- Page 3 Switch symbols (to the left) Switch for regulating the small plate at the rear Switch for regulating the large plate at the front. Switch for regulating the double plate at the rear Switch for regulating the small plate at the front. Regulating The regulating of heat is graduation-free for all plates on a scale from 1 to 12.
-
Page 4: Pilot Light
Pilot light Pilot light is activated as long as either of the unit's switches remains turned Residual-Heat indicator Each burner has a built-in indicatorlight which remains activated as long as the temperature of the burner exceeds 80 degrees Celsius, also when the burner is turned off. - Page 5 For reasons of hygiene and safety, the cooking zones must be kept clean. Grease stains and spilled food generate smoke when heated, and can even cause fire. Taking off the panel You can take the panel off, which makes it easier to clean the surface. What to do: 1.
- Page 6 Use Proper Cooking Utensils Make the most of your new ceramic- top hob unit by using proper utensils of a good quality. Only pots and pans which are expressly intended for use on ceramic- top hob units may be used. Utensils must, as a minimum, cover the entire circle which represents a given burner.
- Page 7 (use liqud AJAX or other diswashing liquid), and well wrung. All spills must be cleaned up immediately, while the burner is still warm. Use the cleaning agent supplied with the unit. Remove spots caused by utensils with aluminium bottoms, or burned grease, by polishing with the cleaning agent supplied with the unit.
- Page 8 Do not slide saucepans across the surface of the hob - always lift the pan when placing it on, or removing it from the ceramic surface. Wipe the bottom surface of the pots and pans with a clean dry cloth before placing them on the ceramic surface.
- Page 9 The decorative pattern on the ceramic surface can become scratched and marred with use, depending upon maintenance, but does not adversely affect performance. Such blemishes are not covered by the warranty. Spills and melts must be removed immediately, while the burner is still warm, using the scraper supplied with the unit.
- Page 10 The hob unit can be mounted in any type of kitchen with a table surface whose thickness is between 28 mm and 40 mm. Clearance The distance between the top side of the tabletop and the carpentry underneath must be at least 45 mm. Fixing Screw the fixing brackets out to such an extent that they can be turned in under...
- Page 11 The unit´s externally measured length 145 mm: Cooker hood 290 mm: Two-burner standard electric hob Two-burner ceramic-top electric hob Two-burner gas hob Grill 580 mm: Four-burner ceramic-top electric hob Four-burner gas hob Installation of a single unit When mounting a single unit, be it a half-or full size unit, in a table surface which is thicker than 30 mm, it is necessary to make a special notch in...
- Page 12 The electrical connection may only be performed by a qualified electrician/ competent person. The electrical connection must be carried out in accordance with prevailing regulations for appliances using heavy current. The connection must comply with any specific requirements specified by the local electricity supply authority.
-
Page 13: Technical Data
Two-phases zero-earth (max. 10A) Cable type 1 mm² HO5VV-F. The cable outside diameter must be between 7,5 and 10,5 mm. Technical data Cell Voltage 230 V Electrical connection 230/400 V 2 phases, neutral + earth Total wattage 6400W Instant heat effect 12/18 cm 1700 W Instant heat effect 21 cm 2300 W Instant heat effect 14 cm 1200 W This unit is... - Page 14 325 88-3064 Rev. 1-007...
