U S E R ' S G U I D E
PN 613-10699-00 Rev. A
Ethernet
Fast
Ethernet
AT-8116

Fast Ethernet

Intelligent Switch

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AT-8116 and is the answer not in the manual?

Questions and answers

Related Manuals for Allied Telesis AT-8116

Summary of Contents for Allied Telesis AT-8116

  • Page 1: Fast Ethernet

    Ethernet Fast Ethernet AT-8116 Fast Ethernet Intelligent Switch U S E R ’ S G U I D E PN 613-10699-00 Rev. A...
  • Page 2 Allied Telesyn International Corp. be liable for any incidental, special, indirect, or consequential damages whatsoever, including but not limited to lost profits, arising out of or related to this manual or the information contained herein, even if Allied Telesyn International Corp. has been advised of, known, or should have known, the possibility of such damages.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1 Administrative Interface ............................. 1-1 Features ....................................1-1 Network Management Systems .............................. 1-3 Accessing the SNMP Agent ............................... 1-3 System Requirements ................................. 1-3 Hardware Requirements ..............................1-3 Software Requirements ..............................1-4 VT100 Terminal Settings ................................1-4 Testing the Installation ................................
  • Page 4 ..........................13-1 Chapter 14 Spanning Tree Commands ............................14-1 Chapter 15 Using an SNMP Manager ............................15-1 Configuring the AT-8116 SNMP Agent ..........................15-1 Global Setup ..................................15-1 IP Setup ....................................15-2 SNMP Setup ..................................15-3 Chapter 16 Software Troubleshooting ............................16-1 Appendix A Software Downloading ..............................

  • Page 5: Administrative Interface

    The Allied Telesyn International AT-8116 Fast Ethernet switch provides a cost-effective solution for Ethernet and Fast Ethernet connectivity. With 16 dual-speed 10/100 ports, the AT-8116 switch delivers the port density and performance required for a wide range of bandwidth-intensive applications. The autosensing 10/100 ports allow for compatibility with today’s network while providing a...
  • Page 6 Administrative Interface The AT-8116 contains a built-in SNMP agent running on the SNMP Processor Board. This allows each unit to be managed from a centralized management station via any SNMP-compliant NMS. The SNMP agent software complies with the following standards:...

  • Page 7: Network Management Systems

    Command Line Interface. The process is described in detail in the following pages. Accessing the SNMP Agent This section describes how to use the console services to configure and manage the AT-8116. To access the console, connect a terminal to the AT-8116 RS-232 DB-9 connector. System Requirements Hardware AT-8116 unit...

  • Page 8: Software Requirements

    Other applications may also provide satisfactory results. VT100 Terminal Settings Use the following settings when connecting the VT100 terminal or terminal emulator to the AT-8116. Communications Setup — 9600 (baud) — No Parity — 8 Data Bits, 1 Stop Bit —...

  • Page 9: Testing The Installation

    AT-8116 User’s Guide Testing the Installation After you have completed the installation, use the CLI ping command to test for connectivity. See Chapter 15, “ Using an SNMP Manager ” . The ping command sends an echo request to the host specified in the command line.

  • Page 11: Command Line Interface

    Chapter 2 Command Line Interface This chapter provides instructions for using the AT-8116 CLI. Features of the Command Line Interface The CLI provides the following: Configuration of system parameters, including the console’s parameters Configuration of the switch’s SNMP Agent parameters Configuration of the ports’...

  • Page 12: Entering Commands

    Command Line Interface Entering Commands Enter commands by typing the command name followed by zero or more parameters and pressing <enter>. For example, typing <banner> <enter> at the command prompt displays the Administrative Interface logo. Items typed in courier are to be typed literally, or read directly from the screen.
  • Page 13 AT-8116 User’s Guide To get an explanation of the command’s parameters add a question mark (?) after the command name: SYS_console> ping ? ping IP traffic generator [arg #0] destination IP address [arg #1] number of packets to send or 0 for endless ping SYS_console>...

  • Page 14: System Commands

    Command Line Interface When, as a result of a command, more than one screen-full of text is to be printed, the user may continue to scroll or stop the process. SYS_console>system System Commands Table 2-1 System Commands sys-stat show system status get-stst-level show the selftest level set-stst-level...

  • Page 15: Virtual Lan Commands

    AT-8116 User’s Guide Finally, the user may press <?> to see the list of commands which start with the text he has already typed, eg: User pressed <?> SYS_console>get-c? command 'get-c' not found SYS_console>get-co? Table 2-2 Commands Matching <get-c> get-comm...
  • Page 16 Command Line Interface Typing ? at the CLI prompt displays a list of all the available command topics and a short explanation about each. Typing in one of the names on this list will yield a list of the commands under that topic.

