Pulsar V658 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TIME
Hour, minute and second hands
CHRONOGRAPH
Measures up to 60 minutes in 1/10 second increments.
Split time measurement
CAL. V658
CHRONOGRAPH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V658 and is the answer not in the manual?

Questions and answers

Related Manuals for Pulsar V658

Summary of Contents for Pulsar V658

  • Page 1 CAL. V658 CHRONOGRAPH TIME Hour, minute and second hands CHRONOGRAPH Measures up to 60 minutes in 1/10 second increments. Split time measurement...
  • Page 2 DISPLAY AND CROWN/BUTTONS CHRONOGRAPH 1/10-second hand Hour hand Minute hand 1/10 SEC. CHRONOGRAPH M I N . minute hand CROWN SEC. Second hand CHRONOGRAPH second hand b: Extended position a: Normal position...

  • Page 3: Screw Down Crown

    SCREW DOWN CROWN [for models with screw down crown] Unlocking the crown 1 Turn Crown counterclockwise until you no longer feel the threads turning. 2 Crown can be pulled out. Locking the crown 1 Push Crown back in to normal position. 2 Turn Crown clockwise while pressing it lightly until tight.
  • Page 4 ADJUSTING CHRONOGRAPH HAND POSITION Before setting the time, be sure to check that the CHRONOGRAPH hands are in “0” position when the chronograph is reset. (For resetting the chronograph, see “CHRONOGRAPH” on page 6) * If any of the CHRONOGRAPH hands do not return to “0” position, follow the procedure below to reset the hands.

  • Page 5: Time Setting

    TIME SETTING 1/10 SEC. M I N . SEC. CROWN 1 Pull out when Second hand is at the 12 o’clock position. 2 Turn to set Hour and Minute hands. 3 Push back in to normal position in accordance with a time signal.
  • Page 6 CHRONOGRAPH Start / Stop / Restart CHRONOGRAPH 1/10-second hand 1/10 SEC. M I N . CHRONOGRAPH minute hand SEC. CHRONOGRAPH Reset / second hand Split /Split release Ex.: 15 minutes and 10.6 seconds After the measurement exceeds 1 minute, the CHRONOGRAPH 1/10- second hand stays at “0”...
  • Page 7 TACHYMETER [for models with tachymeter scale on the dial] To measure the hourly average speed of a vehicle Ex. 1 1 U s e t h e c h r o n o g r a p h t o determine how many seconds it Tachymeter 1/10...
  • Page 8 tachymeter scale: “90” (tachymeter scale figure) x 2 (km or mile) = 180 km/h or mph “90” (tachymeter scale figure) x 0.5 (km or mile) = 45 km/h or mph To measure the hourly rate of operation Ex. 1 1 Use the chronograph to measure the time required to complete 1 job.

  • Page 9: Notes On Operating The Watch

    NOTES ON OPERATING THE WATCH ADJUSTING CHRONOGRAPH HAND POSITION The “0” position of the CHRONOGRAPH 1/10-second hand differs depending on the models. * Some models have the “0” position of the CHRONOGRAPH 1/10-second hand at 3 and 9 o’clock sides of the small dial. In that case, check if the hand is level with its both ends pointing to those “0”...

  • Page 10: Battery Change

    The CHRONOGRAPH 1/10-second scale and hand differ in design and shape depending on the models. * Some models have the CHRONOGRAPH 1/10-second scale graduated on the upper half of the small dial and the hand which is so designed that both ends can indicate the elapsed 1/10 second.
  • Page 11 We recommend that you contact an AUTHORIZED PULSAR DEALER for battery replacement. Necessary procedure after battery change After the battery is replaced with a new one, or in case any of the hands should move improperly, follow the procedure below to reset the hands to “0” position.
  • Page 12 P u s h b a c k i n t o n o r m a l CROWN position. * The CHRONOGRAPH second hand turns half a circle counterclockwise and then returns where it was. The CHRONOGRAPH 1/10-second hand turns a full circle clockwise and stops.

  • Page 13: To Preserve The Quality Of Your Watch

    WATER RESISTANCE Non-water resistant • If the watch becomes wet, have it checked by an AUTHORIZED PULSAR DEALER or SERVICE CENTER. Water resistant 5/10/15/20 bar • Before using in water, be sure the crown is pushed in completely. • Do not operate the crown and buttons when the watch is wet or in water.
  • Page 14 Care should also be taken on diving into water. ** We recommend that you wear a PULSAR Diver’s Watch for scuba diving. MAGNETISM TEMPERATURES...

  • Page 15: Periodic Check

    2 to 3 years. Have Years watch or hit it against hard your watch checked by an surfaces, as this may AUTHORIZED PULSAR cause damage. DEALER or SERVICE CENTER to ensure that the case, crown, buttons, gasket and crystal seal remain intact.
