American Standard Colony Single Control Kitchen Faucet 4175.203 Specification Sheet

4175.201 Shown
21mm
(13/16)

GENERAL DESCRIPTION:

Brass 7-5/8" (194mm) swivel spout. Metal lever handle.
Washerless 40mm ceramic disc valve cartridge. Cast brass
waterway with 1/2" male inlet shanks. Metal escutcheon plate
(escutcheon size 10-1/4"L x 2-3/8"W). 2.2gpm/8.3L/min.
maximum flow rate.
SUGGESTED SPECIFICATION:
Single control kitchen faucet shall feature cast brass waterway. Shall also feature washerless 40mm ceramic disc valve
cartridge. Faucet shall be American Standard Model # 4175.____.____.
© 2008 AS America Inc.
194mm
(7-5/8")
111mm
(4-3/8")
146mm
(5-3/4")
25mm
(1")MAX.
259mm
(10-1/4")
SINGLE CONTROL KITCHEN FAUCET
MODEL NUMBER:
4175.201 Kitchen Faucet
Metal Lever Handle. Separate Handspray.
4175.203 Kitchen Faucet
Metal Lever Handle. Handspray through escutcheon.
4175.200 Kitchen Faucet
Metal Lever Handle. Less Handspray.
173mm
(6-13/16")
114mm
(4-1/2")
51mm
(2")
35mm to 38mm
(1-3/8" to 1-1/2")
DIA. MOUNTING
HOLE (4 PLACES)

PRODUCT FEATURES:

Ceramic Disc Valve Cartridge:
drip-free performance.
Cast Brass Waterways
durable. Integral tabs on casting provide a wobble-free
installation.
Low Lead:
Meets NSF Standard 61/Section 9 & Prop 65
lead requirements.
Memory Position Valving:
and off at preferred temperature setting without readjusting
handle position each time.
Large "Comfort Zone":
temperature.
Simple Installation:
installation. Faucet drops in from top. Quick spin nuts secure
faucet in place.
A29
COLONY
105mm
(4-1/8")
Assures a lifetime of
:
with "City Shanks" Strong and
Allows user to turn valve on
Allows easy fine tuning of
Fast and easy one person