  • Page 17: Chapter 3 Console Commands

    Chapter 3 Console Commands The console commands contain a set of commands which allow the user to configure the CLI parameters and user interface. To view the console commands, type <console>. help-kbd This command lists the console function keys. SYS_console>help-kbd SYS_console>...
  • Page 18 Console Commands banner The banner command will display the CentreCOM 8116 Allied Telesyn International logo. clear The clear command will clear the screen and display the prompt. login The login command will exit the Administrative Interface, but will not disconnect a Telnet session. This allows the user to test a password (or other activity) without reconnecting.
  • Page 19 AT-8116 User’s Guide set-attr-prompt This command sets the prompt attributes. SYS_console>set-attr-prompt <number of option> [arg #0] options: 0-normal,1-bold,2- underline,4-blink,8-reverse SYS_console> set-attr-msg This command sets the display message attributes. SYS_console>set-attr-msg <number of option> [arg #0] options: 0-normal,1-bold,2- underline,4-blink,8-reverse SYS_console> set-attr-text This command sets the text display attributes.
  • Page 20 Console Commands If the user enters the old password incorrectly or fails to verify the new password correctly, the password will not be changed. SYS_console>set-passwd SYS_console> Enter old password: Enter new password: Enter new password again: Error : different new passwords If the password change succeeds, the system will respond accordingly.

  • Page 21: System Commands

    Chapter 4 System Commands The System Commands allow the user to display and set the system- related parameters. Type <system> to display system related commands. sys-stat The sys-stat command displays general status information about the Ethernet Switch and its SNMP Agent Hardware and Software: SYS_console>sys-stat CentreCOM 8116 SNMP Agent Software - Version 2.01 Mon Aug 18...
  • Page 22 System Commands 1 -- description [Port 1 - 10/100BaseTxETHERNET Port] -- status [UP] 2 -- description [Port 2 - 10/100BaseTxETHERNET Port] -- status [UP] 3 -- description [Port 3 - 10/100BaseTxETHERNET Port] -- status [UP] 4 -- description [Port 4 - 10/100BaseTxETHERNET Port] -- status [UP] 5 -- description [Port 5 - 10/100BaseTxETHERNET Port] -- status [UP] 6 -- description [Port...
  • Page 23 AT-8116 User’s Guide get-stst-level This command shows the self-test level (Disable or Enable) of the device. Default Value: Enable set-stst-level <level> This command sets the self-test level of the device. There are two levels of self-test: Disable and Enable. The self-test level is stored in Non-volatile Random Access Memory (NVRAM).
  • Page 24 System Commands init-nvram This command resets the non-volatile RAM (NVRAM) on the SNMP Agent to default values. Change will take effect after boot (warm or cold reset). get-sw-file This command retrieves the SNMP Agent Software file name. set-sw-file set-sw-file <filename> Sets the name of the file downloaded by TFTP.
  • Page 25 AT-8116 User’s Guide sw-dnld This command begins the software download process from the remote TFTP server specified by the set-tftp-srvr command, retrieving the file specified by the set-sw-file command. set-fg-param set-fg-param sets the Ethernet frame generator parameters [arg #0] destination address in hex format xx-xx-xx-xx-xx-xx...
  • Page 26 System Commands This command starts frame generation. dport is a dash-separated list of ports on which to generate traffic. For example, a dport of 2-3-4-5- 6 will send frames to ports 2,3,4,5,6. count specifies the number of frames to send on each interface. A count of 0 specifies an infinite number of packets.

  • Page 27: Chapter 5 Ip Commands

    Chapter 5 IP Commands This section lists the IP Configuration commands available to the command line interface. It is separated into different sections to allow simpler lookup: IP Configuration lists general configuration commands, Ping lists commands pertaining to the ping ability of the Agent, Address Resolution Protocol lists ARP-related information.
  • Page 28 IP Commands Sets the IP address of the SNMP Agent. If no IP address was previously set (as is the default factory configuration), the new value will be used immediately and saved into NVRAM. Otherwise the new value will only be stored in the NVRAM, and the user must execute a “warm-reset”...
  • Page 29 AT-8116 User’s Guide SYS_console>set-ip-cfg 194.90.136.187 255 255.255.0 255.255.255.255 Device IP Address set for this session Device IP Address change in the NVRAM OK The device NVRAM IP configuration will be: IP address : 194.090.136.187 IP netmask : 255.255.255.000 IP broadcast : 255.255.255.255 SYS_console>...
  • Page 30 IP Commands get-gatew Shows default gateway. This command shows which default route will be used to access a different IP network. SYS_console>get-gatew The default gateway address is: 194.090.136.254 SYS_console> set-gatew Sets the default gateway IP Address. This command lets you specify the address of the router used to access a different IP for network management packets or Ping.

