RAID 5 allows the array to continue operating even if one of the disks
fails.
The diagram below indicates the operation of RAID 5:
RAID 6
RAID 6 is an extension of RAID 5. It adds an additional parity block by
using block-level striping with two par¬ity blocks distributed across all
the member disks.
RAID 6 allows the array to continue operating even if two of the disks
fail.
The diagram below indicates the operation of RAID 6:
Technical Specifi cations
Physical & Environmental
Feature
Power Supply
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
MTBF
RoHS
Dimension
Software Features
Feature
Network fi le Protocols
Standards
Network Service Protocols
Network Client Type
File System
File Sharing
User Interface
HDD
Two RESET modes
Avoid risk of explosion if the battery is replaced by an incorrect type. Please dispose of
the used batteries according to the instructions.
Technical Support
If you are experiencing diffi culty installing or using your Verbatim
product, please visit the main Verbatim Technical Support website at
www.verbatim-europe.com. From this page you can access our library
of user documentation, read answers to frequently asked questions, and
download available software updates. Although most of our customers
fi nd this content suffi cient to put them back on the right track, this page
also lists ways in which you can contact the Verbatim Technical Support
Team directly.
Europe: For technical support in Europe e-mail drivesupport@verbatim-
europe.com or call 00 800 3883 2222 in the following countries: Austria,
Belgium, Denmark, Finland, France, Germany, Hungary, Italy, Luxemburg,
Monaco, Netherlands, Norway, Poland, Portugal, Republic of Ireland,
Spain, Sweden, Switzerland and United Kingdom. All other countries call
+353 61 226586.
23
Detailed Description
• SANSHIN ATX Power Supply (SU-082RW)
• AC Input: 100~240Vac/1.8~0.7A; 50~60Hz
• DC Output:12/5/3.3/5Vdc/4.5/10/4.5/1A (124W)
5 ~ 35°C
-20~60°C
10 ~ 85% non-condensing
5 ~ 95% non-condensing
35°C, 5 years
Complies with RoHS
170mm x 183mm x 230mm
(Including rubber feet)
Detailed Description
FTP, SMB, NFS, AFP
IEEE 802.3/u/ab
DHCP Client, SMB (Samba), SMTP, NTP
Windows 7, 2000, XP, Vista; Linux; Mac OS X 10.2
and higher
Internal HDD: EXT2/EXT3
External USB Storage: FAT32 (Read/Write) or NTFS
(Read Only)
External eSATA device: FAT32 (Read/Write) or NTFS
(Read Only)
• Max User Accounts: 128
• Max Groups: 10
• Max Shared Folders: 32
• Max Concurrent Connections:128 (Samba) /10 (FTP)
• HTTP Web browser – Internet Explorer v6 or later;
Mozilla Firefox; Safari
• Magical Finder utility
• HDD control and management via PC
• Reformat Disk
• Disk Check
• S.M.A.R.T Check
• 256-bit AES Disk Encryption
• Reset by web confi guration GUI button
• Reset by rear panel reset button (press and hold
more than 5 seconds)
