Summary of Contents for Candy FC 4440 X
- Page 1 MOD. FC 4440 X USE AND MAINTENANCE INSTRUCTIONS FOR BUILT-IN OVENS...
- Page 2 Instructions for the user Thank you for choosing one of our products. We hope you will get the very best performance from this appliance. Therefore we would ask you to carefully comply with the the suggestions and instructions in this manual for proper use of our products. The manufacturer shall not be held liable for damage to persons and property which is due to poor or incorrect installation of the appliance.
- Page 3 Instructions for user Any work on the appliance must be done with the appliance disconnected from the electrical power supply. Attention: earth connection is required by law. During operation the oven gets very hot. Keep children away. Do not touch the heating elements on the inside.
- Page 4 If the oven is visibly damaged, do not use it. Unplug it and contact customer service. As soon as an operating problem is discovered, the oven must be unplugged. Make sure that the power cord of electrical appliances is not crushed by the oven door.
- Page 5 INSTRUCTIONS FOR INSTALLATION OF THE UNIT All tasks involved in installing the appliance must be carried out by skilled personnel. Any work is to be performed with the appliance unplugged. Electrical connection: make sure that the voltage corresponds to that indicated on the tag on the side. The oven must be connected using a cable with a minimum cross-section of 1.5 mm on the rear, and with an omni-polar switch compliant with current standards with a distance of aperture between contacts of at least 3 mm.
- Page 6 BUILT-IN DIAGRAM Fig. 1...
- Page 7 Fig. 2 Column Under top...
- Page 8 Before using the oven for the first time After unpacking the oven, inserting it in the furniture unit and removing the accessories (drip pan and racks), it is advisable to run it at the highest temperature for about 20 minutes to remove any oily residues left from the manufacturing process which may cause unpleasant odours during cooking.
-
Page 9: Oven Functions
OVEN FUNCTIONS Green indicator light Yellow indicator light Selector Electronic programmer Thermostat Indicator light For any position of the selector knob other than 0, the green indicator light comes on. If the yellow indicator light is on it indicates that the thermostat is in operation. Selector knob This device lets you select various cooking functions. - Page 10 USE OF THE SELECTOR DEFROSTING The oven light and the green indicator light come on as for all other oven functions. Only the fan starts working, without propagation of heat as the thermostat is not in operation. The oven door must be closed. This function makes it possible to defrost foods using only about one-third of the time that would normally be required.
- Page 11 Table of cooking suggestions Type of dish Temp. Cooking time in Level Cycle °C minutes (from bottom) Bread and biscuits Pizza 20/30 Loaf bread 190/200 45/60 Bread with filling 150/160 20/25 1 or 2 White bread 175/210 25/40 1 or 2 Biscuits 140/150 20/30...
- Page 12 Foods to be grilled Cooking time in minutes Over Under Thin meat Normal meat Fish (e.g. trout, salmon) Sausage Toast Depending on the type of food (e.g. meats, fish, poultry, etc.), you will need to turn food to expose both sides to the infrared rays The data provided above is approximate.
- Page 13 Electronic programmer - Fig. 3 Fig. 3 The electronic programmer includes the following functions: - 24-hour clock with illuminated display - Timer (up to 23 hours 59 minutes) - Programme to automatically start and stop cooking - Programme for semi-automatic cooking (possible to programme only beginning and end) Description of buttons TIMER SETTING...
- Page 14 Description of illuminated symbols « AUTO » - (flashing) - Programmer in automatic position, but not programmed. « AUTO » - (on steady) - Programmer in automatic position, with program inserted. Automatic cooking operation TIMER Timer in operation and « AUTO » (both flashing) Programme error TIMER No symbol on except for numbers on clock: programmer set in manual mode.
- Page 15 Automatic cooking Digital clock (cooking start and stop) Indicates the hours (0-24) and minutes. 1) Programme the length of cooking time with Immediately after connection (as well as after a TIMER . power outage), THREE intermittent numerals are 2) Programme the cooking stop time with END . shown on the display.
- Page 16 Semi-automatic cooking to zero. If you then press you will set up the oven for manual operation. A. Programming of cooking time. Electronic signal B. Programming of end of cooking time. The function of the «timer» consists simply of an acoustic signal which can be set for a maximum A) Set the desired cooking time using the button period of up to 23 hours and 59 minutes.
-
Page 17: Cleaning And Maintenance Of The Oven
CLEANING AND MAINTENANCE OF THE OVEN Important: Before performing any maintenance, you must either unplug the oven or disconnect the power supply via the omni-polar switch of the electrical system. Cleaning the oven: Let the oven cool after each use and clean it to keep encrusted residues from getting heated again and again. - Page 18 How to remove the oven door (fig. 4) To make it easier to clean the oven, it is possible to remove the door from the hinges as follows: The hinges A are equipped with 2 mobile U-bolts B. When the U-bolts B are lifted, the hinges are disconnected from their housing. After this, lift the door up and pull it outwards, grasping the door on the sides near the hinges.
- Page 19 Cleaning the side grilles Fig. 5 The side grilles are to be hooked onto the wall of the oven. Slide the racks and tray provided into the side grille. To remove the side grilles. press on part A as shown . Fig.