  • Page 31: Address Resolution Commands

    Chapter 6 Address Resolution Commands get-arp-tbl Shows ARP table. The Address Resolution Protocol (ARP) table contains information that shows the maping of IP addresses to MAC addresses and interface numbers. SYS_console>get-arp-tbl IfIndex IpAddress MAC Address ============================================= 194.090.136.126 00-20-AF-C9-EB-23 SYS_console> del-arp-entry SYS_console>del-arp-entry {<IPaddress>|*} Deletes entries from the ARP table.
  • Page 32 Address Resolution Commands add-arp-entry Add entry to ARP table. add-arp-entry <IPaddress> <mac_address> <Interface> (Port MAC address resides on.) SYS_console>add-arp-entry 194.90.136.133 00- 11-22-33-44-55 1 ARP Table Entry succesfully added SYS_console>get-arp-tbl IfIndex IpAddress MAC Address ============================================= 194.090.136.133 00-11-22-33-44-55 194.090.136.126 00-20-AF-C9-EB-23 SYS_console>...

  • Page 33: Ping Commands

    Chapter 7 Ping Commands Ping Performing a ping allows you to send packets to another managed network device to see if the device responds. Ping <IP address><destination address><# packets to send or 0 for endless pings> ping-stop Stops the active ping process. SYS_console>ping 194.90.136.23 4 Use CTRL-C or ping-stop to stop the ping process...
  • Page 34 Ping Commands If the host does not respond, only statistics are printed. Failure to get an echo response from a host may be due to: A bad physical connection A non-existent or inactive host Network Unreachable: no corresponding entry in the routing table Destination Unreachable: the default gateway failed to route the datagram...
  • Page 35 AT-8116 User’s Guide Use CTRL-C or ping-stop to stop the ping process SYS_console>194.90.136.20 Alive. echo reply: id 4643, seq 1, echo-data-len 0 PING process stopped - statistics : ICMP echo requests ICMP echo responses PING process - press <CR> for prompt ping-stop Stop the active ping process.

  • Page 37: Chapter 8 Snmp Commands

    Chapter 8 SNMP Commands This chapter contains a description of the commands available under the CLI to set and display the SNMP Agent IP and SNMP parameters and databases. Type <SNMP> to view SNMP related commands. SNMP Community String Commands SNMP Community strings authenticate access to the MIB (Management Information Base).

  • Page 38: Snmp Trap Message Commands

    SNMP Commands set-comm set-comm {read|write} <community-string> This command lets you specify the SNMP community string for each of the two access modes: read and write. SYS_console>set-comm write password New write community is: < password > SYS_console> SNMP Trap Message Commands When the Switch detects an extraordinary event, it generates a trap.
  • Page 39 AT-8116 User’s Guide get-traps Displays the list of traps-receiving stations: their IP address and trap SNMP community string. SYS_console>get-traps SNMP TRAP TABLE =============== IPADDR COMMUNITY -------------------------------------------- 194.090.136.126 ----------- public -------------------------------------------- SYS_console> add-trap The add-trap command enters the IP Address of the SNMP Manager station and the trap community string that will appear in the trap message.
  • Page 40 SNMP Commands del-trap The del-trap command can be used to remove an SNMP station from the trap table. The station IP address must be provided. del-trap <IPaddress> SYS_console>del-trap 194.90.136.20 Entry 194.90.136.20 - rnd deleted SYS_console> get-rmon-state This command displays RMON’s limits and bounds. SYS_console>get-rmon-state RMON current configuration ==============================...

  • Page 41: Switching Database Commands

    Chapter 9 Switching Database Commands This section contains instructions for managing the Switching Database with the Administrative Interface. Type <switch-db> to view related commands. The Switching Database consists of 8192 entries. Each active entry contains the information relevant to a workstation, characterized by its Ethernet MAC Address.

