- Page 1 132972390.qxd 18/06/2007 14:06 Pagina User manual Washer- dryer ZWD 14581 W ZWD 14581 S ZWD 16581 W...
-
Page 2: Table Of Contents
132972390.qxd 18/06/2007 14:06 Pagina Thank you for selecting our appliance We wish you lots of enjoyment with your new appliance and we hope that you will consider our brand again when purchasing household appliances. Please read this user manual carefully and keep it throughout the product life cycle as a reference document. -
Page 3: Safety Information
132972390.qxd 18/06/2007 14:06 Pagina Safety information In the interest of your safety and to ensure Always unplug the appliance and turn off the ● the correct use, before installing and first water supply after use, clean and using the appliance, read this user manual maintenance. -
Page 4: Child Safety
132972390.qxd 18/06/2007 14:06 Pagina Never pull the power supply cable to remove ● the plug from the socket; always take hold of This appliance is designed for domestic use. ● the plug itself. It must not be used for purposes other than Never use the washer-dryer if the power ●... -
Page 5: Description Of The Appliance
132972390.qxd 18/06/2007 14:06 Pagina Description of the appliance Your new appliance is fitted with an automatic device which detectes the laundry amount in some programmes for cotton and synthetic items and chooses the best cycles parameters for washing in an economical way. Cycle time duration, energy and water consumptions are proportional to the amount of each load. -
Page 6: Control Panel And Functions
132972390.qxd 18/06/2007 14:06 Pagina Control panel and functions The programme selector dial allows to select a programme ● Programme selector dial and and/or to switch the machine on/off. It can be turned either On/Off switch clockwise or anticlockwise. The light Start/Pause starts to flash. Press the Temperature button repeatedly to change the ●... - Page 7 132972390.qxd 18/06/2007 14:06 Pagina Control panel and functions By depressing this button you can select a timed drying ● programme for cotton or synthetics, the relevant light illuminates. To select the drying time push the button until the time you want appears in the display according to the fabrics Drying Time button (cotton or synthetics) you have to dry.
-
Page 8: Programme Table
132972390.qxd 18/06/2007 14:06 Pagina Programme table - Proportional programmes Programme/ Description of Type of laundry Options Temperature programme White and coloured Main wash from 95°C Cotton cotton (Normally soiled): Cold Spin red. 95 - e.g. sheets, tablecloths, 3 rinses Extra Rinse household linen, towels. - Page 9 132972390.qxd 18/06/2007 14:06 Pagina Programme table Programme/ Description of Type of laundry Options Temperature programme Synthetic or mixed Main wash from 60°C Synthetics fabrics, underwear, Cold Spin red. Normal coloured garments, non- 3 rinses Extra rinse 60 - shrink shirts, blouses. Short spin Prewash at 30°C Synthetic or mixed...
- Page 10 132972390.qxd 18/06/2007 14:06 Pagina Programme table - Special programmes Programme/ Description of Type of laundry Options Temperature programme Main Wash at 30°C Mini 30’ Short cycle for lightly 2 rinses 30° soiled fabrics Short spin Main Wash at 30°C Duvet Special cycle for 3 rinses 30°...
