Figure 2 and Table 2 define the underside of the VP-210xl:
Figure 2: VP-210xl XGA Line Amplifier (Underside)
Table 2: VP-210xl XGA Line Amplifier (Underside) Features
# Feature
1 ID Bit Switch
2
75
TERM /
Hi-Z
Switches
1 The default. Enabling the notebook or laptop to output a VGA signal to an external VGA monitor
2 To the LOOP 15-pin HD (F) connector
Your VP-210xl XGA Line Amplifier
Slide up to set to ON
BLUE
Slide up to set to 75 TERM (when a local monitor is not
GREEN
used); down to set to Hi-Z (when a local monitor is
2
RED connected )
Function
1
; down to set to OFF
5