  • Page 42: Learning Table

    Switching Database Commands MAC Address contained in an entry or given as a parameter is printed as a 6 byte, hexadecimal sequence, separated by the “-” sign, e.g. 00-20-1A-00-01-29 The following section lists commands relevant to the Learning Table and Aging mechanism of the switch. The <index> contained in the following commands is an integer number between 1 and the maximum size of the Switching Database Table (8192).
  • Page 43 AT-8116 User’s Guide get-lt-16 Displays 16 learn table entries starting at <index>, or “ * ” to continue from the last displayed index. The format of the display is similar to the previous command format. If the end of the learn table is reached, the * parameter will start the list over from the beginning.
  • Page 44 Switching Database Commands find-lt-addr SYS_telnet>find-lt-addr 0060e8112265 Entry ---- MAC Address ---- LOCK DPORT MGMT =============================================== 00-60-E8-11-22-65 SYS_telnet> The switch as factory-configured, has default a VBC and a SVLAN VLAN that contain all 16 ports. Ports in the default VLAN's are deleted when they are assigned to a designated VLAN.
  • Page 45 AT-8116 User’s Guide Example 3: SYS_telnet>get-vbc-tbl run RUNTIME VIRTUAL BROADCAST DOMAIN TABLE =========================================== 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 VBC - 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 - - - - - - - - + + + + + + + + SYS_telnet>...
  • Page 46 Switching Database Commands SYS_console>del-lt-entry 25 Deleting entry at index - 25 - SYS_console>del-lt-entry 1 Cannot delete a System Address del-lt-addr Deletes the learn table entry that matches the MAC address. The command fails if mac_address is not found in the learn table. Again, as in the previous command, caution should be employed when deleting system entries : (+) in MGMT column.
  • Page 47 AT-8116 User’s Guide set-lt-age set-lt-age {run|nvram|all} <aging_time> Aging _time is between 10 and 11000 seconds or 0 for aging off. Example: SYS_console>set-lt-age all 300 Aging Period update in NVRAM OK Aging Period update in the running database OK SYS_console> Lets the user modify the Switching Database Aging Time. The change...

  • Page 49: Virtual Lan Commands

    Chapter 10 Virtual LAN Commands Virtual LANs can be used to limit the broadcast domain and to establish secure virtual workgroups. The following parameters are used within the VLAN commands. run indicates that only the currently running configuration is changed. Changes are not restored after a reset. NVRAM indicates that only the configuration stored in non- volatile memory is changed.

  • Page 50: Virtual Broadcast Domains (Vbc)

    Virtual LAN Commands set-mon-port sets the monitoring port stop-mon stops port monitoring monitor starts port monitoring get-nv-mon retrieves the NVRAM based monitoring configuration save-mon saves the running monitoring configuration to NVRAM clear-nv-mon clears the NVRAM based monitoring configuration Virtual Broadcast Domains (VBC) Virtual Broadcast Domains are port-oriented VLANs that allow broadcast Ethernet addresses to be broadcasted (transmitted) to the assigned ports in that VBC.
  • Page 51 AT-8116 User’s Guide SYS_console>get-con-matrix VBC CONNECTIVITY MATRIX ========================== 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 SRC to : 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6...
  • Page 52 Virtual LAN Commands set-vbc-domain set-vbc-domain {run|nvram|all} <port_list> This command establishes a Virtual broadcast domain. port_list is a dash-separated list of ports to group into a broadcast domain. For example: set-vbc-domain all 2-5-6-7 Creates a virtual broadcast domain of ports 2, 5, 6, and 7. del-vbc-domain del-vbc-domain {run|nvram} <domain_id>...
  • Page 53 AT-8116 User’s Guide Note All ports not defined as a member of a VBC are members of the default VBC. get-vbc-matrix Retrieve the current broadcast domain matrix for the switch. Here only the broadcast address will be affected. The first column is the source port list. The other columns are broadcast destination ports.
  • Page 54 Virtual LAN Commands Security VLANs Each Security Virtual LAN (SVLAN) can contain one or more groups of ports. The group in a SVLAN are only allowed to send and receive packets to groups in the same SVLAN. If a group is not assigned to a specific SVLAN, it remains in the default SVLAN.
  • Page 55 AT-8116 User’s Guide set-sec-vlan {run|nvram|all} <group_list> SYS_console>set-sec-vlan run a-b Set Runtime Security Virtual entry - OK SYS_console>set-sec-vlan run c Set Runtime Security Virtual entry - OK SYS_console>get-svlan-tbl run RUNTIME SECURITY VIRTUAL LANs TABLE 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1...
  • Page 56 Virtual LAN Commands get-svlan-tbl This command shows the table of defined Virtual LANs. get-svlan-tbl {run|nvram} SYS_console>get-svlan-tbl run RUNTIME SECURITY VIRTUAL LANs TABLE =========================================== 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 SVLAN - 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 + + + + + + + + - - - - - - - - - - - - - - - - + + - - - - - -...
  • Page 57 AT-8116 User’s Guide get-svlan-matrix This command retrieves the Security VLANs connectivity matrix. get-svlan-matrix {run|nvram} SYS_console>get-svlan-matrix run SECURITY VLANs CONNECTIVITY MATRIX ========================================== 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 SRC to :...

