CNPS5700D-Cu
User s Manual
(English Edition)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CNPS5700D-Cu and is the answer not in the manual?

Questions and answers

Summary of Contents for ZALMAN CNPS5700D-Cu

  • Page 1 CNPS5700D-Cu User s Manual (English Edition)
  • Page 2: Specifications

    * If you wish to OVERCLOCK, set the fan to Normal Mode first. * Zalman Tech. Co., Ltd. is not responsible for any damages that arise from CPU OVERCLOCKING. 2. Specifications 1) Weight (with Air Duct)
  • Page 3: Exploded View

    3. Exploded View Bolt-B Air Duct Bolt-A Air Duct Base Heatsink Duct Rotating Clip Retention Guide Static Clip Heatsink <Fig. 1. Exploded View> 4. Patent Applications Patents Applications Pending in over 20 nations around the world, including the U.S.A., E.U., and Japan Korean Patent Application Nos.
  • Page 4 2) Normal Mode : 2.8 GHz and Higher Note 1) The ‘Willamette’ CPU was discontinued after the release of the 2.0GHz version. Note 2) Should you use a CPU faster than 2.8GHz check the Zalman Tech website (www.zalman.co.kr) for further info.
  • Page 5: How To Install

    How to Install 1. Thinly spread the thermal grease on the CPU core’s surface contacting the FHS. 2. Hook the static clips on the mainboard’s Retention Guide as shown in Fig. 5. To identify the static clips, refer to Fig. 1. Air Duct Heatsink Duct Static Clip...
  • Page 6 5. Slightly unscrew the Bolt-B on the Air Duct and turn the top part of the duct to the left or right so that the duct faces the exhaust fan as shown in Fig. 8. Then, screw in three Bolt-B’s tightly to hold its position.
  • Page 7 Caution) FAN MATE 1 has been specifically designed to be used with the fan of this product. Zalman Tech. Co., Ltd. is not responsible for any damage caused to systems or CPUs when using FAN MATE 1 with other types of fans.
