- Page 1 NORMA gebRAUchsANWeisUNg bRUgsANVisNiNg MANUeL D’UTiLisATiON OPeRATiNg MANUAL isTRUziONi D’UsO > gebRUiKsAANWiJziNg bRUKsANVisNiNg...
- Page 2 iMPORTANT cOMPONeNTs connection flue/ chimney WARm AiR outlet (convection) pRimARy AiR inlet WindoW pAne fiRe heARth hAndle de-Ashing mechAnism (behind chARging dooR) Ash pAn (behind chARging dooR) chARging dooR gAsket AdJustAble feet 1. LeggeRe DAPPRiMA Le iNsTRUziONi D’UsO. 1. ReAD The OPeRATiNg MANUAL FiRsT. 2.
- Page 3 Zibro heating pro- duct. please carefully read this manual first and store it for future reference.
-
Page 4: Safety Instructions
• This heater must be installed by a by Zibro authorized heating and installa- tion engineer. the warranty can only be effective when it is installed by a by Zibro agreed professional. the instructions for use given in this manual may vary from local and/or regional legislation. - Page 5 • The surface of the stove can become very hot when in use. NEVER leave child- ren unattended with the stove. children should be supervised to ensure they do not play with the stove. • This stove is not intended for use by person (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
-
Page 6: First Start-Up
TiPs FOR Use: • make sure the stove and its exhaust pipe and chimney flue is easily acces- sible from all sides. • Start up at low heating capacity when the stove is first used (refer to Chap- ter c) b. - Page 7 D. NORMAL OPeRATiON OF The sTOVe to start the stove: fully open the charging door and the primary inlet valve (see picture 2) by sliding the valve to “+”. place and lit some crumpled paper or fire lighter sticks (fire starter sticks) in the fire bed together with some small size dry fire wood (for fuel requi- rements: see chapter d.3) do not use liquid fuel, such as for example alcohol, petrol, gasoline etc to...
- Page 8 D.1.2 incorrect burning stove how can an incorrect burning stove be recognized: • smothery flames • extensive smoke production • soot covering the window pane D.2 ReFiLLiNg The sTOVe how can an incorrect burning stove be recognized: • shake the bottomgrate bars using the stove tool provided (see picture 3). •...
-
Page 9: Maintenance
e. MAiNTeNANce the heat, ash and residue produced by the combustion of the fire wood makes regular cleaning and maintenance by both the end user as well as an authorized technician necessary. periodically carefully cleaning the stove is important for safe- ty, efficient operation and -in the same time- increasing the life time of the stove. - Page 10 e.2 MAiNTeNANce TO be DONe by AUThORizeD TechNiciAN Task Frequency professional inspection and maintenan- twice per season, first time at begin- ce of stove (& flue system) ning of season cleaning/sweeping the chimney/flue twice per season, first time at begin- system ning of season replacing parts not mentioned in this...
- Page 11 At least twice per year, before the heating season starts, check the fire bed for fractures. the parts are made of cast iron which can break with high temperature shocks or when it drops on the floor. have it replaced by a by Zibro authorized technician if needed. only use original Zibro spare parts.
-
Page 12: Troubleshooting
Zibro agreed spare parts. using non Zibro spare parts will lead to nul- lification of the warranty. g. TROUbLe shOOTiNg... -
Page 13: Warranty Provisions
8. stove is installed by a by Zibro agreed installer and the commissioning protocol can be presented. in order to avoid unnecessary costs, we recommend that you always carefully read this manual first. -
Page 14: Technical Data
Recirculation fan Air filter net weight (*) According to en 13240 (**) for indication only, varies per country/region for your convenience you can download the latest version of the user-, installation- and/or service manual on www.zibro.com/download. -
Page 15: Declaration Of Conformity
That the following products comply with the appropriate basic safety and health requirements of the EC Directives based on its design and type: Product Description: Roomheaters fired by solid fuel Brand of Product: Zibro Reference of Product: norma Applicable EC Directives: ec construction products directive 89/106/eec Applicable Harmonized Standards: en 13240:2001... - Page 16 +32 3 326 39 39 tel: +39 571 628 500 fax: +32 3 326 26 39 fax: +39 571 628 504 email: pvgbelgium@zibro.com email: pvgitaly@zibro.com q SCHWEIZ u NORGE pvg schweiz Ag Appliance A/s salinenstrasse 63 gefionsvej 7 4133 pRAtteln dk-3400 hilleRød...