  • Page 59: Port Monitoring Commands

    Chapter 11 Port Monitoring Commands set-mon-port This command sets the monitoring port (port containing the monitoring device, sniffer port). All traffic from the port specified by the monitor command will be duplicated on assigned ports. Port is a decimal number. set-mon-port <port>...
  • Page 60 Port Monitoring Commands save-mon This command saves the current port monitoring information (including set-mon-port and monitor commands) into the NVRAM, so that the monitoring will be restarted upon device reset. clear-nv-mon This command clears the port monitoring information previously stored in the NVRAM with the save-mon command. 11-2...

  • Page 61: Port Configuration Commands

    Chapter 12 Port Configuration Commands This chapter contains instructions for configuring and displaying the ports’ parameters with the Administrative Interface. Type <port-cfg> to view the related commands. get-port-cfg The get-port-cfg command displays the current port configuration. SYS_console>get-port-cfg PORT_ID LAN_TYPE LINK IF_TYPE SPEED_SEL LAN_SPEED...
  • Page 62 Port Configuration Commands The information displayed contains: An interface number (port-id) LAN type: ETH-10 indicates 10 Mbps Ethernet ETH-10/100 indicates 10/100 Mbps Ethernet ETH-100 indicates 100 Mbps Ethernet Link status: ON/OFF Physical Interface Type: TP Speed selected: FORC10 (10Mbps), FORC100 (100Mbps), ASENSE (Autosense) LAN Speed: 10Mbps or 100Mbps Full Duplex mode: OFF = Standard Ethernet (default Half...
  • Page 63 (necessitated by collisions) before restarting the backoff algorithm. In aggressive mode the AT-8116 restarts the backoff algorithm after 4 consecutive transmit trials instead of 16. This results in the switch being more aggressive in accessing the media following a collision.

  • Page 65: Switching Statistics Commands

    Chapter 13 Switching Statistics Commands This chapter contains instructions for displaying the switching statistics. Type <statistics> to view all the related commands. The commands below provide full physical layer information as well as inter-port switching statistics. clr-cnt This command clears the Ethernet and bridging counters. get-eth-cnt This command displays the Ethernet Statistics Counters for port port- number.
  • Page 66 Switching Statistics Commands get-eth-cnt <port-number> SYS_console>get-eth-cnt 8 Ethernet Statistics for Port 8 ============================================= Good Bytes Received: 249432 Good Multicast Bytes Received: 1011480 Good Broadcast Bytes Received: 85944 Good Bytes Sent: 107222 Good Frames Receive: 16011 Good Multicast Frames Receive: 991 Good BroadCast Frames Receive: 13773 Frames Sent: 1059 Receive and Transmit Collisions: 0...
  • Page 67 AT-8116 User’s Guide get-colls-cnt This command displays the Ethernet collision statistics for port port- number. get-colls-cnt <port-number> SYS_console>get-colls-cnt 8 Ethernet Collision Counters for port 8 ========================================== Collision count:0 Late Collision Count: 0 ========================================== SYS_console> get-rmon-cnt Retrieve the RMON statistics group 1 counters for port.
  • Page 68 Switching Statistics Commands get-mgm-brcnt Retrieve the counters for the management interface. SYS_console>get-mgm-brcnt Management Port Counters ============================================= Received: 15606 Bytes Received : 1119792 Filtered : Frm Received Bcast: 14219 Frm Transmited 29944 Frm Transmit Ucast: Frm Transmit Mcast: 29556 Frm Transmit Bcast: Received from port: FRAMES BYTES...

