LAN Port - Page

DHCP Client: Selecting DHCP Client will cause the device to obtain an
IP address from the local DHCP server.
Static IP: Selecting Static IP requires you to assign the IP information for
the device manually.
MTU: The default MTU (maximum transmission unit) is 1500 bytes. If
your network supports Jumbo Frames you can specify larger frame
sizes (in the range of 3000-9000) by fi rst selecting Enable in the MTU
Settings dialogue.

EXT Port - Page

The Local Area Network settings for the device's EXT Port can be
confi gured on the EXT Port page.
DHCP Client: Selecting DHCP Client will cause the device to obtain an
IP address from the local DHCP server.
Static IP: Selecting Static IP requires you to assign the IP information for
the device manually.
MTU: The default MTU (maximum transmission unit) is 1500 bytes. If
your network supports Jumbo Frames you can specify larger frame
sizes (in the range of 3000-9000) by fi rst selecting Enable in the MTU
Settings dialogue.

Basic Setup - Section

The Time and Date of the device's internal clock can be set manually or
be set automatically from the client computer or using an NTP Server.

Date and Time - Page

Time Zone: Choose the Time Zone of where you are located from the
drop-down menu.
Set from Computer: To set the internal clock of the PowerBay NAS array
to the same time as the client computer, select Set from Computer and
hit Save.
Set the Date and Time Manually: To set the date and time manually,
select Set Manually, and fi ll in the date and time using the drop-down
menus. Press Save to save the new settings.
NTP Server: Tick the Enable NTP Server checkbox to enable NTP.
Network Time Protocol (NTP) synchronizes the device with an Internet
time server.
Type the URL of the NTP Server in the NTP Server checkbox or use the
drop-down menu to choose one of the default time servers listed for
your convenience. Press Save to save the new settings.

Device Settings - Page

The device settings page allows you to confi gure the Workgroup or
Active Directory settings of your network on the device.
If your network is confi gured as a Workgroup, click the Workgroup
radio button. Confi gure the parameters as described below:
8
