Summary of Contents for Zanussi ZR 230
- Page 1 FRIGORIFERO- CONGELATORE FRIDGE-FREEZER KÜHL- GEFRIERSCHRANK REFRIGERATEUR- CONGELATEUR ZR 230/2 TN LIBRETTO ISTRUZIONI INSTRUCTION BOOKLET BEDIENUNGSANLEITUNG MODE D’EMPLOI 2222 028-84...
-
Page 2: Warnings
WARNINGS It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can be acquainted with the functioning of the appliance and the relevant warnings. -
Page 3: Table Of Contents
CONTENTS Warnings Hints for freezing Hints for storage of frozen food Maintenance Cleaning the interior Periodic cleaning Operation Periods of no operation Temperature regulation Interior light Fresh food refrigeration Defrosting Freezing fresh food Customer service and spare parts Storage of frozen food Thawing Installation Ice-cube production... -
Page 4: Storage Of Frozen Food
knob to the coldest setting; but remember that, in Thawing this condition, the refrigerator compartment temperature might drop below 0°C. If this occurs Deep-frozen or frozen food, prior to being used, can reset thermostat knob to a warmer setting. be thawed in the refrigerator compartment or at room temperature, depending on the time available Warning for this operation. -
Page 5: Hints
HINTS • wrap up the food in aluminium foil or polythene Hints for refrigeration and make sure that the packages are airtight; Useful hints: • do not allow fresh, unfrozen food to touch food which is already frozen, thus avoiding a rise in Meat (all types): wrap in polythene bags and place temperature of the latter;... -
Page 6: Interior Light
Interior light The light bulb inside the refrigerator compartment can be reached as follows: - unscrew the light cover securing screw. - unhook the moving part as shown in the figure. If the light does not come on when the door is open, check that it is screwed into place properly. -
Page 7: Customer Service And Spare Parts
CUSTOMER SERVICE AND SPARE PARTS If the appliance is not functioning properly, check • If your appliance is still not working properly after that: making the above checks, contact the nearest service centre. • the plug is firmly in the wall socket and the mains power switch is on;... -
Page 8: Building-In Instructions
holes that are not used must be masked. 4. Disassemble the bottom grille. 5. Unscrew the side hole plug and refit it on the other side. 6. Disassemble the bottom hinge. 7. Remove the two doors. 8. Disassemble the middle hinge. 9. - Page 9 To build-in the appliance, proceed as follows: Fit the higher sealing strip. D747 Slide the appliance into the recess, pushing it against the wall on the handle side. D015 Apply the sealing strip pushing it between the refrigerator and the adjacent cabinet. D724 Fix the ventilation grille and the higher sealing strip with the 6 supplied screws.
- Page 10 Drill the door to fix the runner (A) as shown in figure. D117 open the appliance and kitchen unit doors to about 90°; position block (B) on the inside of the unit door as shown in Fig.; then secure it to the unit door, positioning the screws at the far left-hand end of the elongated holes in the block ;...
