the OSD menus, use the
SOURCE or ENTER button to select a menu and use the MENU
button to exit a menu.
To navigate the set up menus, follow the steps below:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10. Press the Menu button again to exit the OSD menu bar.
F.01U.272.027 | 1.0 | 2012.08
Connect a video source cable to the monitor.
Press the Power button to turn on the unit.
If required, press the SOURCE or ENTER button and then
the and the
and
Press the Menu button to activate the main menu
selections.
Press the
and
Press the
button to enter the selected menu.
Press the
and
Press the
and
Press the Menu button to exit the selected menu and to
return to the menu bar or to confirm a selection.
User's Manual
buttons until a signal is displayed.
buttons to select a menu.
buttons to select a sub-menu item.
buttons to toggle the OSD values.
Bosch HD LCD Monitors
Bosch Security Systems, Inc.
