HASSELBLAD
HC 3.5-4.5/50-110
GENERAL LENS DATA:
Focal length
Aperture range
Angle of view diag/hor/vert
Length/diameter
Weight
Filter diameter
CLOSE FOCUS RANGE DATA:
Minimum distance object to film
Maximum image scale
Corresponding area of coverage
Corresponding exposure reduction
COMPATIBILITY
The HC3,5-4,5/50-110 mm lens is not compatible with the converter 1.7x.
LENS DESIGN
14 elements in 9 groups
FOCUS TYPE
Front focusing
ENTRANCE PUPIL POSITION
50 mm setting:
164 mm
80 mm setting:
161 mm
110 mm setting: 173 mm
In front of the film plane
(at infinite focus setting)
The entrance pupil position is the
correct position of the axis of rota-
tion when making a panorama image
by combining individual images of a
scene.
51.5 (108.3) mm
3.5 (4.5) - 32
69°/58°/46° (35°/29°/22°)
152 mm/103 mm
1650 g
95 mm
0.70 m
1:10.8 (1:5.2)
60 x 45 (29 x 21) cm
0 f-stop
50 mm
80 mm
110 mm
LENSES
1/3
www.hasselblad.com
Advertisement
Related Manuals for Hasselblad HC 3.5-4.5/50-110
Summary of Contents for Hasselblad HC 3.5-4.5/50-110
- Page 1 HASSELBLAD HC 3.5-4.5/50-110 GENERAL LENS DATA: Focal length Aperture range Angle of view diag/hor/vert Length/diameter Weight Filter diameter CLOSE FOCUS RANGE DATA: Minimum distance object to film Maximum image scale Corresponding area of coverage Corresponding exposure reduction COMPATIBILITY The HC3,5-4,5/50-110 mm lens is not compatible with the converter 1.7x.
