GateWay Fax Systems, inc.
The following example shows how to change the default configuration to 2-Line Dual-Mode (defined as configu-
ration # 03)...
With the Secure Phone idle and only the Green "Power" light illuminated:
Procedure
Press and hold
the Reset button
on the 90si
release Reset
Take the fax off-
hook
Press 0 and then
3 on the fax dial
pad
hang up the fax
Notes:
*1 Most fax machines have a button that when depressed, returns dial-tone from the telephone system. This but-
ton is often labled Hook, Manual Dial, Monitor, On Hook Dial or something to that effect. Find and use this Hook
button on your fax or use the handset. If your fax does not have a handset or a hook button you will need to tem-
porarily connect a plain old telephone to the TEL jack on the back of the fax machine to change Default Settings.
2.5

Print the Default Settings List

Currently this feature is unavailable but will be provided to you, at no charge, in a future remote software up-
grade.
The factory Default Settings List is printed from the 90si to the attached COTS fax and looks like this.
90si Default Settings List:
Configuration (select one)
->(01)<- Secure Only (factory default)
(02)
(03)
Mode (select one)
(04)
->(05)<- Full Duplex
Protocol (select one)
(06)
(07)
->(08)<- Async 9600
(09)
(10)
(11)
(12)
(13)
(14)
(15)
Misc: (select any)
->(16)<- STE Connected
(17)
www.gwfs.com, 877-951-9800, info@gwfs.com
Response
... until both the Green and Red lights extinguish, then...
the Green light will be extinguished and the Red light illuminated
(you will hear dial-tone)
*1
you will hear a beep. (Note: 03 is the configuration code for 2-Line Dual-
Mode. See the above Default Settings list for Secure Only, and 1-Line
Dual-Mode.
The Green light will blink a number of times. When it illuminated steady
the 90si will now be ready and in the 2-Line Dual-Mode configuration.
1-Line Dual-Mode
2-Line Dual-Mode
Half Duplex
Async 2400 Bd
Async 4800 Bd
Bd
Async 19200 Bd
Mil STD Handshake w/o FEC
Mil STD Handshake w/FEC
Mil STD Broadcast w/o FEC
Mil STD Broadcast w/FEC
Ricoh
Compatable
OMNI, Sectera, vIPer, other Connected
Model 90si Secure Fax Gateway
help line: 877-951-9814
User's Guide
page 11
