Shure UNF Wireless system Manual page 16

UT1 BODY-PACK TRANSMITTER SPECIFICATIONS
RF Output
Input Configuration
Connector Type
Actual Impedance
Connector Pin
Assignments
Dimensions
Net Weight
Power Requirements 9 V alkaline battery (Duracell MN1604 recommended);
Nominal Current Drain 40 mA
UT2 HAND-HELD TRANSMITTER SPECIFICATIONS
RF Output
Dimensions
Net Weight
Power Requirement
Nominal Current Drain
UT4 RECEIVER SPECIFICATIONS
Connector
Maximum Output Levels
Nominal Output Levels
Output Configuration
Actual Impedance
Connector Pin
Assignments
Dimensions
Net Weight
Power Requirements
Power Supply
Voltage/Current/Phan-
tom Power Protection
15 mW Typical
Unbalanced
4-pin Miniature connector (male), TB4M
1 M
Pin 1: Ground
Pin 2: +5 V Bias
Pin 3: Audio In
Pin 4: 20k Resistor to Audio Ground
82.6 mm H x 63.5 mm W x 26.2 mm D
(3.25" H x 2.50" W x 1.03" D)
125g (4.4 oz.) including battery
V lithium ULTRALIFE battery optional.
UT2/58 (SM58 )
15 mW Typical
241 mm H x 51 mm D
(9.49" H x 2.01" D)
296g (10.4 oz.)
9 V alkaline battery (Duracell MN1604 recommended);
9 V lithium ULTRALIFE battery optional.
40 mA
3-Pin XLR
(male)
Line Level: +10 dBV
Mic Level: –22 dBV
Line Level: –26 dBV
Mic Level: –62 dBV
Active Balanced
Line Level: 138
Mic Level: 500
Pin 1: ground
Pin 2: hot
Pin 3: cold
41 mm H x 197 mm W x 138 mm D
(1.625" H x 7.77" W x 5.42" D)
419.6g (14.8 oz.)
12–18 Vdc nominal, 200mA
120 V or 230V ac adaptor with 2.1 mm female plug
Yes
15
ENGLISH
UT2/(BETA58 )
241.3 mm H x 36.83 mm D
(9.5" H x 1.45" D)
296g (10.4 oz.)
1/4" phone plug
+4 dBV
–32 dBV
Unbalanced
1 k
Tip: hot
Sleeve: ground
Yes
9
(female)
