- Page 1 FRIGORIFERO- CONGELATORE FRIDGE-FREEZER KÜHL- GEFRIERSCHRANK REFRIGERATEUR- CONGELATEUR ZR 290/3TN LIBRETTO ISTRUZIONI INSTRUCTION BOOKLET GEBRAUCHSANWEISUNG MODE D’EMPLOI 2222 014-92/2...
-
Page 2: General Safety
WARNINGS It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can be acquainted with the functioning of the appliance and the relevant warnings. -
Page 3: Table Of Contents
CONTENTS Installation Location Cleaning the interior Building-in instructions Door reversibility Electrical connection Technical specification Operation Starting-up - Temperature Regulation Refrigeration of foods and drinks Movable shelves Positioning the door shelves Freezing fresh food and storage of frozen food Freezing fresh food Storage of frozen food Thawing Ice-cube production... -
Page 4: Installation
INSTALLATION If this appliance featuring magnetic door seals is to replace an older appliance having a spring lock Important (latch), be sure to make that spring lock unusable It is essential that the appliance be connected to an before you discard the old appliance. This will efficient earth tap. -
Page 5: Building-In Instructions
Building-in instructions D112 Fig. 1 Door reversibility Left opening (Fig. 1) Remove (P) from both sides and the door. Remove (A) Right opening and refit it on the opposite side. Refit the door and (P) Remove the pins (P) and (P1). on the left side. - Page 6 Housing dimensions Height 1580 mm Fig. 2 50-min. cm 200 Depth 550 mm Width 560 mm For appropriate venting, follow indications in Fig. 2. min. D033 Push appliance into the housing until stop strip (A) Fig. 3 touches the kitchen unit. D015 If after having carried out the previously described Fig.
- Page 7 Press in the joint covers between the appliance and the kitchen unit. Fig. 6 D030 Apply covers (B) on joint cover lugs and into hinge Fig. 7 holes. D013 Position the runners (E) at the top and bottom of the Fig.
-
Page 8: Electrical Connection
Remove the little plates and make the holes with a diam. of 2 mm. Replace the little plates over the Fig. 10 runners and screw in the screws provided (3.5x16 mm). For the alignment of the kitchen unit door, if necessary, use the clearance size of the slotted holes. -
Page 9: Operation
OPERATION Starting-up - Temperature Refrigeration of foods and drinks Regulation To achieve the best results with the refrigerator compartment, you should follow one or two very Turn the thermostat knob clockwise to the required simple rules: setting (beyond position « O »); the recommended setting is between 2 and 4. -
Page 10: Movable Shelves
Movable shelves The walls of the refrigerator are equipped with a Fig. 13 series of runners so that the shelves can be positioned as desired. D040 Positioning the door shelves Fig. 14 To permit storage of food packages of various sizes, the door shelves can be adjusted in height. -
Page 11: Freezing Fresh Food And Storage Of Frozen Food
Freezing fresh food and storage of Water ices, if consumed immediately after removal from the freezing compartment, can possibly cause frozen food the skin to be freeze burnt. The 4-star compartment ( ) is suitable for long Remember that, once thawed, frozen food deteriorates term storage of commercially frozen food and for rapidly. -
Page 12: Defrosting
Defrosting Fig. 16 Frost is automatically eliminated from the evaporator of the refrigerator compartment every time the motor compressor stops, during normal use. The defrost water drains out through a trough (Fig. 16) into a special container on the back of the appliance where it evaporates. -
Page 13: Maintenance
MAINTENANCE Interior light Unplug the appliance before carrying out any maintenance operation. The light bulb inside the refrigerator compartment can be reached as follows: Periodical cleaning unscrew the light cover securing screws; Clean the interior periodically with lukewarm water unhook the moving part by pressing it as shown in and some bicarbonate of soda.
