Overview

The high performance VP-210xl is a line amplifier for XGA
graphics signals that provides controls to compensate for signal losses
inherent in long cable runs.
In particular, the VP-210xl XGA Line Amplifier features:
Video bandwidth of 500MHz, ensuring that it remains transparent
for all resolutions
HDTV compatibility
Separate controls for output level and cable equalization, ID Bit
control, and independent input signal termination for red, green
and blue
A looping input
To achieve the best performance:
Use only good quality connection cables
deterioration in signal quality due to poor matching, and elevated
noise levels (often associated with low quality cables).
Avoid interference from neighboring electrical appliances that
may adversely influence signal quality and position your Kramer
VP-210xl away from moisture, excessive sunlight and dust
1 The terminology XGA is used throughout this manual, where this implies any RGBHV signal on an 15-pin HD (F)
connector having a resolution from VGA up to UXGA
2 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com
3 For example, part number 22535-000251
Overview
Caution
– No operator-serviceable parts inside unit.
Warning
– Use only the Kramer Electronics input power
wall adapter that is provided with this unit
Warning
– Disconnect power and unplug unit from wall
before installing or removing device or servicing unit.