-
Page 11: Drying Programmes
132972390.qxd 18/06/2007 14:06 Pagina Drying programmes Drying time Degree of drying Type of fabric Max Load Spin speed mins 1600 rpm 95-105 3.5 kg Extra dry 1400 rpm 100-110 Cotton and linen (bathrobes, Ideal for bath towels, etc towelling materials 1600 rpm 45-55 1.5 kg... -
Page 12: Programme Information
132972390.qxd 18/06/2007 14:06 Pagina Programme information This programme can be selected for slightly or normally soiled cotton items. The temperature will decrease and the washing time will be Eco programmes extended. This allows to obtain a good washing efficiency by saving energy. -
Page 13: Washing And Drying Hints
132972390.qxd 18/06/2007 14:06 Pagina Washing and drying hints Sorting the laundry Remove the laundry when the appliance has finished drying. Follow the wash code symbols on each To avoid a static charge when drying is com- garment label and the manufacturer’s washing pleted, use either a fabric softener when you instructions. -
Page 14: Maximum Loads
132972390.qxd 18/06/2007 14:06 Pagina Maximum loads Oil based paint: moisten with benzine stain remover, lay the garment on a soft cloth and Recommended loads are indicated in the dab the stain; treat several times. programme charts. Dried grease stains: moisten with turpentine, General rules: lay the garment on a soft surface and dab the Cotton, linen: drum full but not too tightly... -
Page 15: Degrees Of Water Hardness
132972390.qxd 18/06/2007 14:06 Pagina The choice of detergent will depend on the Follow the product manufacturers’ instructions type of fabric (delicates, woollens, cottons, on quantities to use. etc.), the colour, washing temperature and Degrees of water hardness degree of soiling. All commonly available washer-dryer Follow the product manufacturers’... -
Page 16: Before The First Use
132972390.qxd 18/06/2007 14:06 Pagina Before the first use Acoustic signals WARNING! The machine is provided of an acoustic device, Ensure that the electrical and water which sounds in the following cases: connections comply with the installation at the end of the cycle ●... -
Page 17: Operating Sequence
132972390.qxd 18/06/2007 14:06 Pagina Operating sequence Synthetics, ● 1. Load the laundry Delicates, ● Open the door by Special, ● carefully pulling the Drying ● door handle outwards. The green Start/Pause light starts to flash. Place the laundry in the The selector dial can be turned either drum, one item at a clockwise or anticlockwise. - Page 18 132972390.qxd 18/06/2007 14:06 Pagina Operating sequence When the programme has finished, the 5. Select the spin speed or Night Cycle Start/Pause light goes off, on the display or Rinse Hold option appears a flashing zero « », the «Lock» 0.00 ZWD 14581W - S ZWD 16581W light is alight and the door is locked to indicate...
- Page 19 132972390.qxd 18/06/2007 14:06 Pagina Operating sequence Extra dry (cottons). After selecting a programme, the duration is ● displayed in hours and minutes (for example Cupboard dry (cottons and synthetics). ● 2.05). The duration is calculated automatically Iron dry (cottons). ● on the basis of the maximum recommended The corresponding pilot light illuminates.
- Page 20 132972390.qxd 18/06/2007 14:06 Pagina Operating sequence Drying phase During the drying phase the display shows the drying icon illuminated and the selected drying time to indicate that the After the machine has started, only the running appliance has started icon stays on. When the programme has the drying phase.
- Page 21 132972390.qxd 18/06/2007 14:06 Pagina Operating sequence IMPORTANT! Cancelling the delayed start: If an incorrect option is selected, the red pilot You can cancel the delay time at any moment, light of the Start/ Pause button flashes for 3 before you press the Start/Pause button. times and the message Err is displayed for If you have already pressed the Start/Pause about 2 seconds.
- Page 22 132972390.qxd 18/06/2007 14:06 Pagina Operating sequence Interrupting a programme At the end of the programme Depress the Start/Pause button to interrupt a The machine stops automatically. The programme which is running, the Start/Pause and «Lock» lights go off, and on corresponding light starts to flash.
-
Page 23: Drying
132972390.qxd 18/06/2007 14:06 Pagina Drying programme position (except «Off»), the door Drying 3.5 kg of Cottons can be immediately opened. You have for example just machine-washed and 6. Turn the selector dial to the «Off» position to spun at 1400 rpm 7 kg of laundry. switch the machine off. -
Page 24: Care And Cleaning
132972390.qxd 18/06/2007 14:06 Pagina Care and cleaning IMPORTANT! Remove the drawer by pressing the catch downwards and by pulling it out. Flush it out You must DISCONNECT the appliance from under a tap, to remove any traces of the electricity supply, before you can carry out accumulated powder. - Page 25 132972390.qxd 18/06/2007 14:06 Pagina Care and cleaning • Close the pump door. • pull out the emergency emptying cap from the IMPORTANT! filter cover, using a pliers. When the appliance is in use and depending • when no more water comes out, unscrew the on the programme selected there can be hot pump cover, using a pliers, and remove the water in the pump.
- Page 26 132972390.qxd 18/06/2007 14:06 Pagina Care and cleaning The dangers of freezing place a bowl with a small edge close to the ● pump to collect any spillage. Remove the If the machine is exposed to temperatures emergency emptying cap from the filter below 0°C, certain precautions should be cover.
