Swissvoice ePure TAM User Manual

Cordless analogue telephone (dect) with digital answering machine
Hide thumbs Also See for ePure TAM:
Table of Contents

Advertisement

Quick Links

See also: User Manual
ePure TAM
Cordless analogue telephone (DECT)
WITH DIGITAL ANSWERING MACHINE
User manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ePure TAM and is the answer not in the manual?

Questions and answers

Related Manuals for Swissvoice ePure TAM

Summary of Contents for Swissvoice ePure TAM

  • Page 1 TAM Cordless analogue telephone (DECT) WITH DIGITAL ANSWERING MACHINE User manual...

  • Page 2: Welcome To Swissvoice

    TAM Welcome to Swissvoice The ePure TAM is a cordless telephone designed for connection to an analog telephone network. International DECT (GAP)-standard digital technology offers excellent voice quality. You can register up to 5 handsets to your base and make internal calls free of charge.

  • Page 3: Table Of Contents

    Set date and time Set language Telephoning Keypad lock Redial PBX operation Paging – Locate mislaid handsets Phonebook Direct memory Calls list Extending the ePure TAM Telephoning with several call partners Personal settings Advanced settings Answer machine Appendix ePure TAM...

  • Page 4: Keys

    TAM Keys Handset Earpiece Display Redial key Menu key End call key / back to idle mode Talk key Key 1: Insert a space Digit keys Star key In standby: Long press to activate/ deactivate the keypad lock. Key 0: Press and hold for Internal...

  • Page 5: Display Symbols

    TAM Display symbols Steady on: batterie’s charge level. Flashing: batteries have to be charged. 14/01 12:03 Date and time. Call in progress. Steady on : the caller’s list is open. Flashing : new calls in the caller’s list. The phonebook is open.

  • Page 6: Battery Advice

    TAM Battery advice Use only the original battery (Li-Ion 3.7 V / 550 mAh) as well as the original power sup- ply (6.5 V DC 300mA, 7.5 V 200mA). The handset operating times (standby 150 hours/active 10 hours) and charging times apply only if the battery is charged to the defined minimum capacity.

  • Page 7: Connecting The Phone

    TAM Connecting the phone Telephone line socket Mains power socket • Before you can start using your telephone you must plug in the telephone connector cable and the mains cable. • When the phone is delivered, the battery is not yet charged.

  • Page 8: Telephoning

    TAM Telephoning • Dial the desired number using the keypad. • Press the Talk key End the call Press the End call key. Accepting a call • Incoming calls are signalled by a ring tone and a quick flashing of the control LED on the handset.

  • Page 9: Keypad Lock

    TAM Set speaker/loudspeaker volume You can adjust the speaker/loudspeaker volume during a conversation. π/† Set the desired volume using the navigation key Switch handset off • Press and hold the End call key (approx. 5 sec). • Press and hold again the End call key to reactivate the handset.

  • Page 10: Pbx Operation

    TAM • Press the Talk key. Edit redial list Open the Redial list, press OK. • You have the following options: - Save Number – Add number to the phonebook. - Delete entry – Delete the entry. - Delete All – Delete the entire redial list.

  • Page 11: Direct Memory

    TAM Add new entries in the phonebook , select Phonebook and press OK. • Press Select New entry and press OK. • π/† • Enter the desired name and press the navigation key for further input options. • Press OK to save the entry.

  • Page 12: Calls List

    You can register up to 5 handsets to your base station. If you register your ePure TAM handset with a "third party" base station or a "third party" handset on your ePure TAM base station (GAP), you may not be able to use some functions or only to a limited extent.
  • Page 13 • Press and hold down the Paging key for at Press • The ePure TAM may now ask for the PIN. If so, enter the PIN (default 0000) and least 10 seconds press OK. • Press OK again to confirm.

  • Page 14: Telephoning With Several Call Partners

    TAM Telephoning with several call partners During a call you can make a second internal call (enquiry call), switch between call partners (brokering) or simultaneously converse (3-way conference call) without the need for two telephone lines. Internal conversation / Internal call •...

  • Page 15: Personal Settings

    TAM Personal settings , select Personal set and press OK. • Press π/† • Select a function from the list using the navigation key and press OK. - Handset tone - Ring volume - Ring melody - Group melody - Key tone - Every time a key is pressed, a brief beep is heard.
  • Page 16 TAM menu, enter the PIN code (0000 on delivery). Select the sub-menu Number and enter the desired call number. Then select the sub-menu Mode and activate the function. Baby call on is displayed. To deactivate the baby call: . Baby call on off? is displayed. Press OK.

  • Page 17: Answer Machine

    TAM Answer machine Your ePure TAM features an integrated digital answer machine with a max. recording capacity of 30 minutes. You can operate your answer machine from the base and from any handset registered to the base. On delivery an outgoing message for each mode (Answer &...
  • Page 18 TAM π/† Select On or Off using the navigation keys • and press OK. is displayed when the answer machine is switched on. • You must now select the desired operating mode and record a personal outgoing message: Record a personal outgoing message , select Answ Machine and press OK.
  • Page 19 TAM Delete – delete a message during playback • Save number – save the number in the phonebook • π/† Press the navigation key , to adjust the playback volume. Delete all old messages (from the handset) , select Answ Machine and press OK.
  • Page 20 TAM Memory full The recording capacity of your answer machine is 30 minutes (including outgoing messages). If the memory is full, Memory full appears on the handset display. No more messages can be recorded. The answer machine switches to Answer only mode automatically.

  • Page 21: Appendix

    If this happens, please check the ePure TAM on an analog fixed line and/or contact your Internet/cable telephony provider. Care Your telephone is a sophisticated product in terms of design and construction, and should therefore be handled with care.
  • Page 22 Im Frauental 14 92224 Amberg. The Swissvoice Service Center will replace it with and equivalent good or perform a repair. In the case of components subject to wear (e. g. batteries) this period lasts for 6 months from the date of purchase.
  • Page 23 The declaration of conformity may be viewed at: www.swissvoice.net. The CE symbol confirms the conformity of the telephone with the above directive.
  • Page 24 TAM ePure TAM...
  • Page 25 TAM ePure TAM...
  • Page 26 TAM ePure TAM...

  • Page 27: Warranty Certificate

    Warranty Certificate Warranty Certificate Garantieschein, Bon de garantie, Certificato di garanzia, Garantiebewijs, Takuutodistus, Garantibevis, Garantisedel, Garantibevis, Certificado de Garantía, Talão de garantia device type: (Gerätetyp, type d’appareil, tipo di apparecchio, toesteltype, laitetyyppi, maskintype, apparattyp, apparattype, modelo del aparato, modelo do aparelho): serial number: (Seriennummer, numéro de série, numero di serie, serienummer, sarjanumero, serienummer, serienummer, serienummer, número de serie, número de série):...
  • Page 28 Internet: www.swissvoice.net © Swissvoice SA 2012 20406419en_ba_a0 SV 20406419...