  • Page 69: System Defaults

    Chapter 14 Spanning Tree Commands Spanning Tree automatically configures a loop-free topology in a bridged environment. However, note that the bridge on this switch is not VLAN-based and only one spanning tree is allowed regardless of the number of VLANs. The Spanning Tree agent is implemented in conformance to the IEEE 802.1d standard.
  • Page 70 Spanning Tree Commands get-st-bcfg This command retrieves the Spanning Tree bridge parameters. If Spanning Tree is disabled, no parameters will be retrieved. get-st-pcfg This command retrieves the Spanning Tree port parameter table. If Spanning Tree is disabled, no parameters will be retrieved. get-st-syscfg This command retrieves the Spanning Tree state of all the ports.
  • Page 71 AT-8116 User’s Guide set-prt-prio This command sets the Spanning Tree port priority. port_number is the decimal port number, and port_priority is an integer in the range 1..255. set-prt-prio <port_number> <port_priority> set-prt-enb set-prt-enb <port_number> {enable|disable} This command enables or disables a port in the Spanning Tree.

  • Page 73: Using An Snmp Manager

    AT-8116 SNMP Management System. Configuring the AT-8116 SNMP Agent Once connected to the network and powered ON, the AT-8116 starts operating according to factory-set default values. However, to ensure proper operation and maximum performance specific to your network configuration and to provide SNMP access, some...

  • Page 74: Ip Setup

    Using an SNMP Manager IP Setup 1. Modify the system IP configuration to match your IP network. Use the set-ip-cfg command in order to provide an IP address, a netmask and a broadcast address (see IP Commands). For example: set-ip-cfg 129.001.001.064 255 255.255.255.0 129.001.001.000 Check that the actual IP configuration matches the desired one: SYS_console>get-ip-cfg...

  • Page 75: Snmp Setup

    AT-8116 User’s Guide SNMP Setup 1. Set up the SNMP communities strings for the two access modes: read and write (see SNMP Commands). Confirm that the read and write communities were properly accepted. In this example, the Read community string is public; the Write community string is private.

  • Page 77: Software Troubleshooting

    Chapter 16 Software Troubleshooting This chapter provides troubleshooting hints for problems you may encounter when trying to manage the AT-8116 using an SNMP Management System. If your SNMP Manager has trouble communicating with the SNMP Agent in the Switch, check your SNMP configuration parameters.

  • Page 79: Appendix A Software Downloading

    Use your terminal for Steps 2-7. 2. Set the TFTP mode to client using the set-tftp-mode command. 3. Insure that the host system for the TFTP server (if AT-8116 is the TFTP client , then the host system should be an TFTP sever) and AT-8116 are interconnected.

  • Page 80: 8118 Tftp Server Download Procedure

    3. Set the remote software file using the set-sw-file command. 4. Insure that the host system for the TFTP client (if AT-8116 is the TFTP sever, then the host system should be an TFTP client) and AT- 8116 are interconnected.

  • Page 81: Appendix B System Defaults

    Appendix B System Defaults Table B-1 System Default Values CONSOLE password NULL prompt SYS_console> SYSTEM SW filename changes according to revision tftp mode client SNMP Read Community: public Write Community: private Authentication Mode: enable Traps Managers: none PORT CONFIGURATION port duplex HALF port select FORC100...

  • Page 83: Appendix C Command Line Reference

    Appendix C Command Line Reference Table C-1 Console Commands help-kbd List the console functional keys banner Display banner clear Clear console screen login Exit AI; do not disconnect a Telnet session logout Exit Admin Interface and any active Telnet session set-page Set console page set-prompt...
  • Page 84 Command Line Reference Table C-2 System Commands sys-stat Show system status get-stst-level Show self-test level of switch set-stst-level Change the self-test level warm-reset Warm reset of device cold-reset Cold reset of device get-last-err Display information about the last fatal error init-nvram Initialize NVRAM to default values get-sw-file...
  • Page 85 AT-8116 User’s Guide Table C-3 IP Commands get-ip Show current IP address set-ip Set IP address get-ip-cfg Show current IP configuration set-ip-cfg Set IP address, netmask and broadcast clear-ip-cfg Clear IP configuration in NVRAM get-gatew Show default gateway set-gatew Define default gateway...
  • Page 86 Command Line Reference Table C-5 Switching Database Commands get-lt-entry Gets an LT entry at index get-lt-16 Gets 16 LT entries starting at a given index find-lt-addr Searches for an address in the LT del-lt-entry Removes an LT entry at index del-lt-addr Removes an LT with a given address add-lt-entry...
  • Page 87 AT-8116 User’s Guide Table C-7 Port Configuration Commands get-port-cfg Display the configuration of all ports set-port-dplex Set the port mode: full or half duplex set-speed-sel Set the port speed : 10Mbps, 100Mbps or Asense set-port-state Enable or disable a port when Spanning Tree algorithm...
