HASSELBLAD
HCD 4/28
the HCD 28mm lens has been designed to be compact and
to deliver optimal performance when used with the 48x36mm
sensor of the Hasselblad H3D. Image quality from the
Hasselblad H3D is refined with integral use of Digital APo
Correction which perfects the raw image by digitally removing
any color aberration and distortion. the resulting raw images
have perfect pixel definition optimal for image rendering.

GENERAL LENS DAtA

Focal length
Aperture range
Angle of view diag/hor/vert
Length/diameter
Weight (incl. covers and lens shade)
Filter diameter

CLoSE FoCuS RANGE DAtA

Minimum distance object to film
Maximum image scale
Corresponding area of coverage
Corresponding exposure reduction

CoMPAtIBILItY

• The HCD 4/28 mm is designed for use on the Hasselblad H3D and the H2F camera.
• The HCD 4/28 mm lens is designed solely for digital use. This means that the lens is designed
for a format of 37x49 mm and does not cover the film format (41.5x56mm).
the function is therefor disabled when using a film magazine.
• The HCD 4/28 mm lens is not compatible with the converter 1.7x.

LENS DESIGN

12 elements in 9 groups

FoCuS tYPE

Rear focusing

ENtRANCE PuPIL PoSItIoN

134 mm in front of the sensor plane
(at infinite focus setting)
the entrance pupil position is the correct
position of the axis of rotation when making
a panorama image by combining individual
images of a scene.
28.9 mm
4 - 32
95°/83°/66°
102 mm/100 mm
850 g
95 mm
0.35 m
1:7.3
36 x 27 cm
0 f-stop
LENSES