-
Page 27: Something Not Working
132972390.qxd 18/06/2007 14:06 Pagina Something not working IMPORTANT! Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Centre, please carry out the checks listed below. - Page 28 132972390.qxd 18/06/2007 14:06 Pagina Malfunction Possible Cause / Solution The end of the drain hose is too low. The machine fills then empties • Refer to relevant paragraph in «water drainage» immediately: section. The drain hose is squashed or kinked. •...
- Page 29 132972390.qxd 18/06/2007 14:06 Pagina Malfunction Possible Cause / Solution The programme is still running. • Wait the end of washing cycle. The door lock has not been released. The door will not open: • Wait about 2 minute. There is water in the drum. •...
-
Page 30: Technical Data
132972390.qxd 18/06/2007 14:06 Pagina Technical data Dimensions Width 60 cm Height 85 cm Depth (inclunding the porthole) 63 cm Electrical connection Voltage - Information on the electrical connection is given on the rating Overall power - Fuse plate on the inner edge of the appliance door Water supply pressure Minimum 0,05 MPa... -
Page 31: Consumption Values
132972390.qxd 18/06/2007 14:06 Pagina Consumption values Energy Water Programme Programme consumption consumption duration (in kWh) (in litres) Cottons Normal 95°- Cottons Prewash 95°C - Cottons Superquick 95 - Synthetics Normal 60°C - 1.05 Synthetics Prewash 60°C - Synthetics Superquick 60°C- Easy Iron 40°C 0.45 0.55... -
Page 32: Installation Instruction
132972390.qxd 18/06/2007 14:07 Pagina Installation instruction Unpacking 5. Remove the bracket D, refit the six smaller bolts C and slide out the relevant plastic All transit bolts and packing must be removed spacer E. before using the appliance. You are advised to keep all transit devices so that they can be refitted if the machine ever has to be transported again. - Page 33 132972390.qxd 18/06/2007 14:07 Pagina The appliance must be connected to a cold water supply. A minimum water pressure of 0.05 MPa (0.5 bar) is required for safe operation of the appliance. If you cannot make the cold water connection direct from the rising mains, you may be able to operate the appliance from your cold water storage system.
- Page 34 132972390.qxd 18/06/2007 14:07 Pagina Level the washer-dryer by raising or lowering the feet. The feet may be tight to adjust as they incorporate a self locking nut, but the machine MUST be level and stable. Any necessary adjustment can be made with a spanner.
- Page 35 132972390.qxd 18/06/2007 14:07 Pagina If you require any further advice please The wires in the mains lead are coloured in contact your local water authority. accordance with the following code: Green and Yellow ......- Earth Blue ............- Neutral Brown..........- Live The wire coloured green and yellow must be connected to the...
-
Page 36: Fitting Under A Counter
132972390.qxd 18/06/2007 14:07 Pagina Fitting under a counter WARNING! Before any work to the appliance, you must disconnect the plug from the power socket. Important! For safety reasons, it is dangerous to fit the appliance under a counter without the steel plate, which you can order in your nearest Service Force Centre. -
Page 37: Environmental Concerns
132972390.qxd 18/06/2007 14:07 Pagina Environmental concerns Packaging materials Ecological hints The materials marked with the symbol To save water, energy and to help protect the recyclable. environment, we recommend that you follow >PE<=polyethylene these tips: >PS<=polystyrene Normally soiled laundry may be washed ●... -
Page 38: Guarantee Conditions
132972390.qxd 18/06/2007 14:07 Pagina Guarantee conditions Standard guarantee conditions Service and Spare Parts. We, Zanussi-Electrolux, undertake that if In the event of your appliance requiring within12 months of the date of the purchase service, or if you wish to purchase spare parts, this Zanussi-Electrolux appliance or any part please contact your local Service Force Centre thereof is proved to be defective by reason... - Page 39 132972390.qxd 18/06/2007 14:07 Pagina For Customer Service in The Republic of European guarantee Ireland please contact us at the address below: This appliance is guaranteed by Electrolux, in Electrolux Group (Irl) Ltd each of the countries listed in the following Long Mile Road, Dublin 12, Republic of Ireland page, for the period specified in the appliance Tel: + 353 (0)1 4090751...
