Summary of Contents for Pulsar V657
- Page 1 CAL. V657 CHRONOGRAPH TIME/CALENDAR Hour, minute and second hands Date displayed in numerals CHRONOGRAPH Measures up to 60 minutes in 1/10 second increments. Split time measurement...
- Page 2 DISPLAY AND CROWN/BUTTONS CHRONOGRAPH 1/10-second hand Hour hand Minute hand CHRONOGRAPH CROWN minute hand Date Second hand CHRONOGRAPH second hand a: Normal position b: First click c: Second click...
- Page 3 SCREW DOWN CROWN [for models with screw down crown] Unlocking the crown 1 Turn Crown counterclockwise until you no longer feel the threads turning. 2 Crown can be pulled out. Locking the crown 1 Push Crown back in to normal position. 2 Turn Crown clockwise while pressing it lightly until tight.
- Page 4 ADJUSTING CHRONOGRAPH HAND POSITION Before setting the time, be sure to check that the CHRONOGRAPH hands are in “0” position when the chronograph is reset. (For resetting the chronograph, see “CHRONOGRAPH” on page 6) * If any of the CHRONOGRAPH hands do not return to “0” position, follow the procedure below to reset the hands.
-
Page 5: Time/Calendar Setting
TIME/CALENDAR SETTING CROWN 1 Pull out to first click, and turn clockwise until the previous day’s date appears. 2 Pull out to second click when Second hand is at the 12 o’clock position. 3 Turn clockwise until the desired date appears. 4 Turn to set Hour and Minute hands. - Page 6 CHRONOGRAPH CHRONOGRAPH Start / Stop / Restart 1/10-second hand CHRONOGRAPH minute hand Reset / CHRONOGRAPH Split /Split release second hand Ex.: 15 minutes and 10.6 seconds After the measurement exceeds 1 minute, the CHRONOGRAPH 1/10- second hand stays at “0” position. When the measurement is stopped, it will move to indicate the elapsed 1/10 seconds.
- Page 7 TACHYMETER [for models with tachymeter scale on the dial] To measure the hourly average speed of a vehicle Ex. 1 1 Use the stopwatch to determine how many seconds it takes to go Tachymeter scale: “90” 1 km or 1 mile. 2 Locate the second marker on the CHRONOGRAPH main dial that corresponds to the...
- Page 8 tachymeter scale: “90” (tachymeter scale figure) x 2 (km or mile) = 180 km/h or mph “90” (tachymeter scale figure) x 0.5 (km or mile) = 45 km/h or mph To measure the hourly rate of operation Ex. 1 1 Use the stopwatch to measure the time required to complete 1 job.
-
Page 9: Notes On Operating The Watch
NOTES ON OPERATING THE WATCH ADJUSTING CHRONOGRAPH HAND POSITION The “0” position of the CHRONOGRAPH 1/10-second hand differs depending on the models. * Some models have the “0” position of the CHRONOGRAPH 1/10-second hand at 3 and 9 o’clock sides of the small dial. In that case, check if the hand is level with its both ends pointing to those “0”... - Page 10 While the crown is at the second click, do not press the buttons. Otherwise, the CHRONOGRAPH hands will move. To reset them to “0” position, see “ADJUSTING CHRONOGRAPH HAND POSITION” on page 4. CHRONOGRAPH While the chronograph is counting, do not pull out the crown to set the time. Otherwise, the chronograph operation cannot be made.
-
Page 11: Battery Change
When the battery expires, be sure to replace it as soon as possible to prevent any malfunction. We recommend that you contact an AUTHORIZED PULSAR DEALER for battery replacement. - Page 12 Necessary procedure after battery change After the battery is replaced with a new one, or in case any of the hands should move improperly, follow the procedure below to reset the hands to “0” position. CROWN Pull out to second click. Press and hold at the same time for 2 seconds.
- Page 13 WARNING Do not remove the battery from the watch. If it is necessary to take out the battery, keep it out of the reach of children. If a child swallows it, consult a doctor immediately. Never short-circuit, tamper with or heat the battery, and never expose it to fire.
-
Page 14: To Preserve The Quality Of Your Watch
WATER RESISTANCE Non-water resistant • If the watch becomes wet, have it checked by an AUTHORIZED PULSAR DEALER or SERVICE CENTER. Water resistant 5/10/15/20 bar • Before using in water, be sure the crown is pushed in completely. • Do not operate the crown and buttons when the watch is wet or in water. - Page 15 Care should also be taken on diving into water. ** We recommend that you wear a PULSAR Diver’s Watch for scuba diving. MAGNETISM TEMPERATURES...
-
Page 16: Periodic Check
2 to 3 years. Have Years watch or hit it against hard your watch checked by an surfaces, as this may AUTHORIZED PULSAR cause damage. DEALER or SERVICE CENTER to ensure that the case, crown, buttons, gasket and crystal seal remain intact.
