Sennheiser SKM 500 G3 945 Quick Manual

Sennheiser SKM 500 G3 945 Quick Manual

Handheld vocal radio microphone
Hide thumbs Also See for SKM 500 G3 945:
1
2
3
4
5
6
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
SKM 500 G3 945
SKM 500 G3 965

FEATURES

Sturdy metal housing

42 MHz bandwidth: 1680 tunable UHF

frequencies for interference-free reception
Pilot tone squelch for eliminating RF inter-

ference when transmitter is turned off
Enhanced AF frequency range

Increased range for audio sensitivity

Wireless synchronization via infrared

interface from receiver
User-friendly menu operation with more

control options
Illuminated graphic display

Auto-Lock function avoids accidental

changing of settings
HDX compander for crystal-clear sound

Battery indication in 4 steps, also shown

on receiver display
Easy-exchangeable microphone modules

from evolution series
Contacts for recharging BA 2015 accupack

directly in the transmitter
Wide range of accessories adapts the

system to any requirement
Optimized PLL synthesizer and micro-

processor technology
Increased immunity to intermodulation

and interferences in multi-channel
operation
SKM 500 G3 945
Enhanced frequency bank system with up

to 32 compatible frequencies
SKM 500 G3 965
Enhanced frequency bank system with up

to 32 compatible frequencies
Handheld vocal radio microphone
SKM 500 G3 945
The SKM 500 handheld transmitter features high RF transmission power for
extra-reliable reception. Even more impressive is the sound of the super-cardioid
microphone capsule which is highly feedback-resistant. Built-in charging contacts
can charge the optional rechargeable
battery by simply placing the mic on
the optional charger. With German-
engineered components from stage-
tested technology, the SKM 500-945 G3
is made for performances that leave a
lasting impression.
SKM 500 G3 965
With its ultra-reliable performance and professional features like 32 frequency
presets per range, the SKM 500 handheld transmitter is a true marvel of audio
technology. While the G3 wireless technology is impressive, the real star of this
combination is clearly the true condenser evolution 965 microphone. The uniquely
resonant and distortion-free sound of the large diaphragm dual-capsule micro-
phone lets the singing voice become an authentic and intimate experience for any
audience. Experience a studio-quality true-condenser microphone that is designed
for wireless stage use. The 965
capsule can be switched between
cardioid and super-cardioid patterns,
making it versatile for a wide variety
of styles.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SKM 500 G3 945 and is the answer not in the manual?

Questions and answers

Related Manuals for Sennheiser SKM 500 G3 945

Summary of Contents for Sennheiser SKM 500 G3 945

  • Page 1 SKM 500 G3 945 SKM 500 G3 965 Handheld vocal radio microphone FEATURES SKM 500 G3 945 Sturdy metal housing The SKM 500 handheld transmitter features high RF transmission power for 42 MHz bandwidth: 1680 tunable UHF extra-reliable reception. Even more impressive is the sound of the super-cardioid frequencies for interference-free reception microphone capsule which is highly feedback-resistant.

  • Page 2: Technical Data

    SKM 500 G3 945, SKM 500 G3 965 Handheld vocal radio microphone ARCHITECT’S TECHNICAL DATA SPECIFICATIONS Modulation ...............wideband FM Frequency ranges............ 516 – 558, 566 – 608, 626 – 668, The handheld vocal radio microphone shall 734 –776, 780 – 822, 823 – 865 MHz be for use with a companion receiver as part Transmission frequencies ........
  • Page 3 SKM 500 G3 945, SKM 500 G3 965 Handheld vocal radio microphone ARCHITECT’S TECHNICAL DATA SPECIFICATIONS SKM 500 G3 965 Transducer/microphone type ......externally polarized dual diaphram Power shall be supplied to the radio micro- condenser microphone phone by two 1.5V AA size batteries or by...
  • Page 4 SKM 500 G3 945, SKM 500 G3 965 Handheld vocal radio microphone DIMENSIONS FREQUENCY RESPONSE AND POLAR PATTERN SKM 500 G3 965 – Niere SKM 500 G3 945 1 0 0 2 0 0 5 0 0 1 0 k 2 0 k 0°...

  • Page 5: Recommended Accessories

    SKM 500 G3 945, SKM 500 G3 965 Handheld vocal radio microphone PRODUCT VARIANTS MMD 835-1 BK – e835 dynamic cardioid microphone module for G3 or 2000 Series SKM 500 G3 945 SKM transmitters Cat. No. 502575 SKM 500-945 G3-A –...
  • Page 6 SKM 500 G3 945, SKM 500 G3 965 Handheld vocal radio microphone RECOMMENDED ACCESSORIES SKM 500 G3 965 MME 865-1 BK – e865 polarized, condenser, super-cardioid microphone module for G3 or 2000 Series SKM transmitters Cat. No. 502581 MMK 965-1 BK – e965 switchable condenser...
